ISOM8113

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 375% 至 560% CTR 的直流输入、晶体管输出、单通道光耦仿真器

Rating: Catalog Product type: Analog transistor output Input type: DC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 375 Current transfer ratio (CTR) (max) (%): 560 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500, 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.44, 0.44 Turnoff time (disable) (µs): 2.7, 2.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Catalog Product type: Analog transistor output Input type: DC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 375 Current transfer ratio (CTR) (max) (%): 560 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500, 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.44, 0.44 Turnoff time (disable) (µs): 2.7, 2.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8113-Q1

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 375% 至 560% CTR 的汽车级、直流输入、晶体管输出、单通道光耦仿真器

Rating: Automotive Product type: Analog transistor output Input type: DC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 375 Current transfer ratio (CTR) (max) (%): 560 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.44 Turnoff time (disable) (µs): 2.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Automotive Product type: Analog transistor output Input type: DC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 375 Current transfer ratio (CTR) (max) (%): 560 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.44 Turnoff time (disable) (µs): 2.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8115-Q1

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 100% 至 155% CTR 的汽车级、交流输入、晶体管输出、单通道光耦仿真器

Rating: Automotive Product type: Analog transistor output Input type: AC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 100 Current transfer ratio (CTR) (max) (%): 155 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.62 Turnoff time (disable) (µs): 3.6 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Automotive Product type: Analog transistor output Input type: AC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 100 Current transfer ratio (CTR) (max) (%): 155 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.62 Turnoff time (disable) (µs): 3.6 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8116-Q1

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 150% 至 230% CTR 的汽车级、交流输入、晶体管输出、单通道光耦仿真器

Rating: Automotive Product type: Analog transistor output Input type: AC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 150 Current transfer ratio (CTR) (max) (%): 230 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.56 Turnoff time (disable) (µs): 3.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Automotive Product type: Analog transistor output Input type: AC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 150 Current transfer ratio (CTR) (max) (%): 230 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.56 Turnoff time (disable) (µs): 3.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8117-Q1

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 255% 至 380% CTR 的汽车级、交流输入、晶体管输出、单通道光耦仿真器

Rating: Automotive Product type: Analog transistor output Input type: AC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 255 Current transfer ratio (CTR) (max) (%): 380 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.48 Turnoff time (disable) (µs): 3.1 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Automotive Product type: Analog transistor output Input type: AC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 255 Current transfer ratio (CTR) (max) (%): 380 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.48 Turnoff time (disable) (µs): 3.1 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8118-Q1

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 375% 至 560% CTR 的汽车级、交流输入、晶体管输出、单通道光耦仿真器

Rating: Automotive Product type: Analog transistor output Input type: AC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 375 Current transfer ratio (CTR) (max) (%): 560 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.44 Turnoff time (disable) (µs): 2.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Automotive Product type: Analog transistor output Input type: AC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 375 Current transfer ratio (CTR) (max) (%): 560 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 20 Forward current (IF) (min) (µA): 700 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -40 to 125 Turnon time (enable) (µs): 0.44 Turnoff time (disable) (µs): 2.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8115

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 100% 至 155% CTR 的交流输入、晶体管输出、单通道光耦仿真器

Rating: Catalog Product type: Analog transistor output Input type: AC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 100 Current transfer ratio (CTR) (max) (%): 155 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.62 Turnoff time (disable) (µs): 3.6 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Catalog Product type: Analog transistor output Input type: AC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 100 Current transfer ratio (CTR) (max) (%): 155 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.62 Turnoff time (disable) (µs): 3.6 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8116

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 150% 至 230% CTR 的交流输入、晶体管输出、单通道光耦仿真器

Rating: Catalog Product type: Analog transistor output Input type: AC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 150 Current transfer ratio (CTR) (max) (%): 230 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500, 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.56, 0.56 Turnoff time (disable) (µs): 3.7, 3.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Catalog Product type: Analog transistor output Input type: AC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 150 Current transfer ratio (CTR) (max) (%): 230 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500, 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.56, 0.56 Turnoff time (disable) (µs): 3.7, 3.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8117

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 255% 至 380% CTR 的交流输入、晶体管输出、单通道光耦仿真器

Rating: Catalog Product type: Analog transistor output Input type: AC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 255 Current transfer ratio (CTR) (max) (%): 380 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500, 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.48, 0.48 Turnoff time (disable) (µs): 3.1, 3.1 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Catalog Product type: Analog transistor output Input type: AC 更多

Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 255 Current transfer ratio (CTR) (max) (%): 380 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500, 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.48, 0.48 Turnoff time (disable) (µs): 3.1, 3.1 Creepage (min) (mm): 5 Clearance (min) (mm): 5

ISOM8118

数据:
分类: 光电子器件 / 光电耦合器件 / 其他光电耦合器件

描述: 具有 375% 至 560% CTR 的交流输入、晶体管输出、单通道光耦仿真器

Rating: Catalog Product type: Analog transistor output Input type: AC Output type: Analog transistor Withstand isolation voltage (VISO) (Vrms): 3750 Number of channels: 1 Current transfer ratio (CTR) (min) (%): 375 Current transfer ratio (CTR) (max) (%): 560 Forward voltage (typ) (V): 1.2 Forward current (IF) (max) (mA): 50 Forward current (IF) (min) (µA): 500, 500 Data rate (max) (Mbps): 0.1 Operating temperature range (°C): -55 to 125 Turnon time (enable) (µs): 0.44, 0.44 Turnoff time (disable) (µs): 2.7, 2.7 Creepage (min) (mm): 5 Clearance (min) (mm): 5 Rating: Catalog Product type: Analog transistor output Input type: AC 更多
