Technology family: AVC Supply voltage (min) (V): 1.4 Supply voltage (max) (V): 3.6 Number of channels: 16 IOL (max) (mA): 12 Supply current (max) (µA): 40 IOH (max) (mA): -12 Input type: Standard CMOS Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: AVC Supply voltage (min) (V): 1.4 Supply voltage (max) (V): 3.6 Number of channels: 16 IOL (max) (mA): 12 Supply current (max) (µA): 40 IOH (max) (mA): -12 Input type: Standard CMOS Output type: 3-State 更多

Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): -15 Supply current (max) (µA): 75000 Input type: Bipolar Output type: 3-State Features: Ultra high speed (tpd <5ns) Rating: Catalog Operating temperature range (°C): 0 to 70 Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): -15 Supply current (max) (µA): 75000 Input type: Bipolar 更多

Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 24000 IOH (max) (mA): -15 Input type: Bipolar Output type: 3-State Features: Ultra high speed (tpd <5ns) Rating: Catalog Operating temperature range (°C): 0 to 70 Technology family: AS Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 24000 IOH (max) (mA): -15 Input type: Bipolar 更多

Technology family: S Supply voltage (min) (V): 4.75 Supply voltage (max) (V): 5.25 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 160000 IOH (max) (mA): -15 Input type: Bipolar Output type: 3-State Features: Very high speed (tpd 5-10ns) Rating: Catalog Operating temperature range (°C): 0 to 70 Technology family: S Supply voltage (min) (V): 4.75 Supply voltage (max) (V): 5.25 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 160000 IOH (max) (mA): -15 Input type: Bipolar 更多

Technology family: AC Supply voltage (min) (V): 3 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 24 IOH (max) (mA): -24 Supply current (max) (µA): 80 Input type: Standard CMOS Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: AC Supply voltage (min) (V): 3 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 24 IOH (max) (mA): -24 Supply current (max) (µA): 80 Input type: Standard CMOS Output type: 3-State 更多

Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 80000 IOH (max) (mA): -15 Input type: Bipolar Output type: 3-State Features: Over-voltage tolerant inputs, Very high speed (tpd 5-10ns) Rating: Catalog Operating temperature range (°C): 0 to 70 Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 Supply current (max) (µA): 80000 IOH (max) (mA): -15 Input type: Bipolar 更多

Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): 0 Supply current (max) (µA): 86000 Input type: Bipolar Output type: Open-collector Features: High speed (tpd 10-50ns), Over-voltage tolerant inputs Rating: Catalog Operating temperature range (°C): 0 to 70 Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): 0 Supply current (max) (µA): 86000 Input type: Bipolar 更多

Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): -15 Supply current (max) (µA): 21000 Input type: Bipolar Output type: 3-State Features: Over-voltage tolerant inputs, Very high speed (tpd 5-10ns) Rating: Catalog Operating temperature range (°C): 0 to 70 Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): -15 Supply current (max) (µA): 21000 Input type: Bipolar 更多

Technology family: ABT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 12 IOL (max) (mA): 12 IOH (max) (mA): -12 Supply current (max) (µA): 45000 Input type: TTL-Compatible CMOS Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: ABT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 12 IOL (max) (mA): 12 IOH (max) (mA): -12 Supply current (max) (µA): 45000 Input type: TTL-Compatible CMOS Output type: 3-State 更多

Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): -15 Supply current (max) (µA): 71000 Input type: Bipolar Output type: 3-State Features: Over-voltage tolerant inputs, Very high speed (tpd 5-10ns) Rating: Catalog Operating temperature range (°C): 0 to 70 Technology family: BCT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Number of channels: 8 IOL (max) (mA): 64 IOH (max) (mA): -15 Supply current (max) (µA): 71000 Input type: Bipolar 更多
