VO (V): 1.225 Initial accuracy (max) (%): 0.2 VO adj (min) (V): 1.225 VO adj (max) (V): 10 Iz for regulation (min) (µA): 36 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 20 VO (V): 1.225 Initial accuracy (max) (%): 0.2 VO adj (min) (V): 1.225 VO adj (max) (V): 10 Iz for regulation (min) (µA): 36 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 20

VO (V): 1.225 Initial accuracy (max) (%): 0.5 VO adj (min) (V): 1.225 VO adj (max) (V): 10 Iz for regulation (min) (µA): 36 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 20 VO (V): 1.225 Initial accuracy (max) (%): 0.5 VO adj (min) (V): 1.225 VO adj (max) (V): 10 Iz for regulation (min) (µA): 36 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 20

VO (V): 1.8, 2.048, 2.5, 3, 3.3, 4.1 Initial accuracy (max) (%): 0.1, 0.2, 0.5, 1 Temp coeff (max) (ppm/°C): 75, 100 Vin (min) (V): 2.2 Vin (max) (V): 5.5 Iq (typ) (mA): 0.06 Rating: Catalog Features: Enable pin LFN 0.1 to 10 Hz (typ) (µVPP): 170 Iout/Iz (max) (mA): 20 Operating temperature range (°C): -40 to 125 Shutdown current (ISD) (typ) (µA): 3 VO (V): 1.8, 2.048, 2.5, 3, 3.3, 4.1 Initial accuracy (max) (%): 0.1, 0.2, 0.5, 1 Temp coeff (max) (ppm/°C): 75, 100 Vin (min) (V): 2.2 Vin (max) (V): 5.5 Iq (typ) (mA): 0.06 Rating: Catalog Features: Enable pin 更多

VO (V): 2.5, 4.096 Initial accuracy (max) (%): 0.05, 0.1, 0.15 VO adj (min) (V): 2.5 VO adj (max) (V): 4.096 Iz for regulation (min) (µA): 120 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 10, 20, 30 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 30 VO (V): 2.5, 4.096 Initial accuracy (max) (%): 0.05, 0.1, 0.15 VO adj (min) (V): 2.5 VO adj (max) (V): 4.096 Iz for regulation (min) (µA): 120 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 10, 20, 30 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 30

VO (V): 2.495 Initial accuracy (max) (%): 0.5, 1 VO adj (min) (V): 2.495 VO adj (max) (V): 36 Iz for regulation (min) (µA): 400 Reference voltage (V): adjustable Rating: Automotive TI functional safety category: Functional Safety-Capable Temp coeff (max) (ppm/°C): 92 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 100 VO (V): 2.495 Initial accuracy (max) (%): 0.5, 1 VO adj (min) (V): 2.495 VO adj (max) (V): 36 Iz for regulation (min) (µA): 400 Reference voltage (V): adjustable Rating: Automotive TI functional safety category: Functional Safety-Capable Temp coeff (max) (ppm/°C): 92 更多

VO (V): 1.24 Initial accuracy (max) (%): 1 VO adj (min) (V): 1.24 VO adj (max) (V): 5.3 Iz for regulation (min) (µA): 10 Reference voltage (V): adjustable Rating: Military Operating temperature range (°C): -55 to 125 Iout/Iz (max) (mA): 20 VO (V): 1.24 Initial accuracy (max) (%): 1 VO adj (min) (V): 1.24 VO adj (max) (V): 5.3 Iz for regulation (min) (µA): 10 Reference voltage (V): adjustable Rating: Military Operating temperature range (°C): -55 to 125 Iout/Iz (max) (mA): 20

VO (V): 1.225 Initial accuracy (max) (%): 0.1 VO adj (min) (V): 1.225 VO adj (max) (V): 1.225 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 100 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 25 VO (V): 1.225 Initial accuracy (max) (%): 0.1 VO adj (min) (V): 1.225 VO adj (max) (V): 1.225 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 100 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 25

VO (V): 1.225 Initial accuracy (max) (%): 0.2 VO adj (min) (V): 1.225 VO adj (max) (V): 1.225 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 100 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 25 VO (V): 1.225 Initial accuracy (max) (%): 0.2 VO adj (min) (V): 1.225 VO adj (max) (V): 1.225 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 100 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 25

VO (V): 1.225 Initial accuracy (max) (%): 0.2 VO adj (min) (V): 1.225 VO adj (max) (V): 10 Iz for regulation (min) (µA): 45 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 100 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 25 VO (V): 1.225 Initial accuracy (max) (%): 0.2 VO adj (min) (V): 1.225 VO adj (max) (V): 10 Iz for regulation (min) (µA): 45 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 100 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 25

VO (V): 1.225 Initial accuracy (max) (%): 0.5 VO adj (min) (V): 1.225 VO adj (max) (V): 1.225 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 100 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 25 VO (V): 1.225 Initial accuracy (max) (%): 0.5 VO adj (min) (V): 1.225 VO adj (max) (V): 1.225 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 100 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 25
