Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 48 IOH (max) (mA): -48 Supply current (max) (µA): 27000 Input type: Bipolar Output type: Push-Pull Features: Balanced outputs, Ultra high speed (tpd <5ns) Rating: Military Operating temperature range (°C): -55 to 125 Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 48 IOH (max) (mA): -48 Supply current (max) (µA): 27000 Input type: Bipolar 更多

Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): -15 Supply current (max) (µA): 75000 Input type: Bipolar Output type: 3-State Features: Ultra high speed (tpd <5ns) Rating: Military Operating temperature range (°C): -55 to 125 Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): -15 Supply current (max) (µA): 75000 Input type: Bipolar 更多

Technology family: AHCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 8 Supply current (max) (µA): 20 IOH (max) (mA): -8 Input type: TTL-Compatible CMOS Output type: 3-State Rating: Military Operating temperature range (°C): -55 to 125 Technology family: AHCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 8 Supply current (max) (µA): 20 IOH (max) (mA): -8 Input type: TTL-Compatible CMOS Output type: 3-State 更多

Technology family: S Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 46000 IOH (max) (mA): -15 Input type: Bipolar Output type: 3-State Features: Very high speed (tpd 5-10ns) Rating: Military Operating temperature range (°C): -55 to 125 Technology family: S Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 46000 IOH (max) (mA): -15 Input type: Bipolar 更多

Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 48 Supply current (max) (µA): 14000 IOH (max) (mA): -48 Input type: Bipolar Output type: Push-Pull Features: Balanced outputs, Ultra high speed (tpd <5ns) Rating: Military Operating temperature range (°C): -55 to 125 Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 48 Supply current (max) (µA): 14000 IOH (max) (mA): -48 Input type: Bipolar 更多

Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 8 Supply current (max) (µA): 40 IOH (max) (mA): -8 Input type: Standard CMOS Output type: 3-State Rating: Military Operating temperature range (°C): -55 to 125 Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 8 Supply current (max) (µA): 40 IOH (max) (mA): -8 Input type: Standard CMOS Output type: 3-State 更多

Technology family: ABT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 64 Supply current (max) (µA): 250 IOH (max) (mA): -32 Input type: TTL-Compatible CMOS Output type: 3-State Rating: Military Operating temperature range (°C): -55 to 125 Technology family: ABT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 64 Supply current (max) (µA): 250 IOH (max) (mA): -32 Input type: TTL-Compatible CMOS Output type: 3-State 更多

Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 80000 IOH (max) (mA): -15 Input type: Bipolar Output type: 3-State Features: Over-voltage tolerant inputs, Very high speed (tpd 5-10ns) Rating: Military Operating temperature range (°C): -55 to 125 Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 80000 IOH (max) (mA): -15 Input type: Bipolar 更多

Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 8 IOH (max) (mA): -8 Supply current (max) (µA): 20 Input type: Standard CMOS Output type: Push-Pull Rating: Military Operating temperature range (°C): -55 to 125 Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 8 IOH (max) (mA): -8 Supply current (max) (µA): 20 Input type: Standard CMOS Output type: Push-Pull 更多

Technology family: LVT Supply voltage (min) (V): 2.7 Supply voltage (max) (V): 3.6 Number of channels: 8 IOL (max) (mA): 48 Supply current (max) (µA): 5000 IOH (max) (mA): -24 Input type: TTL-Compatible CMOS Output type: 3-State Rating: Military Operating temperature range (°C): -55 to 125 Technology family: LVT Supply voltage (min) (V): 2.7 Supply voltage (max) (V): 3.6 Number of channels: 8 IOL (max) (mA): 48 Supply current (max) (µA): 5000 IOH (max) (mA): -24 Input type: TTL-Compatible CMOS Output type: 3-State 更多
