Output options: Fixed Output Iout (max) (A): 0.1 Vin (max) (V): 10 Vin (min) (V): 2.7 Vout (max) (V): 3 Vout (min) (V): 1.5 Fixed output options (V): 1.5, 1.8, 2.5, 2.8, 3 Rating: Catalog Noise (µVrms): 56 PSRR at 100 KHz (dB): 31 Iq (typ) (mA): 0.017 Thermal resistance θJA (°C/W): 180 Load capacitance (min) (µF): 4.7 Regulated outputs (#): 1 Features: Enable, Soft start Accuracy (%): 3 Dropout voltage (Vdo) (typ) (mV): 115 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 0.1 更多

Output options: Fixed Output Iout (max) (A): 0.05 Vin (max) (V): 10 Vin (min) (V): 2.7 Vout (max) (V): 3 Vout (min) (V): 1.5 Fixed output options (V): 1.5, 1.8, 2.5, 2.8, 3 Rating: Catalog Noise (µVrms): 56 PSRR at 100 KHz (dB): 35 Iq (typ) (mA): 0.017 Thermal resistance θJA (°C/W): 180 Load capacitance (min) (µF): 4.7 Regulated outputs (#): 1 Features: Enable, Soft start Accuracy (%): 3 Dropout voltage (Vdo) (typ) (mV): 57 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 0.05 更多

Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 1 Vin (max) (V): 6 Vin (min) (V): 2.7 Vout (max) (V): 5.5 Vout (min) (V): 1.2 Fixed output options (V): 1.2, 1.5, 1.8, 2.5, 3.3 Rating: Catalog Noise (µVrms): 78 PSRR at 100 KHz (dB): 22 Iq (typ) (mA): 0.185 Thermal resistance θJA (°C/W): 30.9, 32 Load capacitance (min) (µF): 22 Regulated outputs (#): 2 Features: Enable, Output discharge, Power good, Sequencing and monitoring Accuracy (%): 2 Dropout voltage (Vdo) (typ) (mV): 160 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 1 更多

Output options: Adjustable Output, Fixed Output Iout (max) (A): 1 Vin (max) (V): 15 Vin (min) (V): 2.5 Vout (max) (V): 13.75 Vout (min) (V): 1.5 Fixed output options (V): 1.8, 3.3 Rating: Catalog Noise (µVrms): 412.5 PSRR at 100 KHz (dB): 37 Iq (typ) (mA): 5 Thermal resistance θJA (°C/W): 56, 62 Load capacitance (min) (µF): 10 Regulated outputs (#): 1 Accuracy (%): 3 Dropout voltage (Vdo) (typ) (mV): 1200 Operating temperature range (°C): 0 to 125 Output options: Adjustable Output, Fixed Output Iout (max) (A): 1 Vin (max) (V): 15 更多

Output options: Adjustable Output, Fixed Output Iout (max) (A): 0.15 Vin (max) (V): 10 Vin (min) (V): 2.7 Vout (max) (V): 5.5 Vout (min) (V): 1.5 Fixed output options (V): 1.5, 1.8, 2.7, 3.3, 5 Rating: Catalog Noise (µVrms): 55 PSRR at 100 KHz (dB): 26 Iq (typ) (mA): 0.09 Thermal resistance θJA (°C/W): 243 Load capacitance (min) (µF): 1 Regulated outputs (#): 1 Features: Enable, Power good Accuracy (%): 2 Dropout voltage (Vdo) (typ) (mV): 75 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Fixed Output Iout (max) (A): 0.15 更多

Output options: Adjustable Output, Fixed Output Iout (max) (A): 0.25 Vin (max) (V): 10 Vin (min) (V): 2.7 Vout (max) (V): 5.5 Vout (min) (V): 1.5 Fixed output options (V): 1.5, 1.8, 2.8, 3.3, 5 Rating: Catalog Noise (µVrms): 55 PSRR at 100 KHz (dB): 25 Iq (typ) (mA): 0.09 Thermal resistance θJA (°C/W): 243 Load capacitance (min) (µF): 1 Regulated outputs (#): 1 Features: Enable, Power good Accuracy (%): 2 Dropout voltage (Vdo) (typ) (mV): 200 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Fixed Output Iout (max) (A): 0.25 更多

Output options: Dual output, Fixed Output Iout (max) (A): 0.3 Vin (max) (V): 6 Vin (min) (V): 2.5 Vout (max) (V): 2.85 Vout (min) (V): 2.5 Fixed output options (V): 1.8, 2.5, 2.8, 2.85, 3 Rating: Catalog Noise (µVrms): 40 PSRR at 100 KHz (dB): 35 Iq (typ) (mA): 0.115 Thermal resistance θJA (°C/W): 220 Load capacitance (min) (µF): 1 Regulated outputs (#): 2 Features: Enable Accuracy (%): 3 Dropout voltage (Vdo) (typ) (mV): 60 Operating temperature range (°C): -40 to 125 Output options: Dual output, Fixed Output Iout (max) (A): 0.3 更多

Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 0.5 Vin (max) (V): 6 Vin (min) (V): 2.7 Vout (max) (V): 5.5 Vout (min) (V): 1.2 Fixed output options (V): 1.2, 1.5, 1.8, 2.5, 3.3 Rating: Catalog Noise (µVrms): 65 PSRR at 100 KHz (dB): 20 Iq (typ) (mA): 0.19 Thermal resistance θJA (°C/W): 32 Load capacitance (min) (µF): 6.8 Regulated outputs (#): 2 Features: Enable, Output discharge, Power good Accuracy (%): 2 Dropout voltage (Vdo) (typ) (mV): 170 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 0.5 更多

Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 0.25 Vin (max) (V): 6 Vin (min) (V): 2.7 Vout (max) (V): 5.5 Vout (min) (V): 1.2 Fixed output options (V): 1.2, 1.5, 1.8, 2.5, 3.3 Rating: Catalog Noise (µVrms): 65 PSRR at 100 KHz (dB): 20 Iq (typ) (mA): 0.19 Thermal resistance θJA (°C/W): 32 Load capacitance (min) (µF): 10 Regulated outputs (#): 2 Features: Enable, Output discharge, Power good Accuracy (%): 2 Dropout voltage (Vdo) (typ) (mV): 83 Operating temperature range (°C): -40 to 125 Output options: Adjustable Output, Dual output, Fixed Output Iout (max) (A): 0.25 更多

Output options: Fixed Output Iout (max) (A): 0.5 Vin (max) (V): 16 Vin (min) (V): 2.1 Vout (max) (V): 1.8 Vout (min) (V): 1.8 Fixed output options (V): 1.8 Rating: Catalog Noise (µVrms): 18 PSRR at 100 KHz (dB): 32 Iq (typ) (mA): 0.11 Thermal resistance θJA (°C/W): 114 Load capacitance (min) (µF): 10 Regulated outputs (#): 1 Features: Enable, Power good Accuracy (%): 1.6 Dropout voltage (Vdo) (typ) (mV): 160 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 0.5 更多
