ESD227-U1-W01005
数据:
分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 瞬态抑制二极管
描述: Uni-directional ESD protection device, 5.5 V, 1.4 pF, 01005
C[L ]: 1.4pF
I[EFT ]: 60A
Protected Lines: 1
R[dyn](reverse): 0.15Ω
R[dyn](forward): 0.11Ω
V[WM]: 5.5V
V[cl typ. reverse](@16A): 9.5V
V[ESD] min: -20.0kV
V[ESD] max: 20.0kV
I[R] max: 50.0nA
I[PP]: 5A
C[L ]: 3.2pF
V[ESD] max: 16.0kV
R[dyn](reverse): 0.27Ω
R[dyn](forward): 0.27Ω
I[R]: 1.0nA
I[EFT ]: 40A
I[PP]: 3.0A
Protected Lines: 1
V[WM] max: 22.0V
V[cl typ. reverse](TLP 16A): 26.5 V
V[cl typ. reverse](TLP 30A): 30.0V
C[L ]: 5.8pF
V[ESD] max: 15.0kV
R[dyn](reverse): 0.1Ω
R[dyn](forward): 0.1Ω
I[R] max: 30.0nA
I[EFT ]: 40A
I[PP]: 5.0A
Protected Lines: 1
V[WM] max: 5.5V
V[cl typ. reverse](TLP 30A): 9.0V
V[cl typ. reverse](TLP 16A): 7.5 V
R[dyn](reverse): 0.22Ω
R[dyn](forward): 0.37Ω
I[R]: 1.0nA
C[L ]: 5.0pF
V[ESD] max: 20.0kV
I[PP]: 2.5A
Protected Lines: 1
V[WM] max: 5.5V
V[cl typ. reverse](@16A): 10.0V
V[cl typ. reverse](TLP 16A): 10 V
I[EFT ]: 50 A
C[L ]: 30.0pF
I[EFT ]: 60A
I[R]: 1.0nA
I[PP]: 11A
Protected Lines: 1
R[dyn](forward): 0.07Ω
R[dyn](reverse): 0.07Ω
V[ESD] max: 30.0kV
V[cl typ. reverse](TLP 16A): 5.8
V[cl typ. reverse](@16A): 5.8V
V[WM] max: 3.3V
I[R] max: 50.0nA
V[ESD] max: 30.0kV
R[dyn](reverse): 0.13Ω
C[L ]: 14.0pF
R[dyn](forward): 0.13Ω
I[PP]: 8A
I[EFT ]: 40A
Protected Lines: 1
V[WM]: 3.3V
V[cl typ. reverse](@16A): 7.0V
V[cl typ. reverse](TLP 16A): 7 V
ESD254-B1-W01005
数据:
分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 瞬态抑制二极管
描述: High Operating Voltage, Multipurpose, Bi Directional ESD/ Transient Protection Diode (TVS: transient voltage suppressor)
C[L ]: 2.5pF
Protected Lines: 1
R[dyn](reverse): 0.38Ω
R[dyn](forward): 0.38Ω
V[ESD] max: 15.0kV
V[cl typ. reverse](@16A): 33.5V
V[cl typ. reverse](TLP 16A): 33.5V
V[WM] max: 24.0V
I[R]: 1.0nA
I[PP]: 2 A
I[EFT ]: 40 A
C[L ]: 6.0pF
V[ESD] max: 15.0kV
R[dyn](reverse): 0.09Ω
R[dyn](forward): 0.09Ω
I[R]: 1.0nA
I[EFT ]: 50A
I[PP]: 4.0A
Protected Lines: 1
V[WM] max: 3.3V
V[cl typ. reverse](TLP 30A): 7.4V
V[cl typ. reverse](TLP 16A): 6 A
C[L ]: 2.8pF
I[EFT ]: 40A
I[R] max: 100.0nA
I[PP]: 3A
Protected Lines: 1
R[dyn](reverse): 0.3Ω
R[dyn](forward): 0.15Ω
V[ESD] max: 15.0kV
V[WM] max: 24.0V
V[cl typ. reverse](TLP 30A): 36.5V
V[cl typ. reverse](TLP 16A): 32.5 V
C[L ]: 9.0pF
V[ESD] max: 25.0kV
R[dyn](reverse): 0.3Ω
R[dyn](forward): 0.18Ω
I[R]: 1.0nA
Protected Lines: 1
V[WM] max: 14.0V
V[cl typ. reverse](@16A): 26.0V
V[cl typ. reverse](TLP 16A): 26 V
I[EFT ]: 60 A
I[PP]: 3 A
