UC3825
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 脉宽调制电路
描述: 具有 9.2V/8.4V UVLO 和 85% 占空比、温度范围为 0°C 至 70°C 的增强型 30V、1.5A 双端 PWM 控制器
Vin (max) (V): 12
Operating temperature range (°C): 0 to 70
Control mode: Current, Feedforward, Voltage
Topology: Boost, Flyback, Forward, Half bridge, Push pull
Rating: Catalog
Duty cycle (max) (%): 85
Vin (max) (V): 12
Operating temperature range (°C): 0 to 70
Control mode: Current, Feedforward, Voltage
Topology: Boost, Flyback, Forward, Half bridge, Push pull
Rating: Catalog
Duty cycle (max) (%): 85
Vin (max) (V): 35
Operating temperature range (°C): -55 to 125
Control mode: Voltage
Topology: Boost, Flyback, Forward, Full bridge, Half bridge, Push pull
Rating: Military
Features: Error amplifier, Multi-topology, Soft start, Synchronization pin
