Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 6 IOL (max) (mA): 5.2 IOH (max) (mA): -5.2 Supply current (max) (µA): 40 Input type: Standard CMOS Output type: Push-Pull Features: Balanced outputs, High speed (tpd 10-50ns), Input clamp diode Rating: Catalog Operating temperature range (°C): -55 to 125 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 6 IOL (max) (mA): 5.2 IOH (max) (mA): -5.2 Supply current (max) (µA): 40 Input type: Standard CMOS 更多

Technology family: LV-A Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 12 IOH (max) (mA): 0 Supply current (max) (µA): 20 Input type: Standard CMOS Output type: Open-drain Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: LV-A Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 12 IOH (max) (mA): 0 Supply current (max) (µA): 20 Input type: Standard CMOS Output type: Open-drain 更多

Technology family: HCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 6 Supply current (max) (µA): 80 IOH (max) (mA): -6 Input type: TTL-Compatible CMOS Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: HCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 6 Supply current (max) (µA): 80 IOH (max) (mA): -6 Input type: TTL-Compatible CMOS Output type: 3-State 更多

Technology family: LV-A Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 16 Supply current (max) (µA): 20 IOH (max) (mA): -16 Input type: Standard CMOS Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: LV-A Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 16 Supply current (max) (µA): 20 IOH (max) (mA): -16 Input type: Standard CMOS Output type: 3-State 更多

Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 8 IOH (max) (mA): 0 Supply current (max) (µA): 20 Input type: Standard CMOS Output type: Open-drain Features: Over-voltage tolerant inputs, Very high speed (tpd 5-10ns) Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: AHC Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 8 IOH (max) (mA): 0 Supply current (max) (µA): 20 Input type: Standard CMOS 更多

Technology family: LV-A Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 16 Supply current (max) (µA): 20 IOH (max) (mA): -16 Input type: Standard CMOS Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: LV-A Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Number of channels: 4 IOL (max) (mA): 16 Supply current (max) (µA): 20 IOH (max) (mA): -16 Input type: Standard CMOS Output type: 3-State 更多

Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 3.6 Number of channels: 8 IOL (max) (mA): 24 Supply current (max) (µA): 40 IOH (max) (mA): -24 Input type: Standard CMOS Output type: 3-State Features: Balanced outputs, Very high speed (tpd 5-10ns) Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 3.6 Number of channels: 8 IOL (max) (mA): 24 Supply current (max) (µA): 40 IOH (max) (mA): -24 Input type: Standard CMOS 更多

Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 6 IOL (max) (mA): 6 Supply current (max) (µA): 80 IOH (max) (mA): -6 Input type: Standard CMOS Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 6 IOL (max) (mA): 6 Supply current (max) (µA): 80 IOH (max) (mA): -6 Input type: Standard CMOS Output type: 3-State 更多

Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 6 IOL (max) (mA): 6 Supply current (max) (µA): 80 IOH (max) (mA): -6 Input type: Standard CMOS Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 6 IOL (max) (mA): 6 Supply current (max) (µA): 80 IOH (max) (mA): -6 Input type: Standard CMOS Output type: 3-State 更多

Technology family: HCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 5.2 IOH (max) (mA): -5.2 Supply current (max) (µA): 40 Input type: Schmitt-Trigger Output type: Push-Pull Features: Balanced outputs, High speed (tpd 10-50ns), Input clamp diode Rating: Catalog Operating temperature range (°C): -55 to 125 Technology family: HCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 6 IOL (max) (mA): 5.2 IOH (max) (mA): -5.2 Supply current (max) (µA): 40 Input type: Schmitt-Trigger 更多
