ADC12DL1500

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 12 位双通道 1.5GSPS 或单通道 3GSPS 模数转换器（LVDS 接口）

Sample rate (max) (Msps): 1500, 3000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: DDR LVDS, Parallel LVDS Analog input BW (MHz): 8000 Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 2770 Architecture: Folding Interpolating SNR (dB): 56.8 ENOB (Bits): 9 SFDR (dB): 67 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 1500, 3000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: DDR LVDS, Parallel LVDS Analog input BW (MHz): 8000 更多

Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 2770 Architecture: Folding Interpolating SNR (dB): 56.8 ENOB (Bits): 9 SFDR (dB): 67 Operating temperature range (°C): -40 to 85 Input buffer: Yes

ADC12DL2500

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 12 位双通道 2.5GSPS 或单通道 5GSPS 模数转换器（LVDS 接口）

Sample rate (max) (Msps): 2500, 5000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: DDR LVDS, Parallel LVDS Analog input BW (MHz): 8000 Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 2948 Architecture: Folding Interpolating SNR (dB): 56 ENOB (Bits): 9 SFDR (dB): 65 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 2500, 5000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: DDR LVDS, Parallel LVDS Analog input BW (MHz): 8000 更多

Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 2948 Architecture: Folding Interpolating SNR (dB): 56 ENOB (Bits): 9 SFDR (dB): 65 Operating temperature range (°C): -40 to 85 Input buffer: Yes

ADC12DL500

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 12 位双通道 500MSPS 或单通道 1GSPS 模数转换器（LVDS 接口）

Sample rate (max) (Msps): 500, 1000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: DDR LVDS, Parallel LVDS Analog input BW (MHz): 8000 Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 2500 Architecture: Folding Interpolating SNR (dB): 56.8 ENOB (Bits): 9 SFDR (dB): 69 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 500, 1000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: DDR LVDS, Parallel LVDS Analog input BW (MHz): 8000 更多

Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 2500 Architecture: Folding Interpolating SNR (dB): 56.8 ENOB (Bits): 9 SFDR (dB): 69 Operating temperature range (°C): -40 to 85 Input buffer: Yes

ADS1288

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 用于地震探测和地球空间探测的低功耗 32 位双通道 Δ-Σ ADC

Resolution (Bits): 32 Sample rate (max) (ksps): 2 Number of input channels: 2 Interface type: SPI Architecture: Delta-Sigma Input type: Differential Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 2.5 Input voltage range (min) (V): -2.5 Features: GPIO, PGA Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 5 Analog supply (min) (V): 3 Analog supply voltage (max) (V): 5.5 SNR (dB): 121 Digital supply (min) (V): 1.65 Digital supply (max) (V): 3.6 Resolution (Bits): 32 更多

Sample rate (max) (ksps): 2 Number of input channels: 2 Interface type: SPI Architecture: Delta-Sigma Input type: Differential Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 2.5 Input voltage range (min) (V): -2.5 Features: GPIO, PGA Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 5 Analog supply (min) (V): 3 Analog supply voltage (max) (V): 5.5 SNR (dB): 121 Digital supply (min) (V): 1.65 Digital supply (max) (V): 3.6

ADC3910D125

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有单时钟周期延迟、高达 16 倍抽取率以及数字比较器的 10 位双通道 125MSPS ADC

Sample rate (max) (Msps): 125 Resolution (Bits): 10 Number of input channels: 2 Interface type: Parallel CMOS, Serial CMOS Analog input BW (MHz): 150 Rating: Catalog Peak-to-peak input voltage range (V): 1.9 Power consumption (typ) (mW): 98 Architecture: SAR SNR (dB): 60.8 ENOB (Bits): 9.8 SFDR (dB): 67 Operating temperature range (°C): -40 to 105 Input buffer: Yes Sample rate (max) (Msps): 125 Resolution (Bits): 10 Number of input channels: 2 Interface type: Parallel CMOS, Serial CMOS Analog input BW (MHz): 150 Rating: Catalog 更多

Peak-to-peak input voltage range (V): 1.9 Power consumption (typ) (mW): 98 Architecture: SAR SNR (dB): 60.8 ENOB (Bits): 9.8 SFDR (dB): 67 Operating temperature range (°C): -40 to 105 Input buffer: Yes

ADS1115L

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有 PGA、比较器和 1.8V I²C 总线电压支持的 16 位、860SPS 四通道 Δ-Σ ADC

Resolution (Bits): 16 Sample rate (max) (ksps): 0.86 Number of input channels: 4 Interface type: I2C Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Internal Input voltage range (max) (V): 3.6 Input voltage range (min) (V): 0 Features: Comparator, Oscillator, PGA Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 0.3 Analog supply (min) (V): 2 Analog supply voltage (max) (V): 3.6 Digital supply (min) (V): 2 Digital supply (max) (V): 3.6 Resolution (Bits): 16 Sample rate (max) (ksps): 0.86 更多

Number of input channels: 4 Interface type: I2C Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Internal Input voltage range (max) (V): 3.6 Input voltage range (min) (V): 0 Features: Comparator, Oscillator, PGA Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 0.3 Analog supply (min) (V): 2 Analog supply voltage (max) (V): 3.6 Digital supply (min) (V): 2 Digital supply (max) (V): 3.6

TX75E16

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有增强型阻尼特性的 16 通道五级变送器

Device type: Transmitter Number of input channels: 16 Active supply current (typ) (mA): 3.6 Supply voltage (max) (V): 5.5 Operating temperature range (°C): 0 to 70 Interface type: Serial Rating: Catalog Device type: Transmitter Number of input channels: 16 Active supply current (typ) (mA): 3.6 Supply voltage (max) (V): 5.5 Operating temperature range (°C): 0 to 70 Interface type: Serial Rating: Catalog

ADS9817

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有集成模拟前端的八通道、18 位、2MSPS/通道、双路同步采样 ADC

Resolution (Bits): 18 Sample rate (max) (ksps): 2000 Number of input channels: 8 Interface type: Enhanced SPI, Serial CMOS Architecture: SAR Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 12 Input voltage range (min) (V): -12 Features: Over-Voltage Protection, PGA Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 220 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 SNR (dB): 92.3 Digital supply (min) (V): 1.75 Digital supply (max) (V): 1.85 Resolution (Bits): 18 更多

Sample rate (max) (ksps): 2000 Number of input channels: 8 Interface type: Enhanced SPI, Serial CMOS Architecture: SAR Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 12 Input voltage range (min) (V): -12 Features: Over-Voltage Protection, PGA Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 220 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 SNR (dB): 92.3 Digital supply (min) (V): 1.75 Digital supply (max) (V): 1.85

TX08D

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 集成 8 个线性放大器和 DAC 并配备 5 级脉冲发生器、T/R 开关和片上波束形成器

Device type: Transmitter Number of input channels: 8 Supply voltage (max) (V): 5.5 Operating temperature range (°C): 0 to 70 Interface type: Serial Rating: Catalog Device type: Transmitter Number of input channels: 8 Supply voltage (max) (V): 5.5 Operating temperature range (°C): 0 to 70 Interface type: Serial Rating: Catalog

AFE3256

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 适用于动态和半动态 X 射线平板检测器的 256 通道模拟前端 (AFE)

Number of input channels: 256 Resolution (Bits): 16 Features: Internal Reference Buffer, Nap Mode, Power Down, X-ray Interface type: SPI/LVDS Operating temperature range (°C): 0 to 70 Rating: Catalog Number of input channels: 256 Resolution (Bits): 16 Features: Internal Reference Buffer, Nap Mode, Power Down, X-ray Interface type: SPI/LVDS Operating temperature range (°C): 0 to 70 Rating: Catalog
