UC1709


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 40V VDD、热关断功能和 5V 稳压输出的 1.5A/1.5A 双路栅极驱动器

Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40 Features: Thermal shutdown Operating temperature range (°C): -55 to 125 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.025 Input threshold: TTL Channel input logic: Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Dual Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40
Features: Thermal shutdown Operating temperature range (°C): -55 to 125 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.025 Input threshold: TTL Channel input logic: Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Dual

UC3709


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 40V VDD、25ns 传播延迟和 5V 稳压输出的航天级 1.5A/1.5A 双路栅极驱动器

Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40 Features: Thermal shutdown Operating temperature range (°C): 0 to 70 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.025 Input threshold: TTL Channel input logic: Inverting Input negative voltage (V): 0 Rating: Catalog Driver configuration: Dual Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40
Features: Thermal shutdown Operating temperature range (°C): 0 to 70 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.025 Input threshold: TTL Channel input logic: Inverting Input negative voltage (V): 0 Rating: Catalog Driver configuration: Dual

UC1708


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 35V VDD 的 3A/3A 双通道栅极驱动器

Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 3 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 35 Features: Enable pin, Shutdown, Thermal shutdown Operating temperature range (°C): -55 to 125 Rise time (ns): 25 Fall time (ns): 25 Propagation delay time (µs): 0.025 Input threshold: CMOS, TTL Channel input logic: Non-Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Dual Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 3 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 35
Features: Enable pin, Shutdown, Thermal shutdown Operating temperature range (°C): -55 to 125 Rise time (ns): 25 Fall time (ns): 25 Propagation delay time (µs): 0.025 Input threshold: CMOS, TTL Channel input logic: Non-Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Dual

UC3708


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 采用 16 引脚 SOIC 封装、具有 35V VDD 和 25ns 传播延迟的 3A/3A 双路栅极驱动器

Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 3 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 35 Features: Enable pin, Shutdown, Thermal shutdown Operating temperature range (°C): 0 to 70 Rise time (ns): 25 Fall time (ns): 25 Propagation delay time (µs): 0.025 Input threshold: CMOS, TTL Channel input logic: Non-Inverting Input negative voltage (V): 0 Rating: Catalog Undervoltage lockout (typ) (V): 3 Driver configuration: Dual Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 3 Input supply voltage (min) (V): 5
Input supply voltage (max) (V): 35 Features: Enable pin, Shutdown, Thermal shutdown Operating temperature range (°C): 0 to 70 Rise time (ns): 25 Fall time (ns): 25 Propagation delay time (µs): 0.025 Input threshold: CMOS, TTL Channel input logic: Non-Inverting Input negative voltage (V): 0 Rating: Catalog Undervoltage lockout (typ) (V): 3 Driver configuration: Dual

UC1707


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 40V VDD 和输出锁存器的 1.5A/1.5A 双路栅极驱动器

Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40 Features: Analog Shutdown with Optional Latch, Thermal shutdown Operating temperature range (°C): -55 to 125 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Dual Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40
Features: Analog Shutdown with Optional Latch, Thermal shutdown Operating temperature range (°C): -55 to 125 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Dual

UC2950


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 4A 半桥双极开关

Power switch: IGBT, MOSFET Input supply voltage (min) (V): 8 Input supply voltage (max) (V): 35 Peak output current (A): 4 Operating temperature range (°C): -20 to 100 Rating: Catalog Propagation delay time (µs): 0.1 Rise time (ns): 500 Fall time (ns): 500 Iq (mA): 0.5 Input threshold: CMOS, TTL Channel input logic: CMOS, TTL Switch node voltage (V): -3 Driver configuration: Sink/source TTL Power switch: IGBT, MOSFET Input supply voltage (min) (V): 8 Input supply voltage (max) (V): 35 Peak output current (A): 4 Operating temperature range (°C): -20 to 100 Rating: Catalog
Propagation delay time (µs): 0.1 Rise time (ns): 500 Fall time (ns): 500 Iq (mA): 0.5 Input threshold: CMOS, TTL Channel input logic: CMOS, TTL Switch node voltage (V): -3 Driver configuration: Sink/source TTL

UC3707


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 40V VDD、40ns 下降时间和输出锁存器的 1.5A/1.5A 双路栅极驱动器

Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40 Features: Analog Shutdown with Optional Latch, Thermal shutdown Operating temperature range (°C): 0 to 70 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Catalog Driver configuration: Dual Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40
Features: Analog Shutdown with Optional Latch, Thermal shutdown Operating temperature range (°C): 0 to 70 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Catalog Driver configuration: Dual

UC3707M


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 40V VDD 和输出锁存器的军用级 1.5A/1.5A 双路栅极驱动器

Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40 Features: Analog Shutdown with Optional Latch, Thermal shutdown Operating temperature range (°C): 0 to 70 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Dual Number of channels: 2 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40
Features: Analog Shutdown with Optional Latch, Thermal shutdown Operating temperature range (°C): 0 to 70 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Dual

UC1705


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 40V VDD 和输出锁存器的 1.5A/1.5A 单通道栅极驱动器

Number of channels: 1 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40 Features: Thermal shutdown Operating temperature range (°C): -55 to 125 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Complementary Number of channels: 1 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40
Features: Thermal shutdown Operating temperature range (°C): -55 to 125 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Military Driver configuration: Complementary

UC2705


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 采用 8 引脚封装、具有 40V VDD 和 40ns 下降时间的 1.5A/1.5A 双路栅极驱动器

Number of channels: 1 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40 Features: Thermal shutdown Operating temperature range (°C): -40 to 85 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Catalog Driver configuration: Complementary Number of channels: 1 Power switch: IGBT, MOSFET Peak output current (A): 1.5 Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 40
Features: Thermal shutdown Operating temperature range (°C): -40 to 85 Rise time (ns): 40 Fall time (ns): 40 Propagation delay time (µs): 0.1 Input threshold: TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): 0 Rating: Catalog Driver configuration: Complementary
