SRAM (incl. Cache): 50.0kByte
Program Memory: 832.0kByte
Number of ADC Modules: 2.0
I/O Operation Voltages: 3.3V
CAN Nodes: 3
A/D Input Lines(incl. FADC): 24
Type of Memory: Flash
Digital I/O Pins: 118
EEPROM Emulation(Data-Flash): yes
Timed I/O Pins(PWM, CAPCOM): 32
Serial I/O Interfaces: 6
Type of Serial I/O Interfaces: UART
Instruction Width([bits]): 16/32
DMA Channels: 8
Timer/Counter: 17
External Bus Interface: yes
Fast Flash Programming: yes
Temperature: -40 to 125°C
Power Mode: 2
DSP Functionality: yes
更多
On-chip Clock Generation: yes
Touch/LED Matrix Control: no
On-chip Voltage Regulator: yes
Real Time Clock: yes
Floating Point Unit: no
Watchdog Timer: yes
Oscillator Watchdog: yes
Additional Features: no
Qualification: Automotive
Language: IBIS
Budgetary Price €/1k: 10.02
SRAM (incl. Cache): 50.0kByte
Program Memory: 832.0kByte
Number of ADC Modules: 2.0
I/O Operation Voltages: 3.3V
CAN Nodes: 3
A/D Input Lines (incl. FADC): 16
Type of Memory: Flash
Digital I/O Pins: 76
EEPROM Emulation(Data-Flash): yes
Timed I/O Pins(PWM, CAPCOM): 24
Serial I/O Interfaces: 6
Type of Serial I/O Interfaces: UART
Instruction Width([bits]): 16/32
DMA Channels: 8
Timer/Counter: 17
External Bus Interface: yes
Fast Flash Programming: yes
Temperature: -40 to 125°C
Power Mode: 2
DSP Functionality: yes
更多
On-chip Clock Generation: yes
Touch/LED Matrix Control: no
On-chip Voltage Regulator: yes
Real Time Clock: yes
Floating Point Unit: no
Watchdog Timer: yes
Oscillator Watchdog: yes
Additional Features: no
Qualification: Automotive
Language: IBIS
Budgetary Price €/1k: 8.93
SRAM (incl. Cache): 90.0kByte
I/O Operation Voltages: 3.3V
I/O Operation Voltages: 5.0V
Program Memory: 1088.0kByte
Number of ADC Modules: 2.0
Type of Memory: Flash
EEPROM Emulation(Data-Flash): yes
A/D Input Lines (incl. FADC): 24
Digital I/O Pins: 118
Timed I/O Pins(PWM, CAPCOM): 32
Serial I/O Interfaces: 4
Type of Serial I/O Interfaces: UART
Type of Serial I/O Interfaces: SPI
Type of Serial I/O Interfaces: I²C
Type of Serial I/O Interfaces: I²S
Type of Serial I/O Interfaces: LIN
Type of Serial I/O Interfaces: CAN
Type of Serial I/O Interfaces: FlexRay™
CAN Nodes: 3
DMA Channels: 16
更多
Fast Flash Programming: yes
DSP Functionality: yes
On-chip Clock Generation: yes
On-chip Voltage Regulator: yes
Real Time Clock: yes
Floating Point Unit: no
Additional Features: instruction cache
Touch/LED Matrix Control: no
Qualification: Automotive
Timer/Counter: 17
Instruction Width([bits]): 16/32
External Bus Interface: yes
Temperature: -40 to 125°C
Watchdog Timer: yes
Oscillator Watchdog: yes
Power Mode: 2
Budgetary Price €/1k: 16.54
SRAM (incl. Cache): 82.0kByte
Program Memory: 768.0kByte
I/O Operation Voltages: 5.0V
I/O Operation Voltages: 3.3V
Number of ADC Modules: 2.0
Additional Features: for selected automotive leadcustomers
Touch/LED Matrix Control: no
On-chip Voltage Regulator: yes
Floating Point Unit: no
External Bus Interface: yes
Fast Flash Programming: no
Temperature: -40 to 125°C
Qualification: Automotive
Power Mode: 3
Watchdog Timer: yes
Oscillator Watchdog: yes
Timer/Counter: 15
DSP Functionality: yes
Type of Memory: Flash
CAN Nodes: 5
更多
Real Time Clock: yes
EEPROM Emulation(Data-Flash): yes
A/D Input Lines (incl. FADC): 16
Timed I/O Pins(PWM, CAPCOM): 32
Serial I/O Interfaces: 6
Instruction Width([bits]): 16/32
DMA Channels: 8
Type of Serial I/O Interfaces: UART
Type of Serial I/O Interfaces: SPI
Type of Serial I/O Interfaces: I²C
Type of Serial I/O Interfaces: I²S
Type of Serial I/O Interfaces: LIN
Type of Serial I/O Interfaces: CAN
Digital I/O Pins: 75
On-chip Clock Generation: yes
Language: IBIS
Budgetary Price €/1k: 11.55
SRAM (incl. Cache): 82.0kByte
Program Memory: 768.0kByte
I/O Operation Voltages: 5.0V
I/O Operation Voltages: 3.3V
Number of ADC Modules: 2.0
Additional Features: for selected automotive leadcustomers
Touch/LED Matrix Control: no
On-chip Voltage Regulator: yes
Floating Point Unit: no
External Bus Interface: yes
Fast Flash Programming: no
Temperature: -40 to 125°C
Qualification: Automotive
Power Mode: 3
Watchdog Timer: yes
Oscillator Watchdog: yes
Timer/Counter: 15
DSP Functionality: yes
Type of Memory: Flash
CAN Nodes: 5
更多
Real Time Clock: yes
EEPROM Emulation(Data-Flash): yes
A/D Input Lines (incl. FADC): 24
Timed I/O Pins(PWM, CAPCOM): 32
Serial I/O Interfaces: 6
Instruction Width([bits]): 16/32
DMA Channels: 8
Type of Serial I/O Interfaces: UART
Type of Serial I/O Interfaces: SPI
Type of Serial I/O Interfaces: I²C
Type of Serial I/O Interfaces: I²S
Type of Serial I/O Interfaces: LIN
Type of Serial I/O Interfaces: CAN
Digital I/O Pins: 118
On-chip Clock Generation: yes
Language: IBIS
Budgetary Price €/1k: 11.91
SRAM (incl. Cache): 50.0kByte
Program Memory: 832.0kByte
Number of ADC Modules: 2.0
I/O Operation Voltages: 3.3V
CAN Nodes: 6
A/D Input Lines (incl. FADC): 16
Type of Memory: Flash
Digital I/O Pins: 76
EEPROM Emulation(Data-Flash): yes
Timed I/O Pins(PWM, CAPCOM): 32
Serial I/O Interfaces: 8
Type of Serial I/O Interfaces: UART
Instruction Width([bits]): 16/32
DMA Channels: 8
Timer/Counter: 15
External Bus Interface: yes
Fast Flash Programming: no
Temperature: -40 to 125°C
Power Mode: 3
DSP Functionality: yes
更多
On-chip Clock Generation: yes
Touch/LED Matrix Control: no
On-chip Voltage Regulator: yes
Real Time Clock: yes
Floating Point Unit: no
Watchdog Timer: yes
Oscillator Watchdog: yes
Additional Features: no
I/O Operation Voltages: 5.0V
Qualification: Automotive
Budgetary Price €/1k: 7.4
SRAM (incl. Cache): 0.5kByte
Program Memory: 4.0kByte
I/O Operation Voltages: 3.3V
I/O Operation Voltages: 5.0V
Number of ADC Modules: 1.0
Additional Features: Industrial
Touch/LED Matrix Control: yes
On-chip Voltage Regulator: yes
Floating Point Unit: no
External Bus Interface: no
Fast Flash Programming: no
Temperature: -40 to 85°C
Qualification: Industrial
Power Mode: 4
Watchdog Timer: yes
Oscillator Watchdog: yes
Timer/Counter: 0
DSP Functionality: yes
Type of Memory: Flash
CAN Nodes: 0
更多
Real Time Clock: yes
EEPROM Emulation(Data-Flash): yes
A/D Input Lines (incl. FADC): 4
Timed I/O Pins(PWM, CAPCOM): 4
Serial I/O Interfaces: 3
Instruction Width([bits]): 8
DMA Channels: 0
Type of Serial I/O Interfaces: UART
Type of Serial I/O Interfaces: SPI
Type of Serial I/O Interfaces: I²C
Digital I/O Pins: 0
On-chip Clock Generation: yes
SRAM (incl. Cache): 0.5kByte
Program Memory: 8.0kByte
I/O Operation Voltages: 3.3V
I/O Operation Voltages: 5.0V
Number of ADC Modules: 1.0
Additional Features: Industrial
Touch/LED Matrix Control: yes
On-chip Voltage Regulator: yes
Floating Point Unit: no
External Bus Interface: no
Fast Flash Programming: no
Temperature: -40 to 85°C
Qualification: Industrial
Power Mode: 4
Watchdog Timer: yes
Oscillator Watchdog: yes
Timer/Counter: 2
DSP Functionality: yes
Type of Memory: Flash
CAN Nodes: 0
更多
Real Time Clock: yes
EEPROM Emulation(Data-Flash): yes
A/D Input Lines (incl. FADC): 4
Timed I/O Pins(PWM, CAPCOM): 4
Serial I/O Interfaces: 3
Instruction Width([bits]): 8
DMA Channels: 0
Type of Serial I/O Interfaces: UART
Type of Serial I/O Interfaces: SPI
Type of Serial I/O Interfaces: I²C
Digital I/O Pins: 0
On-chip Clock Generation: yes
Budgetary Price €/1k: 1.38
SRAM (incl. Cache): 34.0kByte
Program Memory: 320.0kByte
Number of ADC Modules: 2.0
I/O Operation Voltages: 3.3V
CAN Nodes: 6
A/D Input Lines (incl. FADC): 9
Type of Memory: Flash
Digital I/O Pins: 38
EEPROM Emulation(Data-Flash): yes
Timed I/O Pins(PWM, CAPCOM): up to 22
Serial I/O Interfaces: 4
Type of Serial I/O Interfaces: UART
Instruction Width([bits]): 16/32
DMA Channels: 8
Timer/Counter: 13
External Bus Interface: yes
Fast Flash Programming: no
Temperature: -40 to 125°C
Power Mode: 3
DSP Functionality: yes
更多
On-chip Clock Generation: yes
Touch/LED Matrix Control: no
On-chip Voltage Regulator: yes
Real Time Clock: yes
Floating Point Unit: no
Watchdog Timer: yes
Oscillator Watchdog: yes
Additional Features: for details, please refer to the data sheet
Qualification: Automotive
Budgetary Price €/1k: 6.04
SRAM (incl. Cache): 0.5kByte
Program Memory: 8.0kByte
I/O Operation Voltages: 3.3V
I/O Operation Voltages: 5.0V
Number of ADC Modules: 1.0
Additional Features: Industrial
Touch/LED Matrix Control: no
On-chip Voltage Regulator: yes
Floating Point Unit: no
External Bus Interface: no
Fast Flash Programming: no
Temperature: -40 to 85°C
Qualification: Industrial
Power Mode: 4
Watchdog Timer: yes
Oscillator Watchdog: yes
Timer/Counter: 2
DSP Functionality: yes
Type of Memory: Flash
CAN Nodes: 0
更多
Real Time Clock: yes
EEPROM Emulation(Data-Flash): yes
A/D Input Lines (incl. FADC): 4
Timed I/O Pins(PWM, CAPCOM): 4
Serial I/O Interfaces: 3
Instruction Width([bits]): 8
DMA Channels: 0
Type of Serial I/O Interfaces: UART
Type of Serial I/O Interfaces: SPI
Type of Serial I/O Interfaces: I²C
Digital I/O Pins: 0
On-chip Clock Generation: yes
Budgetary Price €/1k: 1.38
