Technology family: TXU Applications: GPIO Bits (#): 2 Configuration: 1 Ch A to B 1 Ch B to A High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 0 Vout (max) (V): 5.5 Data rate (max) (Mbps): 200 IOH (max) (mA): -12 IOL (max) (mA): -12 Supply current (max) (µA): 5.5 Features: 1.95, 4.6 Input type: Schmitt-Trigger Output type: 3-State Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: TXU Applications: GPIO Bits (#): 2 更多

Technology family: TXU Applications: GPIO Bits (#): 1 Configuration: 1 Ch A to B 0 Ch B to A High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 0 Vout (max) (V): 5.5 Data rate (max) (Mbps): 200 IOH (max) (mA): -12 IOL (max) (mA): -12 Supply current (max) (µA): 5.5 Features: 1.45, 4.2 Input type: Schmitt-Trigger Output type: 3-State Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: TXU Applications: GPIO Bits (#): 1 更多

Technology family: LV-A Applications: GPIO Bits (#): 4 Configuration: 4 Ch A to B 0 Ch B to A High input voltage (min) (V): 1 High input voltage (max) (V): 5.5 Vout (min) (V): 0 Vout (max) (V): 5.5 Data rate (max) (Mbps): 100 IOH (max) (mA): -16 IOL (max) (mA): -16 Supply current (max) (µA): 5.5 Features: 32 Input type: TTL-Compatible CMOS Output type: 3-State, Balanced CMOS Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: LV-A Applications: GPIO Bits (#): 4 更多

Technology family: LXC Applications: GPIO Bits (#): 1 Configuration: 1 Ch A to B 0 Ch B to A High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 0 Vout (max) (V): 5.5 Data rate (max) (Mbps): 420 IOH (max) (mA): 32 IOL (max) (mA): 32 Supply current (max) (µA): 5.5 Features: 4.2 Input type: CMOS, Schmitt-Trigger Output type: Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: LXC Applications: GPIO Bits (#): 1 更多

Technology family: LXC Applications: GPIO Bits (#): 1 High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 1.1 Vout (max) (V): 5.5 Data rate (max) (Mbps): 420 IOH (max) (mA): -32 IOL (max) (mA): 32 Supply current (max) (µA): 4 Input type: Schmitt-Trigger Output type: Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: LXC Applications: GPIO Bits (#): 1 High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 更多

Technology family: TXU Applications: GPIO Bits (#): 1 Configuration: 1 Ch A to B 0 Ch B to A High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 0 Vout (max) (V): 5.5 Data rate (max) (Mbps): 200 IOH (max) (mA): -12 IOL (max) (mA): -12 Supply current (max) (µA): 5.5 Features: .8, 1.45, 4.2, 4.64 Input type: Schmitt-Trigger Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: TXU Applications: GPIO Bits (#): 1 更多

Technology family: TXU Applications: GPIO Bits (#): 2 Configuration: 1 Ch A to B 1 Ch B to A High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 0 Vout (max) (V): 5.5 Data rate (max) (Mbps): 200 IOH (max) (mA): -12 IOL (max) (mA): -12 Supply current (max) (µA): 5.5 Features: 1.08, 1.95, 4.6 Input type: Schmitt-Trigger Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: TXU Applications: GPIO Bits (#): 2 更多

Technology family: TXU Applications: GPIO, JTAG, SPI, UART Bits (#): 2 Configuration: 2 Ch A to B 0 Ch B to A High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 0 Vout (max) (V): 5.5 Data rate (max) (Mbps): 200 IOH (max) (mA): -12 IOL (max) (mA): -12 Supply current (max) (µA): 5.5 Features: 1.08, 1.95, 4.6 Input type: Schmitt-Trigger Output type: 3-State Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: TXU Applications: GPIO, JTAG, SPI, UART Bits (#): 2 更多

Technology family: LXC Applications: GPIO Bits (#): 1 High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 1.1 Vout (max) (V): 5.5 Data rate (max) (Mbps): 420 IOH (max) (mA): -32 IOL (max) (mA): 32 Supply current (max) (µA): 4 Input type: Schmitt-Trigger Output type: Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: LXC Applications: GPIO Bits (#): 1 High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 更多

Technology family: LXC Applications: GPIO, JTAG, UART Bits (#): 2 High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 Vout (min) (V): 1.1 Vout (max) (V): 5.5 Data rate (max) (Mbps): 420 IOH (max) (mA): -32 IOL (max) (mA): 32 Supply current (max) (µA): 6 Input type: Schmitt-Trigger Output type: Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: LXC Applications: GPIO, JTAG, UART Bits (#): 2 High input voltage (min) (V): 0.44 High input voltage (max) (V): 5.5 更多
