Number of channels: 1 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.18 Vs (max) (V): 7 Vs (min) (V): 2 Rating: Catalog Iq per channel (typ) (mA): 0.08 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): -40 to 85 Input bias current (±) (max) (nA): 250 VICR (max) (V): 5.5 VICR (min) (V): 0 Number of channels: 1 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.18 Vs (max) (V): 7 Vs (min) (V): 2 Rating: Catalog Iq per channel (typ) (mA): 0.08 更多

Number of channels: 4 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.65 Vs (max) (V): 16 Vs (min) (V): 1.4 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 0.07 Input bias current (±) (max) (nA): 20 Rail-to-rail: In to V- Rating: Catalog Operating temperature range (°C): -40 to 85 VICR (max) (V): 15 VICR (min) (V): 0 Number of channels: 4 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.65 Vs (max) (V): 16 Vs (min) (V): 1.4 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 0.07 更多

Number of channels: 2 Output type: Push-Pull Propagation delay time (µs): 1.1 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.009 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): -55 to 125 Input bias current (±) (max) (nA): 0.03 VICR (max) (V): 15 VICR (min) (V): 0 Number of channels: 2 Output type: Push-Pull Propagation delay time (µs): 1.1 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.009 更多

Number of channels: 4 Output type: Push-Pull Propagation delay time (µs): 1.1 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.009 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): -55 to 125 Input bias current (±) (max) (nA): 0.03 VICR (max) (V): 15 VICR (min) (V): 0 Number of channels: 4 Output type: Push-Pull Propagation delay time (µs): 1.1 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.009 更多

Number of channels: 4 Output type: Open-collector, Open-drain Propagation delay time (µs): 1 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.011 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): -55 to 125 Input bias current (±) (max) (nA): 0.002 VICR (max) (V): 15 VICR (min) (V): 0 Number of channels: 4 Output type: Open-collector, Open-drain Propagation delay time (µs): 1 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.011 更多

Number of channels: 2 Output type: Open-collector, Open-drain Propagation delay time (µs): 1 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.011 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): -40 to 125 Input bias current (±) (max) (nA): 0.002 VICR (max) (V): 15 VICR (min) (V): 0 Number of channels: 2 Output type: Open-collector, Open-drain Propagation delay time (µs): 1 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.011 更多

Number of channels: 2 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.65 Vs (max) (V): 16 Vs (min) (V): 1.4 Rating: Catalog Iq per channel (typ) (mA): 0.07 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): -40 to 85 Input bias current (±) (max) (nA): 20 VICR (max) (V): 15 VICR (min) (V): 0 Number of channels: 2 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.65 Vs (max) (V): 16 Vs (min) (V): 1.4 Rating: Catalog Iq per channel (typ) (mA): 0.07 更多

Number of channels: 2 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.2 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.075 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): -55 to 125 Input bias current (±) (max) (nA): 0.03 VICR (max) (V): 15 VICR (min) (V): 0 Number of channels: 2 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.2 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.075 更多

Number of channels: 4 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.2 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.075 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): -55 to 125 Input bias current (±) (max) (nA): 0.03 VICR (max) (V): 15 VICR (min) (V): 0 Number of channels: 4 Output type: Open-collector, Open-drain Propagation delay time (µs): 0.2 Vs (max) (V): 16 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.075 更多

Number of channels: 2 Output type: Open-collector, Open-drain Propagation delay time (µs): 1.5 Vs (max) (V): 32 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.5 Vos (offset voltage at 25°C) (max) (mV): 5 Rail-to-rail: In to V- Operating temperature range (°C): 0 to 70 Input bias current (±) (max) (nA): 250 VICR (max) (V): 32 VICR (min) (V): 3 Number of channels: 2 Output type: Open-collector, Open-drain Propagation delay time (µs): 1.5 Vs (max) (V): 32 Vs (min) (V): 3 Rating: Catalog Iq per channel (typ) (mA): 0.5 更多
