Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 0.25 Vin (max) (V): 5.5 Vin (min) (V): 2.7 Vout (max) (V): 3.3 Vout (min) (V): 1.8 Fixed output options (V): 1.8, 3.3 Rating: Catalog Noise (µVrms): 32 PSRR at 100 KHz (dB): 35 Iq (typ) (mA): 0.3 Thermal resistance θJA (°C/W): 52 Load capacitance (min) (µF): 2.2 Regulated outputs (#): 2 Features: Enable, Sequencing and monitoring Accuracy (%): 3 Dropout voltage (Vdo) (typ) (mV): 125 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 0.25 更多

Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 0.25 Vin (max) (V): 5.5 Vin (min) (V): 2.7 Vout (max) (V): 5.4 Vout (min) (V): 1.2 Fixed output options (V): 1.8, 2.8, 2.85 Rating: Catalog Noise (µVrms): 32 PSRR at 100 KHz (dB): 37 Iq (typ) (mA): 0.3 Thermal resistance θJA (°C/W): 50 Load capacitance (min) (µF): 2.2 Regulated outputs (#): 2 Features: Enable Accuracy (%): 3 Dropout voltage (Vdo) (typ) (mV): 125 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 0.25 更多

Output options: Adjustable Output, Fixed Output Iout (max) (A): 0.8 Vin (max) (V): 15 Vin (min) (V): 2.7 Vout (max) (V): 13.7 Vout (min) (V): 1.25 Fixed output options (V): 1.5, 1.8, 2.5, 3.3, 5, 13.7 Rating: Catalog Noise (µVrms): 411 PSRR at 100 KHz (dB): 28 Iq (typ) (mA): 1.7 Thermal resistance θJA (°C/W): 28 Load capacitance (min) (µF): 10 Regulated outputs (#): 1 Accuracy (%): 3.75 Dropout voltage (Vdo) (typ) (mV): 1200 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Fixed Output Iout (max) (A): 0.8 Vin (max) (V): 15 更多

Regulated outputs (#): 4 Step-down DC/DC converter: 2 Step-up DC/DC converter: 0 LDO: 2 Vin (min) (V): 1.8 Vin (max) (V): 6.5 Vout (min) (V): 0.85 Vout (max) (V): 6.5 Iout (max) (A): 1 Configurability: Hardware configurable, Software configurable Features: Power good, Power sequencing Rating: Catalog Operating temperature range (°C): -40 to 85 Step-down DC/DC controller: 0 Step-up DC/DC controller: 0 Iq (typ) (mA): 0.07 Switching frequency (max) (kHz): 1500 Shutdown current (ISD) (typ) (µA): 0.1 Switching frequency (typ) (kHz): 1250 Regulated outputs (#): 4 更多

Output options: Adjustable Output, Fixed Output Iout (max) (A): 0.2 Vin (max) (V): 5.5 Vin (min) (V): 2.7 Vout (max) (V): 5.5 Vout (min) (V): 1.22 Fixed output options (V): 1.8, 2.5, 2.8, 2.85, 3, 3.3, 4.7 Rating: Catalog Noise (µVrms): 33 PSRR at 100 KHz (dB): 43 Iq (typ) (mA): 0.17 Thermal resistance θJA (°C/W): 179 Load capacitance (min) (µF): 2.2 Regulated outputs (#): 1 Features: Enable Accuracy (%): 2 Dropout voltage (Vdo) (typ) (mV): 120 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Fixed Output Iout (max) (A): 0.2 更多

Output options: Fixed Output Iout (max) (A): 1 Vin (max) (V): 10 Vin (min) (V): 2.7 Vout (max) (V): 5 Vout (min) (V): 1.8 Fixed output options (V): 1.8, 2.5, 3.3, 5 Rating: Catalog Noise (µVrms): 80 PSRR at 100 KHz (dB): 50 Iq (typ) (mA): 0.055 Thermal resistance θJA (°C/W): 51, 62 Load capacitance (min) (µF): 1 Regulated outputs (#): 1 Features: Enable, Foldback Overcurrent protection Accuracy (%): 2.5 Dropout voltage (Vdo) (typ) (mV): 450 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 1 更多

Output options: Adjustable Output Iout (max) (A): 1 Vin (max) (V): 10 Vin (min) (V): 2.7 Vout (max) (V): 9 Vout (min) (V): 1.25 Rating: Catalog Noise (µVrms): 80 PSRR at 100 KHz (dB): 45 Iq (typ) (mA): 0.055 Thermal resistance θJA (°C/W): 51 Load capacitance (min) (µF): 1 Regulated outputs (#): 1 Accuracy (%): 1.5 Dropout voltage (Vdo) (typ) (mV): 450 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output Iout (max) (A): 1 Vin (max) (V): 10 Vin (min) (V): 2.7 更多

Output options: Fixed Output Iout (max) (A): 1 Vin (max) (V): 10 Vin (min) (V): 2.7 Vout (max) (V): 5 Vout (min) (V): 1.8 Fixed output options (V): 1.8, 2.5, 3.3, 5 Rating: Catalog Noise (µVrms): 80 PSRR at 100 KHz (dB): 50 Iq (typ) (mA): 0.055 Thermal resistance θJA (°C/W): 51, 69 Load capacitance (min) (µF): 1 Regulated outputs (#): 1 Features: Enable, Foldback Overcurrent protection Accuracy (%): 2.5 Dropout voltage (Vdo) (typ) (mV): 450 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 1 更多

Output options: Adjustable Output Iout (max) (A): 1 Vin (max) (V): 10 Vin (min) (V): 2.7 Vout (max) (V): 9 Vout (min) (V): 1.25 Rating: Catalog Noise (µVrms): 80 PSRR at 100 KHz (dB): 45 Iq (typ) (mA): 0.055 Thermal resistance θJA (°C/W): 51 Load capacitance (min) (µF): 1 Regulated outputs (#): 1 Accuracy (%): 1.4 Dropout voltage (Vdo) (typ) (mV): 250 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output Iout (max) (A): 1 Vin (max) (V): 10 Vin (min) (V): 2.7 更多

Vin (min) (V): 3 Vin (max) (V): 6 Vout (max) (V): 6 Features: Status Pin Rating: Automotive Operating temperature range (°C): -40 to 125 Iq (typ) (mA): 8.4 Product type: DDR DDR memory type: DDR, DDR2, DDR3 Vin (min) (V): 3 Vin (max) (V): 6 Vout (max) (V): 6 Features: Status Pin Rating: Automotive Operating temperature range (°C): -40 to 125 Iq (typ) (mA): 8.4 Product type: DDR DDR memory type: DDR, DDR2, DDR3
