Product type: Analog output Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -14 Input offset (±) (max) (µV): 70 Input offset drift (±) (typ) (µV/°C): 0.3 Voltage gain (V/V): 1000 CMRR (min) (dB): 120 Bandwidth (kHz): 2 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 0.9 Number of channels: 1 Comparators (#): 0 Gain error (%): 1.6 Gain error drift (±) (max) (ppm/°C): 50 Slew rate (V/µs): 0.2 Features: Bidirectional, Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125 Product type: Analog output 更多

Product type: Analog output Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -14 Input offset (±) (max) (µV): 70 Input offset drift (±) (typ) (µV/°C): 0.3 Voltage gain (V/V): 100 CMRR (min) (dB): 120 Bandwidth (kHz): 10 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 0.9 Number of channels: 1 Comparators (#): 0 Gain error (%): 1.4 Gain error drift (±) (max) (ppm/°C): 50 Slew rate (V/µs): 0.2 Features: Bidirectional, Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125 Product type: Analog output 更多

Product type: Analog output Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -14 Input offset (±) (max) (µV): 70 Input offset drift (±) (typ) (µV/°C): 0.3 Voltage gain (V/V): 50 CMRR (min) (dB): 120 Bandwidth (kHz): 10 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 0.9 Number of channels: 1 Comparators (#): 0 Gain error (%): 1.4 Gain error drift (±) (max) (ppm/°C): 50 Slew rate (V/µs): 0.2 Features: Bidirectional, Low-side Capable Rating: Automotive TI functional safety category: Functional Safety-Capable Operating temperature range (°C): -40 to 125 更多

Product type: Analog output Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -14 Input offset (±) (max) (µV): 70 Input offset drift (±) (typ) (µV/°C): 0.3 Voltage gain (V/V): 50 CMRR (min) (dB): 120 Bandwidth (kHz): 10 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 0.9 Number of channels: 1 Comparators (#): 0 Gain error (%): 1.4 Gain error drift (±) (max) (ppm/°C): 50 Slew rate (V/µs): 0.2 Features: Bidirectional, Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125 Product type: Analog output 更多

Product type: Analog output Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -16 Input offset (±) (max) (µV): 2500 Input offset drift (±) (typ) (µV/°C): 2.5 Voltage gain (V/V): 14 CMRR (min) (dB): 100 Bandwidth (kHz): 130 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 0.95 Number of channels: 1 Comparators (#): 0 Gain error (%): 1 Gain error drift (±) (max) (ppm/°C): 50 Slew rate (V/µs): 2 Features: Low-side Capable Rating: Automotive Operating temperature range (°C): -40 to 125 Product type: Analog output 更多

Product type: Analog output with integrated comparator Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -16 Input offset (±) (max) (µV): 2500 Input offset drift (±) (typ) (µV/°C): 5 Voltage gain (V/V): 20 CMRR (min) (dB): 100 Bandwidth (kHz): 500 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 2.8 Number of channels: 1 Comparators (#): 2 Gain error (%): 1 Gain error drift (±) (max) (ppm/°C): 100 Slew rate (V/µs): 1 Features: Alert Function, Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125 Product type: Analog output with integrated comparator 更多

Product type: Analog output with integrated comparator Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -16 Input offset (±) (max) (µV): 2500 Input offset drift (±) (typ) (µV/°C): 5 Voltage gain (V/V): 50 CMRR (min) (dB): 100 Bandwidth (kHz): 300 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 2.8 Number of channels: 2 Comparators (#): 0 Gain error (%): 1 Gain error drift (±) (max) (ppm/°C): 100 Slew rate (V/µs): 1 Features: Alert Function, Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125 Product type: Analog output with integrated comparator 更多

Product type: Analog output with integrated comparator Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -16 Input offset (±) (max) (µV): 2500 Input offset drift (±) (typ) (µV/°C): 5 Voltage gain (V/V): 100 CMRR (min) (dB): 100 Bandwidth (kHz): 200 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 2.8 Number of channels: 2 Comparators (#): 0 Gain error (%): 1 Gain error drift (±) (max) (ppm/°C): 100 Slew rate (V/µs): 1 Features: Alert Function, Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125 Product type: Analog output with integrated comparator 更多

Product type: Analog output Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -16 Input offset (±) (max) (µV): 2500 Input offset drift (±) (typ) (µV/°C): 2.5 Voltage gain (V/V): 20 CMRR (min) (dB): 100 Bandwidth (kHz): 130 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 0.95 Number of channels: 1 Comparators (#): 0 Gain error (%): 1 Gain error drift (±) (max) (ppm/°C): 50 Slew rate (V/µs): 1 Features: Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125 Product type: Analog output 更多

Product type: Analog output with integrated comparator Common-mode voltage (max) (V): 80 Common-mode voltage (min) (V): -16 Input offset (±) (max) (µV): 2500 Input offset drift (±) (typ) (µV/°C): 5 Voltage gain (V/V): 20 CMRR (min) (dB): 100 Bandwidth (kHz): 500 Supply voltage (max) (V): 18 Supply voltage (min) (V): 2.7 Iq (max) (mA): 1.85 Number of channels: 1 Comparators (#): 1 Gain error (%): 1 Gain error drift (±) (max) (ppm/°C): 100 Slew rate (V/µs): 1 Features: Alert Function, Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125 Product type: Analog output with integrated comparator 更多
