Number of series cells: 1 Charge current (max) (A): 1 Vin (max) (V): 6.5 TI functional safety category: Functional Safety-Capable Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 4.2 Battery charge voltage (max) (V): 4.2 Absolute max Vin (max) (V): 30 Control topology: Linear Control interface: Standalone (RC-Settable) Vin (min) (V): 3.5 Rating: Catalog Operating temperature range (°C): 0 to 125 Number of series cells: 1 Charge current (max) (A): 1 Vin (max) (V): 6.5 TI functional safety category: Functional Safety-Capable Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 4.2 Battery charge voltage (max) (V): 4.2 更多

Function: Charger Front-End Protection Number of series cells (min): 1 Number of series cells (max): 1 Features: Overcurrent protection, Overvoltage Operating current (typ) (µA): 400 Rating: Catalog Vin (max) (V): 30 Overvoltage protection: 5.85 Operating temperature range (°C): -40 to 125 Battery overvoltage protection (min) (V): 4.35 Battery overvoltage protection (max) (V): 4.35 Function: Charger Front-End Protection Number of series cells (min): 1 Number of series cells (max): 1 Features: Overcurrent protection, Overvoltage Operating current (typ) (µA): 400 Rating: Catalog Vin (max) (V): 30 Overvoltage protection: 5.85 Operating temperature range (°C): -40 to 125 更多

Number of series cells: 2, 3, 4 Charge current (max) (A): 10 Vin (max) (V): 24 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 8 Battery charge voltage (max) (V): 18.048 Absolute max Vin (max) (V): 30 Control topology: Switch-Mode Buck Control interface: Standalone (RC-Settable) Features: Input OVP, Power Path Vin (min) (V): 8 Rating: Catalog Operating temperature range (°C): -40 to 85 Number of series cells: 2, 3, 4 Charge current (max) (A): 10 Vin (max) (V): 24 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 8 Battery charge voltage (max) (V): 18.048 Absolute max Vin (max) (V): 30 更多

Number of series cells: 1, 2, 3 Charge current (max) (A): 2 Vin (max) (V): 16 Cell chemistry: Li-Ion/Li-Polymer, Lithium Phosphate/LiFePO4, NiCd, NiMH Battery charge voltage (min) (V): 2.1 Battery charge voltage (max) (V): 15.5 Absolute max Vin (max) (V): 20 Control topology: Switch-Mode Buck Control interface: Standalone (RC-Settable) Vin (min) (V): 4.35 Rating: Automotive Operating temperature range (°C): -40 to 85 Number of series cells: 1, 2, 3 Charge current (max) (A): 2 Vin (max) (V): 16 Cell chemistry: Li-Ion/Li-Polymer, Lithium Phosphate/LiFePO4, NiCd, NiMH Battery charge voltage (min) (V): 2.1 Battery charge voltage (max) (V): 15.5 Absolute max Vin (max) (V): 20 Control topology: Switch-Mode Buck 更多

Number of series cells: 1 Charge current (max) (A): 1.5 Vin (max) (V): 6.4 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 4.1 Battery charge voltage (max) (V): 4.1 Absolute max Vin (max) (V): 28 Control topology: Linear Control interface: Standalone (RC-Settable) Vin (min) (V): 4.35 Rating: Catalog Operating temperature range (°C): -40 to 85 Number of series cells: 1 Charge current (max) (A): 1.5 Vin (max) (V): 6.4 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 4.1 Battery charge voltage (max) (V): 4.1 Absolute max Vin (max) (V): 28 Control topology: Linear 更多

Number of series cells: 2, 3, 4 Charge current (max) (A): 10 Vin (max) (V): 24 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 8 Battery charge voltage (max) (V): 18 Absolute max Vin (max) (V): 30 Control topology: Switch-Mode Buck Control interface: Standalone (RC-Settable) Features: Power Path Vin (min) (V): 8 Rating: Catalog Operating temperature range (°C): -40 to 125 Number of series cells: 2, 3, 4 Charge current (max) (A): 10 Vin (max) (V): 24 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 8 Battery charge voltage (max) (V): 18 Absolute max Vin (max) (V): 30 更多

Function: Charger Front-End Protection Number of series cells (min): 1 Number of series cells (max): 1 Operating current (typ) (µA): 400 Rating: Catalog Vin (max) (V): 30 Overvoltage protection: 7.1 Operating temperature range (°C): -40 to 85 Battery overvoltage protection (min) (V): 4.35 Battery overvoltage protection (max) (V): 4.35 Function: Charger Front-End Protection Number of series cells (min): 1 Number of series cells (max): 1 Operating current (typ) (µA): 400 Rating: Catalog Vin (max) (V): 30 Overvoltage protection: 7.1 Operating temperature range (°C): -40 to 85 Battery overvoltage protection (min) (V): 4.35 Battery overvoltage protection (max) (V): 4.35

Function: Charger Front-End Protection Number of series cells (min): 1 Number of series cells (max): 1 Operating current (typ) (µA): 400 Rating: Catalog Vin (max) (V): 30 Overvoltage protection: 6.17 Operating temperature range (°C): -40 to 85 Battery overvoltage protection (min) (V): 4.35 Battery overvoltage protection (max) (V): 4.35 Function: Charger Front-End Protection Number of series cells (min): 1 Number of series cells (max): 1 Operating current (typ) (µA): 400 Rating: Catalog Vin (max) (V): 30 Overvoltage protection: 6.17 Operating temperature range (°C): -40 to 85 Battery overvoltage protection (min) (V): 4.35 Battery overvoltage protection (max) (V): 4.35

Number of series cells: 1 Charge current (max) (A): 1.2 Vin (max) (V): 6 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.5 Battery charge voltage (max) (V): 4.44 Absolute max Vin (max) (V): 20 Control topology: Switch-Mode Buck Control interface: I2C Vin (min) (V): 4 Rating: Catalog Operating temperature range (°C): -40 to 85 Number of series cells: 1 Charge current (max) (A): 1.2 Vin (max) (V): 6 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.5 Battery charge voltage (max) (V): 4.44 Absolute max Vin (max) (V): 20 Control topology: Switch-Mode Buck 更多

Cell chemistry: Li-Ion/Li-Polymer Number of series cells: Single Cell Communication interface: I2C Battery capacity (min) (mAh): 300 Battery capacity (max) (mAh): 8000 Implementation: System External capacity indication: None Features: Impedance Track™ algorithm Operating temperature range (°C): -40 to 85 Rating: Catalog Cell chemistry: Li-Ion/Li-Polymer Number of series cells: Single Cell Communication interface: I2C Battery capacity (min) (mAh): 300 Battery capacity (max) (mAh): 8000 Implementation: System External capacity indication: None Features: Impedance Track™ algorithm Operating temperature range (°C): -40 to 85 Rating: Catalog
