Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 2 IOL (max) (mA): 8 IOH (max) (mA): 0 Input type: Standard CMOS Output type: Open-drain Features: Over-voltage tolerant inputs, Very high speed (tpd 5-10ns) Data rate (max) (Mbps): 110 Rating: Catalog Operating temperature range (°C): -55 to 125 Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 2 IOL (max) (mA): 8 IOH (max) (mA): 0 更多

Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 1 IOL (max) (mA): 32 IOH (max) (mA): -32 Input type: Schmitt-Trigger Output type: 3-State Data rate (max) (Mbps): 100 Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 1 IOL (max) (mA): 32 IOH (max) (mA): -32 Input type: Schmitt-Trigger 更多

Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 3 IOL (max) (mA): 32 IOH (max) (mA): -32 Input type: Standard CMOS Output type: Push-Pull Data rate (max) (Mbps): 100 Rating: Automotive Operating temperature range (°C): -40 to 85 Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 3 IOL (max) (mA): 32 IOH (max) (mA): -32 Input type: Standard CMOS 更多

Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 2 IOL (max) (mA): 8 Input type: Standard CMOS IOH (max) (mA): -8 Output type: Push-Pull Features: Over-voltage tolerant inputs, Very high speed (tpd 5-10ns) Data rate (max) (Mbps): 110 Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 2 IOL (max) (mA): 8 Input type: Standard CMOS 更多

Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 3 IOL (max) (mA): 32 IOH (max) (mA): -32 Input type: Standard CMOS Output type: Push-Pull Data rate (max) (Mbps): 100 Rating: Automotive Operating temperature range (°C): -40 to 85 Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 3 IOL (max) (mA): 32 IOH (max) (mA): -32 Input type: Standard CMOS 更多

Technology family: AHCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 2 IOL (max) (mA): 8 Input type: TTL-Compatible CMOS IOH (max) (mA): -8 Output type: Push-Pull Features: Over-voltage tolerant inputs, Very high speed (tpd 5-10ns) Data rate (max) (Mbps): 70 Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: AHCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 2 IOL (max) (mA): 8 Input type: TTL-Compatible CMOS 更多

Technology family: AUP Supply voltage (min) (V): 0.8 Supply voltage (max) (V): 3.6 Number of channels: 2 Inputs per channel: 2 IOL (max) (mA): 4 IOH (max) (mA): -4 Input type: Standard CMOS Output type: Push-Pull Data rate (max) (Mbps): 100 Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: AUP Supply voltage (min) (V): 0.8 Supply voltage (max) (V): 3.6 Number of channels: 2 Inputs per channel: 2 IOL (max) (mA): 4 IOH (max) (mA): -4 Input type: Standard CMOS 更多

Configuration: Serial-in, Parallel-out Bits (#): 8 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Input type: Standard CMOS Output type: 3-State Clock frequency (MHz): 24 IOL (max) (mA): 7.8 IOH (max) (mA): -7.8 Supply current (max) (µA): 80 Operating temperature range (°C): -55 to 125 Rating: HiRel Enhanced Product Configuration: Serial-in, Parallel-out Bits (#): 8 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Input type: Standard CMOS Output type: 3-State 更多

Configuration: Serial-in, Parallel-out Bits (#): 8 Technology family: CD4000 Supply voltage (min) (V): 3 Supply voltage (max) (V): 18 Input type: Standard CMOS Output type: Push-Pull Clock frequency (MHz): 8.5 IOL (max) (mA): 4.2 IOH (max) (mA): -4.2 Supply current (max) (µA): 3000 Operating temperature range (°C): -40 to 125 Rating: Automotive Configuration: Serial-in, Parallel-out Bits (#): 8 Technology family: CD4000 Supply voltage (min) (V): 3 Supply voltage (max) (V): 18 Input type: Standard CMOS Output type: Push-Pull 更多

Number of channels: 2 Technology family: AUP Supply voltage (min) (V): 0.8 Supply voltage (max) (V): 3.6 Input type: Standard CMOS Output type: Push-Pull Clock frequency (max) (MHz): 260 IOL (max) (mA): 4 IOH (max) (mA): -4 Supply current (max) (µA): 0.9 Operating temperature range (°C): -40 to 85 Rating: Catalog Number of channels: 2 Technology family: AUP Supply voltage (min) (V): 0.8 Supply voltage (max) (V): 3.6 Input type: Standard CMOS Output type: Push-Pull Clock frequency (max) (MHz): 260 IOL (max) (mA): 4 更多
