TMS320F28386D-Q1


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有连接管理器、2x C28x+CLA CPU、1.5MB 闪存、FPU64、CLB、以太网的汽车类 C2000™ 32 位 MCU

CPU: 2x C28x, 2x CLA Frequency (MHz): 200 Flash memory (kByte): 1536 RAM (kByte): 338 ADC resolution (bps): 12, 16 Total processing (MIPS): 925 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 12 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Automotive Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB CPU: 2x C28x, 2x CLA
Frequency (MHz): 200 Flash memory (kByte): 1536 RAM (kByte): 338 ADC resolution (bps): 12, 16 Total processing (MIPS): 925 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 12 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Automotive Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB

TMS320C28341


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有 200MIPS、FPU、196KB RAM、EMIF 的 C2000™ 32 位 MCU

CPU: C28x Frequency (MHz): 200 Flash memory (kByte): 0 RAM (kByte): 196 Total processing (MIPS): 200 Features: External ADC interface, FPU32 UART: 3 CAN (#): 2 Sigma-delta filter: 0 PWM (Ch): 12 Number of ADC channels: 0 Direct memory access (Ch): 6 SPI: 2 QEP: 2 USB: No Operating temperature range (°C): -40 to 105 Rating: Catalog Communication interface: CAN, I2C, SPI, UART CPU: C28x Frequency (MHz): 200
Flash memory (kByte): 0 RAM (kByte): 196 Total processing (MIPS): 200 Features: External ADC interface, FPU32 UART: 3 CAN (#): 2 Sigma-delta filter: 0 PWM (Ch): 12 Number of ADC channels: 0 Direct memory access (Ch): 6 SPI: 2 QEP: 2 USB: No Operating temperature range (°C): -40 to 105 Rating: Catalog Communication interface: CAN, I2C, SPI, UART

TMS320C28343


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有 200MIPS、FPU、260KB RAM、EMIF 的 C2000™ 32 位 MCU

CPU: C28x Frequency (MHz): 200 Flash memory (kByte): 0 RAM (kByte): 260 Total processing (MIPS): 200 Features: External ADC interface, FPU32 UART: 3 CAN (#): 2 Sigma-delta filter: 0 PWM (Ch): 18 Number of ADC channels: 0 Direct memory access (Ch): 6 SPI: 2 QEP: 2 USB: No Operating temperature range (°C): -40 to 105 Rating: Catalog Communication interface: CAN, I2C, SPI, UART CPU: C28x Frequency (MHz): 200
Flash memory (kByte): 0 RAM (kByte): 260 Total processing (MIPS): 200 Features: External ADC interface, FPU32 UART: 3 CAN (#): 2 Sigma-delta filter: 0 PWM (Ch): 18 Number of ADC channels: 0 Direct memory access (Ch): 6 SPI: 2 QEP: 2 USB: No Operating temperature range (°C): -40 to 105 Rating: Catalog Communication interface: CAN, I2C, SPI, UART

TMS320F280025


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有 100MHz 频率、FPU、TMU、128kB 闪存的 C2000™ 32 位 MCU

CPU: C28x Frequency (MHz): 100 Flash memory (kByte): 128 RAM (kByte): 24 ADC resolution (bps): 12 Total processing (MIPS): 100 Features: FPU32 UART: 3 CAN (#): 1 Sigma-delta filter: 0 PWM (Ch): 14 TI functional safety category: Functional Safety Quality-Managed Number of ADC channels: 14, 16 Direct memory access (Ch): 6 SPI: 2 QEP: 2 USB: No Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, FSI, I2C, LIN, PMBUS, SCI, SPI
CPU: C28x Frequency (MHz): 100 Flash memory (kByte): 128 RAM (kByte): 24 ADC resolution (bps): 12 Total processing (MIPS): 100 Features: FPU32 UART: 3 CAN (#): 1 Sigma-delta filter: 0 PWM (Ch): 14 TI functional safety category: Functional Safety Quality-Managed Number of ADC channels: 14, 16 Direct memory access (Ch): 6 SPI: 2 QEP: 2 USB: No Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, FSI, I2C, LIN, PMBUS, SCI, SPI

TMS320F280025C


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有 100MHz 频率、FPU、TMU、128kB 闪存、CLB 的 C2000™ 32 位 MCU

CPU: C28x Frequency (MHz): 100 Flash memory (kByte): 128 RAM (kByte): 24 ADC resolution (bps): 12 Total processing (MIPS): 100 Features: Configurable logic block, FPU32 UART: 3 CAN (#): 1 Sigma-delta filter: 0 PWM (Ch): 14 TI functional safety category: Functional Safety Quality-Managed Number of ADC channels: 14, 16 Direct memory access (Ch): 6 SPI: 2 QEP: 2 USB: No Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, FSI, I2C, LIN, PMBUS, SPI, UART
CPU: C28x Frequency (MHz): 100 Flash memory (kByte): 128 RAM (kByte): 24 ADC resolution (bps): 12 Total processing (MIPS): 100 Features: Configurable logic block, FPU32 UART: 3 CAN (#): 1 Sigma-delta filter: 0 PWM (Ch): 14 TI functional safety category: Functional Safety Quality-Managed Number of ADC channels: 14, 16 Direct memory access (Ch): 6 SPI: 2 QEP: 2 USB: No Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, FSI, I2C, LIN, PMBUS, SPI, UART

TMS320F28384S


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有连接管理器、1 个 C28x+CLA CPU、1.0MB 闪存、FPU64、以太网的 C2000™ 32 位 MCU

CPU: C28x, CLA Frequency (MHz): 200 Flash memory (kByte): 1024 RAM (kByte): 277 ADC resolution (bps): 12, 16 Total processing (MIPS): 525 Features: CAN FD, Connectivity manager, Ethernet, FPU64 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 6 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB
CPU: C28x, CLA Frequency (MHz): 200 Flash memory (kByte): 1024 RAM (kByte): 277 ADC resolution (bps): 12, 16 Total processing (MIPS): 525 Features: CAN FD, Connectivity manager, Ethernet, FPU64 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 6 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB

TMS320F28386S


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有连接管理器、1 个 C28x+CLA CPU、1.0MB 闪存、FPU64、CLB、以太网的 C2000™ 32 位 MCU

CPU: C28x, CLA Frequency (MHz): 200 Flash memory (kByte): 1024 RAM (kByte): 277 ADC resolution (bps): 12, 16 Total processing (MIPS): 525 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 6 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB CPU: C28x, CLA
Frequency (MHz): 200 Flash memory (kByte): 1024 RAM (kByte): 277 ADC resolution (bps): 12, 16 Total processing (MIPS): 525 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 6 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB

TMS320F28384D


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有连接管理器、2 个 C28x+CLA CPU、1.5MB 闪存、FPU64、以太网的 C2000™ 32 位 MCU

CPU: 2x C28x, 2x CLA Frequency (MHz): 200 Flash memory (kByte): 1536 RAM (kByte): 338 ADC resolution (bps): 12, 16 Total processing (MIPS): 925 Features: CAN FD, Connectivity manager, Ethernet, FPU64 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 12 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB
CPU: 2x C28x, 2x CLA Frequency (MHz): 200 Flash memory (kByte): 1536 RAM (kByte): 338 ADC resolution (bps): 12, 16 Total processing (MIPS): 925 Features: CAN FD, Connectivity manager, Ethernet, FPU64 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 12 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB

TMS320F28386D


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有连接管理器、2 个 C28x+CLA CPU、1.5MB 闪存、FPU64、CLB、以太网的 C2000™ 32 位 MCU

CPU: 2x C28x, 2x CLA Frequency (MHz): 200 Flash memory (kByte): 1536 RAM (kByte): 338 ADC resolution (bps): 12, 16 Total processing (MIPS): 925 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 12 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB CPU: 2x C28x, 2x CLA
Frequency (MHz): 200 Flash memory (kByte): 1536 RAM (kByte): 338 ADC resolution (bps): 12, 16 Total processing (MIPS): 925 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 12 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog Communication interface: CAN, CAN FD, Ethernet, FSI, I2C, McBSP, PMBUS, SCI, SPI, USB

TMS320F28388S


数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)

描述: 具有连接管理器、1 个 C28x+CLA CPU、1.0MB 闪存、FPU64、CLB、ENET、EtherCAT 的 C2000™ 32 位 MCU

CPU: C28x, CLA Frequency (MHz): 200 Flash memory (kByte): 1024 RAM (kByte): 277 ADC resolution (bps): 12, 16 Total processing (MIPS): 525 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 6 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog CPU: C28x, CLA Frequency (MHz): 200
Flash memory (kByte): 1024 RAM (kByte): 277 ADC resolution (bps): 12, 16 Total processing (MIPS): 525 UART: 4 CAN (#): 3 Sigma-delta filter: 8 PWM (Ch): 32 TI functional safety category: Functional Safety-Compliant Number of ADC channels: 12, 16 Direct memory access (Ch): 6 SPI: 8 QEP: 32 USB: Yes Operating temperature range (°C): -40 to 125 Rating: Catalog
