Output options: Fixed Output Iout (max) (A): 0.1 Vin (max) (V): 30 Vin (min) (V): 4.75 Vout (max) (V): 15 Vout (min) (V): 2.6 Fixed output options (V): 2.6, 3.3, 5, 6.2, 8, 9, 10, 12, 15 Rating: Catalog Noise (µVrms): 42 PSRR at 100 KHz (dB): 40 Iq (typ) (mA): 3.8 Thermal resistance θJA (°C/W): 55 Load capacitance (min) (µF): 0.1 Regulated outputs (#): 1 Accuracy (%): 3.75 Dropout voltage (Vdo) (typ) (mV): 1700 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 0.1 Vin (max) (V): 30 更多

Output options: Fixed Output Iout (max) (A): 0.05 Vin (max) (V): 60 Vin (min) (V): 5.5 Vout (max) (V): 5 Vout (min) (V): 3 Fixed output options (V): 3, 3.3, 5 Rating: Catalog Noise (µVrms): 500 PSRR at 100 KHz (dB): 35 Iq (typ) (mA): 0.015 Thermal resistance θJA (°C/W): 51 Load capacitance (min) (µF): 10 Regulated outputs (#): 1 Features: Reverse voltage protection Accuracy (%): 3 Dropout voltage (Vdo) (typ) (mV): 200 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 0.05 更多

Output options: Fixed Output Iout (max) (A): 0.05 Vin (max) (V): 40 Vin (min) (V): 4 Vout (max) (V): 5 Vout (min) (V): 3.3 Fixed output options (V): 3.3, 5 Rating: Catalog Iq (typ) (mA): 0.02 Thermal resistance θJA (°C/W): 50 Load capacitance (min) (µF): 22 Regulated outputs (#): 1 Accuracy (%): 3 Dropout voltage (Vdo) (typ) (mV): 200 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 0.05 Vin (max) (V): 40 Vin (min) (V): 4 Vout (max) (V): 5 更多

Output options: Adjustable Output Iout (max) (A): 1 Vin (max) (V): 26 Vin (min) (V): -15 Vout (max) (V): 20 Vout (min) (V): 5 Rating: Catalog Noise (µVrms): 38 PSRR at 100 KHz (dB): 67 Iq (typ) (mA): 10 Thermal resistance θJA (°C/W): 32, 41 Load capacitance (min) (µF): 22 Regulated outputs (#): 1 Features: Enable Accuracy (%): 2.8 Dropout voltage (Vdo) (typ) (mV): 500 Operating temperature range (°C): 0 to 125 Output options: Adjustable Output Iout (max) (A): 1 Vin (max) (V): 26 更多

Output options: Fixed Output Iout (max) (A): 1 Vin (max) (V): 26 Vin (min) (V): 6 Vout (max) (V): 15 Vout (min) (V): 5 Fixed output options (V): 5, 8, 9, 10, 12, 15 Rating: Catalog Noise (µVrms): 150 PSRR at 100 KHz (dB): 48 Iq (typ) (mA): 10 Thermal resistance θJA (°C/W): 23, 41, 59 Load capacitance (min) (µF): 22 Regulated outputs (#): 1 Accuracy (%): 2 Dropout voltage (Vdo) (typ) (mV): 500 Operating temperature range (°C): -40 to 125 Output options: Fixed Output Iout (max) (A): 1 Vin (max) (V): 26 更多

Output options: Fixed Output Iout (max) (A): 1 Vin (max) (V): 26 Vin (min) (V): 6 Vout (max) (V): 15 Vout (min) (V): 5 Fixed output options (V): 5, 9, 12, 15 Rating: Catalog Noise (µVrms): 150 PSRR at 100 KHz (dB): 54 Iq (typ) (mA): 10 Thermal resistance θJA (°C/W): 23, 41 Load capacitance (min) (µF): 22 Regulated outputs (#): 1 Accuracy (%): 5 Dropout voltage (Vdo) (typ) (mV): 500 Operating temperature range (°C): 0 to 125 Output options: Fixed Output Iout (max) (A): 1 Vin (max) (V): 26 更多

Output options: Adjustable Output Iout (max) (A): 5 Vin (max) (V): 40 Vin (min) (V): 4.2 Vout (max) (V): 32 Vout (min) (V): 1.24 Rating: Catalog Noise (µVrms): 37 PSRR at 100 KHz (dB): 10 Iq (typ) (mA): 0.045 Thermal resistance θJA (°C/W): 23 Load capacitance (min) (µF): 0 Regulated outputs (#): 1 Accuracy (%): 2.4 Dropout voltage (Vdo) (typ) (mV): 2700 Operating temperature range (°C): 0 to 125 Output options: Adjustable Output Iout (max) (A): 5 Vin (max) (V): 40 Vin (min) (V): 4.2 更多

Output options: Fixed Output Iout (max) (A): 1 Vin (max) (V): 35 Vin (min) (V): 7.1 Vout (max) (V): 5 Vout (min) (V): 5 Fixed output options (V): 5 Rating: Military Noise (µVrms): 40 PSRR at 100 KHz (dB): 64 Iq (typ) (mA): 5.2 Thermal resistance θJA (°C/W): 35 Load capacitance (min) (µF): 0 Regulated outputs (#): 1 Accuracy (%): 4 Dropout voltage (Vdo) (typ) (mV): 3000 Operating temperature range (°C): -55 to 150 Output options: Fixed Output Iout (max) (A): 1 Vin (max) (V): 35 更多

Output options: Adjustable Output Iout (max) (A): 1.5 Vin (max) (V): 40 Vin (min) (V): 4.2 Vout (max) (V): 37 Vout (min) (V): 1.25 Rating: Military Noise (µVrms): 75 PSRR at 100 KHz (dB): 40 Iq (typ) (mA): 5 Thermal resistance θJA (°C/W): 39 Load capacitance (min) (µF): 0 Regulated outputs (#): 1 Accuracy (%): 4 Dropout voltage (Vdo) (typ) (mV): 1200 Operating temperature range (°C): -55 to 150 Output options: Adjustable Output Iout (max) (A): 1.5 Vin (max) (V): 40 Vin (min) (V): 4.2 更多

Output options: Adjustable Output Iout (max) (A): 1.5 Vin (max) (V): 40 Vin (min) (V): 4.2 Vout (max) (V): 37 Vout (min) (V): 1.25 Fixed output options (V): 0 Rating: Military Noise (µVrms): 75 PSRR at 100 KHz (dB): 40 Iq (typ) (mA): 5 Thermal resistance θJA (°C/W): 39 Load capacitance (min) (µF): 0 Regulated outputs (#): 1 Accuracy (%): 4 Dropout voltage (Vdo) (typ) (mV): 1200 Operating temperature range (°C): -55 to 125 Output options: Adjustable Output Iout (max) (A): 1.5 Vin (max) (V): 40 更多
