Protocols: PCI/PCIe Number of channels: 2 Supply voltage (max) (V): 13.5 Supply voltage (min) (V): 3 Operating temperature range (°C): -40 to 85 Protocols: PCI/PCIe Number of channels: 2 Supply voltage (max) (V): 13.5 Supply voltage (min) (V): 3 Operating temperature range (°C): -40 to 85

Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Power supply voltage - dual (V): +/-2.5, +/-5 Protocols: Analog Ron (typ) (Ω): 40 CON (typ) (pF): 25 ON-state leakage current (max) (µA): 4 Supply current (typ) (µA): 8 Bandwidth (MHz): 180 Operating temperature range (°C): -55 to 125 Features: Break-before-make Input/output continuous current (max) (mA): 25 Rating: Military Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 10 Negative rail supply voltage (max) (V): 0 Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 更多

Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Power supply voltage - dual (V): +/-2.5, +/-5 Protocols: Analog Ron (typ) (Ω): 40 CON (typ) (pF): 25 ON-state leakage current (max) (µA): 2 Supply current (typ) (µA): 8 Bandwidth (MHz): 180 Operating temperature range (°C): -55 to 125 Features: Break-before-make Input/output continuous current (max) (mA): 25 Rating: Military Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 10 Negative rail supply voltage (max) (V): 0 Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 更多

Configuration: 2:1 SPDT Number of channels: 3 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Power supply voltage - dual (V): +/-2.5, +/-5 Protocols: Analog Ron (typ) (Ω): 40 CON (typ) (pF): 25 ON-state leakage current (max) (µA): 1 Supply current (typ) (µA): 8 Bandwidth (MHz): 180 Operating temperature range (°C): -55 to 125 Features: Break-before-make Input/output continuous current (max) (mA): 25 Rating: Military Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 10 Negative rail supply voltage (max) (V): 0 Configuration: 2:1 SPDT Number of channels: 3 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 更多

Configuration: 1:1 SPST Number of channels: 4 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 16 CON (typ) (pF): 5 Supply current (typ) (µA): 2 Bandwidth (MHz): 200 Operating temperature range (°C): -55 to 125 Input/output continuous current (max) (mA): 25 Rating: Military Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 4 Configuration: 1:1 SPST Number of channels: 4 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 16 CON (typ) (pF): 5 Supply current (typ) (µA): 2 更多

Configuration: 1:1 SPST Number of channels: 4 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 35 CON (typ) (pF): 5 Supply current (typ) (µA): 16 Bandwidth (MHz): 200 Operating temperature range (°C): -55 to 125 Features: Break-before-make Input/output continuous current (max) (mA): 25 Rating: Military Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 4 Configuration: 1:1 SPST Number of channels: 4 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 35 CON (typ) (pF): 5 更多

Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Power supply voltage - dual (V): +/-2.5, +/-5 Protocols: Analog Ron (typ) (Ω): 40 CON (typ) (pF): 25 ON-state leakage current (max) (µA): 4 Supply current (typ) (µA): 16 Bandwidth (MHz): 180 Operating temperature range (°C): -55 to 125 Features: Break-before-make Input/output continuous current (max) (mA): 25 Rating: Military Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 10 Negative rail supply voltage (max) (V): 0 Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 更多

Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 5 Power supply voltage - dual (V): +/-2.5, +/-5 Protocols: Analog Ron (typ) (Ω): 40 CON (typ) (pF): 25 ON-state leakage current (max) (µA): 1 Supply current (typ) (µA): 8 Bandwidth (MHz): 180 Operating temperature range (°C): -55 to 125 Features: Break-before-make Input/output continuous current (max) (mA): 25 Rating: Military Drain supply voltage (max) (V): 5.5 Supply voltage (max) (V): 10 Negative rail supply voltage (max) (V): 0 Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 5 更多

Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Power supply voltage - dual (V): +/-2.5, +/-5 Protocols: Analog Ron (typ) (Ω): 45 CON (typ) (pF): 12 ON-state leakage current (max) (µA): 2 Bandwidth (MHz): 185 Operating temperature range (°C): -55 to 125 Features: Break-before-make Input/output continuous current (max) (mA): 25 Rating: Catalog Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 10 Negative rail supply voltage (max) (V): 0 Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Power supply voltage - dual (V): +/-2.5, +/-5 更多

状态: 已停产 Compliance: Pb A H P Channels: 2 Number of Switches: 2 Configuration: DPDT Icc Max (µA): 1 ron Max (Ω): 7 VCC Min (V): 3 VCC Max (V): 3.6 Package Type: MSOP-10 MSL Type: 1 MSL Temp (°C): 260 ON Target: No 参考价格: Price N/A
