GPIOs: 20.0
Family: AIROC™ Bluetooth Modules
ADC (#, Max. Resolution @ Sample Rate): SD(1,12-bit ENoB (audio), 10-bit ENoB (DC), 12MHz clock)
CapSense: No
Flash: 256.0kByte
I2C: 1
SPI: 2
SRAM: 176.0kByte
UART: 2
PWM: 6
Main CPU Core: Arm® Cortex®- M4
Secondary CPU Core: None
CPU Core: 96MHz
Bluetooth LE: Yes
Bluetooth Classic: Yes
PDM: 1
Type of Antenna: External - RF pad
Extended Range: Yes
Bluetooth LE Data rate: 2.0MByte/s
Bluetooth EDR 2MBPS RX SENSITIVITY: -93.5dBm
更多
Bluetooth LE RX Sensitivity: - 95.0 dBm
Bluetooth LE TX Power: 15dBm
Bluetooth EDR 2Mbps TX POWER: 15dBm
ROM: 1MB
V max: 3.3V
Operational Amplifier: No
Operating Temperature max: 85.0°C
Pads: 35.0
Size (X mm x Y mm x Z mm): 12.5 × 19 × 1.85 mm
Base Silicon: CYW20819
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2018
Currently planned availability until at least: 31-03-2033
GPIOs: 16.0
Family: AIROC™ Bluetooth Modules
ADC (#, Max. Resolution @ Sample Rate): SAR (1, 12-bit @ 1 msps)
CapSense: Yes
Flash: 128.0kByte
I2C: Configurable
Serial Communication Blocks: 5.0
SPI: Configurable
SRAM: 16.0kByte
UART: Configurable
PWM: 4
Main CPU Core: Arm® Cortex®- M0
Secondary CPU Core: None
CPU Core: 48MHz
Bluetooth LE: Yes
Bluetooth Classic: No
PDM: Configurable
Type of Antenna: Chip antenna
Extended Range: No
Bluetooth LE Data rate: 1.0MByte/s
更多
Bluetooth EDR 2MBPS RX SENSITIVITY: N/A
Bluetooth LE RX Sensitivity: -85dBm
Bluetooth LE TX Power: 3dBm
Bluetooth EDR 2Mbps TX POWER: N/A
V max: 5.5V
Operational Amplifier: Yes
Operating Temperature max: 85.0°C
Pads: 21.0
Size (X mm x Y mm x Z mm): 10 x 10 x 1.80 mm
Base Silicon: PSoC™ 4 MCU with AIROC™ Bluetooth® LE
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-12-2009
Currently planned availability until at least: 31-12-2024
GPIOs: 23.0
Family: AIROC™ Bluetooth Modules
ADC (#, Max. Resolution @ Sample Rate): SAR (1, 12-bit @ 1 msps)
CapSense: Yes
Flash: 128.0kByte
I2C: Configurable
Serial Communication Blocks: 5.0
SPI: Configurable
SRAM: 16.0kByte
UART: Configurable
PWM: 4
Main CPU Core: Arm® Cortex®- M0
Secondary CPU Core: None
CPU Core: 48MHz
Bluetooth LE: Yes
Bluetooth Classic: No
PDM: Configurable
Type of Antenna: PCB trace antenna
Extended Range: No
Bluetooth LE Data rate: 1.0MByte/s
更多
Bluetooth EDR 2MBPS RX SENSITIVITY: N/A
Bluetooth LE RX Sensitivity: - 93 dBm
Bluetooth LE TX Power: 3dBm
Bluetooth EDR 2Mbps TX POWER: N/A
V max: 5.5V
Operational Amplifier: Yes
Operating Temperature max: 85.0°C
Pads: 31.0
Size (X mm x Y mm x Z mm): 14 x 19 x 2.00 mm
Base Silicon: PSoC™ 4-BLE
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-12-2009
Currently planned availability until at least: 31-12-2024
GPIOs: 25.0
Family: AIROC™ Bluetooth Modules
ADC (#, Max. Resolution @ Sample Rate): SAR (1, 12-bit @ 1 msps)
CapSense: Yes
Flash: 128.0kByte
I2C: Configurable
Serial Communication Blocks: 5.0
SPI: Configurable
SRAM: 16.0kByte
UART: Configurable
PWM: 4
Main CPU Core: Arm® Cortex®- M0
Secondary CPU Core: None
CPU Core: 48MHz
Bluetooth LE: Yes
Bluetooth Classic: No
PDM: Configurable
Type of Antenna: PCB trace antenna
Extended Range: No
Bluetooth LE Data rate: 1.0MByte/s
更多
Bluetooth EDR 2MBPS RX SENSITIVITY: N/A
Bluetooth LE RX Sensitivity: -87dBm
Bluetooth LE TX Power: 3dBm
Bluetooth EDR 2Mbps TX POWER: N/A
V max: 5.5V
Operational Amplifier: Yes
Operating Temperature max: 85.0°C
Pads: 32.0
Size (X mm x Y mm x Z mm): 11 x 11 x 1.70 mm
Base Silicon: PSoC™ 4-BLE
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-12-2009
Currently planned availability until at least: 31-12-2024
GPIOs: 22.0
Family: AIROC™ Bluetooth Modules
ADC (#, Max. Resolution @ Sample Rate): SD(1,12-bit ENoB (audio), 10-bit ENoB (DC), 12MHz clock)
CapSense: No
Flash: 256.0kByte
I2C: 1
SPI: 2
SRAM: 176.0kByte
UART: 2
PWM: 6
Main CPU Core: Arm® Cortex®- M4
Secondary CPU Core: None
CPU Core: 96MHz
Bluetooth LE: Yes
Bluetooth Classic: Yes
PDM: 1
Type of Antenna: PCB trace antenna
Extended Range: No
Bluetooth LE Data rate: 2.0MByte/s
Bluetooth EDR 2MBPS RX SENSITIVITY: –94.0 dBm
更多
Bluetooth LE RX Sensitivity: - 94.5 dBm
Bluetooth LE TX Power: 10.5 dBm
Bluetooth EDR 2Mbps TX POWER: 0 dBm
ROM: 1MB
V max: 3.3V
Operational Amplifier: No
Operating Temperature max: 85.0°C
Pads: 35.0
Size (X mm x Y mm x Z mm): 12 x 16.61 x 1.70 mm
Base Silicon: CYW20820
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2018
Currently planned availability until at least: 31-03-2033
Bluetooth Specification: Bluetooth 5.3
CPU: N/A
Family: AIROC™ Wi-Fi + Bluetooth® Combos
Operating Temperature max: 85.0°C
Wi-Fi Specification: Wi-Fi 5 (802.11ac)
Product Description: Wi-Fi 5 combo
Replacement: CYW4373
Antenna Configuration: 1x1
Bluetooth Interface: UART/PCM
Memory: N/A
WI-FI Interface: SDIO
Operating system support: Linux, RTOS
Wi-Fi Band: 2.4GHz, 5GHz
Partner Module: Y
Core: Cortex M3
SRAM: 270.0kByte
ROM: 845 KB
Package: WLCSP-140
Dimensions: 4.47 × 5.27 mm
Pitch: 0.4mm
更多
GPIOs: 15.0
Operating Voltage max: 5.25V
Antenna Configuration: 1x1
Bluetooth Interface: UART/PCM
Family: AIROC™ Wi-Fi + Bluetooth® Combos
Memory: N/A
Operating Temperature max: 70.0°C
Operating system support: Linux, Android, RTOS
Partner Module: Y
Product Description: Ultra-low power Wi-Fi 5
Software Support: ModusToolbox™
WI-FI Interface: SDIO/SPI
Wi-Fi Band: 2.4GHz, 5GHz
Wi-Fi Specification: Wi-Fi 5 (802.11ac)
Bluetooth Specification: Bluetooth 5.4
Launch Date: 2024
Longevity - 15 years: Yes
Longevity - Extended: No
Core: Cortex M4
SRAM: 388.0kByte
ROM: 1152 KB
Package: WLBGA-106
更多
Package: WLCSP-251
Dimensions: 3.76 x 4.43 mm
Dimensions: 3.76 x 4.43 mm
Pitch: 0.35mm
Pitch: 0.2mm
GPIOs: 7.0
GPIOs: 16.0
Operating Voltage max: 4.6V
Currently planned availability until at least: 01-01-2039
CPU: N/A
Family: AIROC™ Wi-Fi + Bluetooth® Combos
Operating Temperature max: 85.0°C
Wi-Fi Specification: Wi-Fi 5 (802.11ac)
Product Description: Wi-Fi 5 combo
Antenna Configuration: 1x1
Bluetooth Interface: UART/PCM
Memory: N/A
WI-FI Interface: SDIO/SPI/PCIe/USB
Wi-Fi Band: 2.4GHz, 5GHz
Software Support: ModusToolbox™
Operating system support: Linux, Android, RTOS
Partner Module: Y
Bluetooth Specification: Bluetooth 5.4
Launch Date: 2018
Longevity - 15 years: Yes
Longevity - Extended: No
Core: Cortex M3
Dimensions: 5.43 x 4.51 mm
SRAM: 384.0kByte
更多
ROM: 1088 KB
Package: WLCSP-128
Pitch: 0.4mm
GPIOs: 10.0
Operating Voltage max: 4.8V
Currently planned availability until at least: 01-09-2033
Wi-Fi PHY Data Rate((MBit/s)): upto 96Mbps
CPU: N/A
Family: AIROC™ Wi-Fi + Bluetooth® Combos
Wi-Fi Specification: Wi-Fi 4 (802.11n)
Product Description: Wi-Fi 4 combo
Antenna Configuration: 1x1
Bluetooth Interface: UART/PCM/SDIO
Memory: N/A
WI-FI Interface: SDIO/SPI
Operating system support: Linux, RTOS
Software Support: ModusToolbox™
Partner Module: Y
Bluetooth Specification: Bluetooth 5.4
Launch Date: N/A
Longevity - 15 years: No
Currently planned availability until at least: N/A
Wi-Fi Band: 2.4GHz
Longevity - Extended: No
Core: Cortex M3
Dimensions: 4.87 x 2.87 mm
更多
SRAM: 160.0kByte
ROM: 576 KB
Package: WLBGA-63
Pitch: 0.4mm
GPIOs: 5.0
Operating Voltage max: 4.8V
Operating Temperature max: 85.0°C
GPIOs: 5.0
Partner Module: Y
Software Support: WICED
Wi-Fi PHY Data Rate((MBit/s)): upto 96Mbps
Interfaces: SDIO 2.0, gSPI
Bluetooth Specification: N/A
CPU: N/A
Family: AIROC™ Wi-Fi + Bluetooth® Combos
Wi-Fi Specification: Wi-Fi 4 (802.11n)
Product Description: Wi-Fi 4 combo
Replacement: CYW43439
Antenna Configuration: 1x1
Bluetooth Interface: N/A
Memory: N/A
WI-FI Interface: SDIO/SPI
Operating system support: Linux, RTOS
Wi-Fi Band: 2.4GHz
Operating Temperature max: 70.0°C
Core: Cortex M3
Dimensions: 4.87 x 2.87 mm
更多
SRAM: 512.0kByte
ROM: 640 KB
Pitch: 0.4mm
Operating Voltage max: 4.6V
