Resolution (Bits): 8 Sample rate (max) (ksps): 200 Number of input channels: 8 Interface type: Microwire (Serial I/O), SPI Architecture: SAR Input type: Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Supply Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 105 Power consumption (typ) (mW): 0.9 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 49.5 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 8 Sample rate (max) (ksps): 200 更多

Resolution (Bits): 8 Sample rate (max) (ksps): 500 Number of input channels: 8 Interface type: Microwire (Serial I/O), SPI Architecture: SAR Input type: Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Supply Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 105 Power consumption (typ) (mW): 1.2 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 49.6 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 8 Sample rate (max) (ksps): 500 更多

Resolution (Bits): 10 Sample rate (max) (ksps): 200 Number of input channels: 8 Interface type: Microwire (Serial I/O), SPI Architecture: SAR Input type: Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Supply Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 105 Power consumption (typ) (mW): 1.1 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 61.9 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 10 Sample rate (max) (ksps): 200 更多

Resolution (Bits): 10 Sample rate (max) (ksps): 500 Number of input channels: 8 Interface type: Microwire (Serial I/O), SPI Architecture: SAR Input type: Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Supply Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 105 Power consumption (typ) (mW): 1.5 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 61.8 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 10 Sample rate (max) (ksps): 500 更多

Resolution (Bits): 8 Sample rate (max) (ksps): 1000 Number of input channels: 8 Interface type: Microwire (Serial I/O), SPI Architecture: SAR Input type: Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Supply Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 105 Power consumption (typ) (mW): 1.8 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 49.6 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 8 Sample rate (max) (ksps): 1000 更多

Resolution (Bits): 10 Sample rate (max) (ksps): 1000 Number of input channels: 8 Interface type: Microwire (Serial I/O), SPI Architecture: SAR Input type: Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Supply Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 105 Power consumption (typ) (mW): 2.1 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 61.8 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 10 Sample rate (max) (ksps): 1000 更多

Sample rate (max) (Msps): 20 Resolution (Bits): 14 Number of input channels: 1 Interface type: Parallel CMOS, TTL Analog input BW (MHz): 150 Features: Low Power Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 150 Architecture: Pipeline SNR (dB): 74 ENOB (Bits): 12 SFDR (dB): 93 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 20 Resolution (Bits): 14 Number of input channels: 1 Interface type: Parallel CMOS, TTL Analog input BW (MHz): 150 更多

Sample rate (max) (Msps): 65 Resolution (Bits): 12 Number of input channels: 8 Interface type: Parallel LVDS Analog input BW (MHz): 300 Features: Low Power Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 983 Architecture: Pipeline SNR (dB): 71.2 ENOB (Bits): 11.5 SFDR (dB): 90 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 65 Resolution (Bits): 12 Number of input channels: 8 Interface type: Parallel LVDS Analog input BW (MHz): 300 更多

Sample rate (max) (Msps): 70 Resolution (Bits): 12 Number of input channels: 8 Interface type: Parallel LVDS Analog input BW (MHz): 300 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 1003 Architecture: Pipeline SNR (dB): 71.1 ENOB (Bits): 11.5 SFDR (dB): 92 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 70 Resolution (Bits): 12 Number of input channels: 8 Interface type: Parallel LVDS Analog input BW (MHz): 300 更多

Resolution (Bits): 12 Sample rate (max) (ksps): 200 Number of input channels: 1 Interface type: Microwire (Serial I/O), SPI Architecture: SAR Input type: Single-ended Rating: Catalog Reference mode: Supply Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: Small Size Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 1.5 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 72.3 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 12 Sample rate (max) (ksps): 200 更多
