TS5A22364
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有负信号处理功能的 0.65Ω、5V、2:1 (SPDT) 2 通道模拟开关
Protocols: Analog Audio
Configuration: 2:1 SPDT
Number of channels: 2
Bandwidth (MHz): 18.3
Supply voltage (max) (V): 5.5
Supply voltage (min) (V): 2.3
Ron (typ) (mΩ): 520
Input/output voltage (min) (V): -3.2
Input/output voltage (max) (V): 5.5
Supply current (typ) (µA): 0.2
ESD HBM (typ) (kV): 1.5
Operating temperature range (°C): -40 to 85
Crosstalk (dB): -78
ESD CDM (kV): 1.5
Input/output continuous current (max) (mA): 350
CON (typ) (pF): 370
Off isolation (typ) (dB): -70
Ron (max) (mΩ): 1300
Ron channel match (max) (Ω): 0.3
RON flatness (typ) (Ω): 0.076
更多
Turnoff time (disable) (max) (ns): 70
Turnon time (enable) (max) (ns): 120
VIH (min) (V): 1.4
VIL (max) (V): 0.8
Protocols: Analog Audio
Configuration: 2:1 SPDT
Number of channels: 2
Bandwidth (MHz): 18.3
Supply voltage (max) (V): 5.5
Supply voltage (min) (V): 2.3
Ron (typ) (mΩ): 520
Input/output voltage (min) (V): -3.2
Input/output voltage (max) (V): 5.5
Supply current (typ) (µA): 0.2
ESD HBM (typ) (kV): 1.5
Operating temperature range (°C): -40 to 85
Crosstalk (dB): -78
ESD CDM (kV): 1.5
Input/output continuous current (max) (mA): 350
CON (typ) (pF): 370
Off isolation (typ) (dB): -70
Ron (max) (mΩ): 1300
Ron channel match (max) (Ω): 0.3
RON flatness (typ) (Ω): 0.076
Turnoff time (disable) (max) (ns): 70
Turnon time (enable) (max) (ns): 120
VIH (min) (V): 1.4
VIL (max) (V): 0.8
Configuration: 3:1
Number of channels: 2
Power supply voltage - single (V): 2.5, 3.3, 5
Protocols: Analog, I2C, I3C, LVDS, UART
Ron (typ) (Ω): 5.5
CON (typ) (pF): 1
ON-state leakage current (max) (µA): 2
Supply current (typ) (µA): 28
Bandwidth (MHz): 6500
Operating temperature range (°C): -40 to 85
Features: 1.8-V compatible control inputs, Powered-off protection
Input/output continuous current (max) (mA): 60
Rating: Catalog
Supply voltage (max) (V): 4.3
Configuration: 3:1
Number of channels: 2
Power supply voltage - single (V): 2.5, 3.3, 5
Protocols: Analog, I2C, I3C, LVDS, UART
Ron (typ) (Ω): 5.5
CON (typ) (pF): 1
更多
ON-state leakage current (max) (µA): 2
Supply current (typ) (µA): 28
Bandwidth (MHz): 6500
Operating temperature range (°C): -40 to 85
Features: 1.8-V compatible control inputs, Powered-off protection
Input/output continuous current (max) (mA): 60
Rating: Catalog
Supply voltage (max) (V): 4.3
TMUX121
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有 1.8V 兼容逻辑的 2pF、3.3V、2:1 (SPDT)、2 通道开关
Configuration: 2:1 SPDT
Number of channels: 2
Power supply voltage - single (V): 3.3
Protocols: Analog, I2C, I3C, LVDS, UART
Ron (typ) (Ω): 3
CON (typ) (pF): 1.7
ON-state leakage current (max) (µA): 2
Supply current (typ) (µA): 11
Bandwidth (MHz): 3300
Operating temperature range (°C): -40 to 125
Features: 1.8-V compatible control inputs, Powered-off protection
Input/output continuous current (max) (mA): 100
Rating: Catalog
Supply voltage (max) (V): 3.6
Configuration: 2:1 SPDT
Number of channels: 2
Power supply voltage - single (V): 3.3
Protocols: Analog, I2C, I3C, LVDS, UART
Ron (typ) (Ω): 3
CON (typ) (pF): 1.7
更多
ON-state leakage current (max) (µA): 2
Supply current (typ) (µA): 11
Bandwidth (MHz): 3300
Operating temperature range (°C): -40 to 125
Features: 1.8-V compatible control inputs, Powered-off protection
Input/output continuous current (max) (mA): 100
Rating: Catalog
Supply voltage (max) (V): 3.6
TMUX646
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 支持 1.8V 逻辑电平的 6GHz、5V、2:1 (SPDT) 10 通道 MIPI 开关
Protocols: MIPI
Configuration: 2:1 SPDT
Number of channels: 10
Bandwidth (MHz): 6000
Supply voltage (max) (V): 5.5
Supply voltage (min) (V): 1.5
Ron (typ) (mΩ): 6000
Input/output voltage (min) (V): 0
Input/output voltage (max) (V): 3.6
Supply current (typ) (µA): 0.1
ESD HBM (typ) (kV): 6
Operating temperature range (°C): -40 to 85
Crosstalk (dB): -40
ESD CDM (kV): 2
Input/output continuous current (max) (mA): 35
COFF (typ) (pF): 1.5
CON (typ) (pF): 1.5
Off isolation (typ) (dB): -20
OFF-state leakage current (max) (µA): 0.5
Propagation delay time (µs): 0.04
更多
Ron (max) (mΩ): 10000
RON flatness (typ) (Ω): 0.1
VIH (min) (V): 1
VIL (max) (V): 0.4
Protocols: MIPI
Configuration: 2:1 SPDT
Number of channels: 10
Bandwidth (MHz): 6000
Supply voltage (max) (V): 5.5
Supply voltage (min) (V): 1.5
Ron (typ) (mΩ): 6000
Input/output voltage (min) (V): 0
Input/output voltage (max) (V): 3.6
Supply current (typ) (µA): 0.1
ESD HBM (typ) (kV): 6
Operating temperature range (°C): -40 to 85
Crosstalk (dB): -40
ESD CDM (kV): 2
Input/output continuous current (max) (mA): 35
COFF (typ) (pF): 1.5
CON (typ) (pF): 1.5
Off isolation (typ) (dB): -20
OFF-state leakage current (max) (µA): 0.5
Propagation delay time (µs): 0.04
Ron (max) (mΩ): 10000
RON flatness (typ) (Ω): 0.1
VIH (min) (V): 1
VIL (max) (V): 0.4
TMUX1574
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有断电保护功能和 1.8V 输入逻辑的 5V、2:1 (SPDT)、4 通道模拟开关
Configuration: 2:1 SPDT
Number of channels: 4
Power supply voltage - single (V): 1.8, 2.5, 3.3, 5
Protocols: Analog, I2C, I2S, I3C, JTAG, MIPI, RGMII, SPI, TDM, UART
Ron (typ) (Ω): 2
CON (typ) (pF): 7.5
ON-state leakage current (max) (µA): 0.05
Supply current (typ) (µA): 40
Bandwidth (MHz): 2000
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 25
Rating: Catalog
Drain supply voltage (max) (V): 5.5
Supply voltage (max) (V): 5.5
Configuration: 2:1 SPDT
Number of channels: 4
Power supply voltage - single (V): 1.8, 2.5, 3.3, 5
Protocols: Analog, I2C, I2S, I3C, JTAG, MIPI, RGMII, SPI, TDM, UART
Ron (typ) (Ω): 2
CON (typ) (pF): 7.5
更多
ON-state leakage current (max) (µA): 0.05
Supply current (typ) (µA): 40
Bandwidth (MHz): 2000
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 25
Rating: Catalog
Drain supply voltage (max) (V): 5.5
Supply voltage (max) (V): 5.5
TMUX154E
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有断电保护功能的 7.5pF 导通状态电容、3.3V、2:1 (SPDT)、2 通道模拟开关
Configuration: 2:1 SPDT
Number of channels: 2
Power supply voltage - single (V): 3.3
Protocols: Analog, I2C, I3C, LVDS, UART
Ron (typ) (Ω): 6
CON (typ) (pF): 7.5
ON-state leakage current (max) (µA): 1
Bandwidth (MHz): 900
Operating temperature range (°C): -40 to 85
Input/output continuous current (max) (mA): 64
Rating: Catalog
Drain supply voltage (max) (V): 4.3
Supply voltage (max) (V): 4.3
Configuration: 2:1 SPDT
Number of channels: 2
Power supply voltage - single (V): 3.3
Protocols: Analog, I2C, I3C, LVDS, UART
Ron (typ) (Ω): 6
CON (typ) (pF): 7.5
ON-state leakage current (max) (µA): 1
更多
Bandwidth (MHz): 900
Operating temperature range (°C): -40 to 85
Input/output continuous current (max) (mA): 64
Rating: Catalog
Drain supply voltage (max) (V): 4.3
Supply voltage (max) (V): 4.3
TS5MP645
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有断电保护和 1.8V 逻辑的 1.5pF、5V、2:1 (SPDT)、10 通道 MIPI 模拟开关
Protocols: C-PHY, CSI, D-PHY, DSI, MIPI
Configuration: 2:1 SPDT
Number of channels: 10
Bandwidth (MHz): 1500
Supply voltage (max) (V): 5.5
Supply voltage (min) (V): 1.65
Ron (typ) (mΩ): 2450
Input/output voltage (min) (V): 0
Input/output voltage (max) (V): 3.6
Supply current (typ) (µA): 30
ESD HBM (typ) (kV): 2
Operating temperature range (°C): -40 to 85
Crosstalk (dB): -40
ESD CDM (kV): 0.25
Input/output continuous current (max) (mA): 35
COFF (typ) (pF): 1.5
CON (typ) (pF): 1.5
Off isolation (typ) (dB): -20
OFF-state leakage current (max) (µA): 0.5
Propagation delay time (µs): 0.000004
更多
Ron (max) (mΩ): 6500
Ron channel match (max) (Ω): 0.1
RON flatness (typ) (Ω): 0.1
Turnoff time (disable) (max) (ns): 1000
Turnon time (enable) (max) (ns): 300000
VIH (min) (V): 1.425
VIL (max) (V): 0.5
Protocols: C-PHY, CSI, D-PHY, DSI, MIPI
Configuration: 2:1 SPDT
Number of channels: 10
Bandwidth (MHz): 1500
Supply voltage (max) (V): 5.5
Supply voltage (min) (V): 1.65
Ron (typ) (mΩ): 2450
Input/output voltage (min) (V): 0
Input/output voltage (max) (V): 3.6
Supply current (typ) (µA): 30
ESD HBM (typ) (kV): 2
Operating temperature range (°C): -40 to 85
Crosstalk (dB): -40
ESD CDM (kV): 0.25
Input/output continuous current (max) (mA): 35
COFF (typ) (pF): 1.5
CON (typ) (pF): 1.5
Off isolation (typ) (dB): -20
OFF-state leakage current (max) (µA): 0.5
Propagation delay time (µs): 0.000004
Ron (max) (mΩ): 6500
Ron channel match (max) (Ω): 0.1
RON flatness (typ) (Ω): 0.1
Turnoff time (disable) (max) (ns): 1000
Turnon time (enable) (max) (ns): 300000
VIH (min) (V): 1.425
VIL (max) (V): 0.5
TMUX136
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有断电保护功能的 1.4pF 导通状态电容、5V、2:1 (SPDT)、2 通道模拟开关
Configuration: 2:1 SPDT
Number of channels: 2
Power supply voltage - single (V): 2.5, 3.3
Protocols: Analog, I2C, I3C, LVDS, UART
Ron (typ) (Ω): 4.6
CON (typ) (pF): 1.4
ON-state leakage current (max) (µA): 2
Supply current (typ) (µA): 30
Bandwidth (MHz): 6100
Operating temperature range (°C): -40 to 125
Features: 1.8-V compatible control inputs, Powered-off protection
Input/output continuous current (max) (mA): 20
Rating: Catalog
Drain supply voltage (max) (V): 4.8
Supply voltage (max) (V): 4.8
Configuration: 2:1 SPDT
Number of channels: 2
Power supply voltage - single (V): 2.5, 3.3
Protocols: Analog, I2C, I3C, LVDS, UART
Ron (typ) (Ω): 4.6
更多
CON (typ) (pF): 1.4
ON-state leakage current (max) (µA): 2
Supply current (typ) (µA): 30
Bandwidth (MHz): 6100
Operating temperature range (°C): -40 to 125
Features: 1.8-V compatible control inputs, Powered-off protection
Input/output continuous current (max) (mA): 20
Rating: Catalog
Drain supply voltage (max) (V): 4.8
Supply voltage (max) (V): 4.8
状态: 已停产
Compliance: Pb A H P
Channels: 2
Number of Switches: 2
Configuration: SPST
Icc Max (µA): 1
ron Max (Ω): 6
VCC Min (V): 4
VCC Max (V): 5.5
Package Type: UDFN-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: No
参考价格: Price N/A
状态: 已停产
Compliance: Pb A H P
Channels: 2
Number of Switches: 2
Configuration: SPST
Icc Max (µA): 1
ron Max (Ω): 6
VCC Min (V): 4
VCC Max (V): 5.5
Package Type: UDFN-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: No
参考价格: Price N/A
