Resolution (Bits): 14 Sample rate (max) (ksps): 1250 Number of input channels: 1 Interface type: SPI Architecture: SAR Input type: Pseudo-Differential, Single-ended Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 2.6 Input voltage range (min) (V): 0 Features: Oscillator Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 45 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 SNR (dB): 78 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 14 Sample rate (max) (ksps): 1250 更多

Resolution (Bits): 14 Sample rate (max) (ksps): 3000 Number of input channels: 1 Interface type: Byte-Wide, Parallel Architecture: SAR Input type: Pseudo-Differential, Single-ended Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 2.5 Input voltage range (min) (V): 0 Features: Oscillator Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 85 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 SNR (dB): 78.5 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 14 Sample rate (max) (ksps): 3000 更多

Resolution (Bits): 18 Sample rate (max) (ksps): 580 Number of input channels: 1 Interface type: Byte-Wide, Parallel Architecture: SAR Input type: Pseudo-Differential, Single-ended Rating: Catalog Reference mode: External Input voltage range (max) (V): 4.2 Input voltage range (min) (V): 0 Features: Oscillator Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 115 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 SNR (dB): 88 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 18 Sample rate (max) (ksps): 580 更多

Sample rate (max) (Msps): 65 Resolution (Bits): 12 Number of input channels: 1 Interface type: Parallel CMOS Analog input BW (MHz): 1000 Features: Low Power Rating: Catalog Peak-to-peak input voltage range (V): 2.25 Power consumption (typ) (mW): 400 Architecture: Pipeline SNR (dB): 68.5 ENOB (Bits): 11.3 SFDR (dB): 81 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 65 Resolution (Bits): 12 Number of input channels: 1 Interface type: Parallel CMOS Analog input BW (MHz): 1000 更多

Resolution (Bits): 12 Sample rate (max) (ksps): 1000 Number of input channels: 12 Interface type: Parallel, SPI Architecture: SAR Input type: Differential Multichannel configuration: Simultaneous Sampling Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 2.5 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 250 Analog supply (min) (V): 4.5 Analog supply voltage (max) (V): 5.5 SNR (dB): 71 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.5 Resolution (Bits): 12 Sample rate (max) (ksps): 1000 更多

Resolution (Bits): 12 Sample rate (max) (ksps): 500 Number of input channels: 8 Interface type: Microwire (Serial I/O), SPI Architecture: SAR Input type: Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: Supply Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 1.5 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 73 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 12 Sample rate (max) (ksps): 500 更多

Resolution (Bits): 18 Sample rate (max) (ksps): 1250 Number of input channels: 1 Interface type: Parallel Architecture: Delta-Sigma Input type: Differential Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 4.8 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 105 Power consumption (typ) (mW): 520 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 SNR (dB): 93 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 18 Sample rate (max) (ksps): 1250 Number of input channels: 1 更多

Resolution (Bits): 12 Sample rate (max) (ksps): 4000 Number of input channels: 1 Interface type: Byte-Wide, Parallel Architecture: SAR Input type: Pseudo-Differential, Single-ended Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 2.6 Input voltage range (min) (V): 0 Features: Oscillator Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 95 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 SNR (dB): 71.5 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 12 Sample rate (max) (ksps): 4000 更多

Resolution (Bits): 16 Sample rate (max) (ksps): 5000 Number of input channels: 1 Interface type: Parallel Architecture: Delta-Sigma Input type: Differential Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 4.7 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 560 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 SNR (dB): 84 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 16 Sample rate (max) (ksps): 5000 Number of input channels: 1 更多

Resolution (Bits): 24 Sample rate (max) (ksps): 30 Number of input channels: 2 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: 50/60 Hz Rejection, GPIO, PGA Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 36 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 Digital supply (min) (V): 1.8 Digital supply (max) (V): 3.6 Resolution (Bits): 24 Sample rate (max) (ksps): 30 更多
