DLP3010LC

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: 0.3-inch 720p DLP® digital micromirror device (DMD)

Illumination wavelength (min) (nm): 420 Illumination wavelength (max) (nm): 700 Micromirror array size: 1280 x 720 Chipset family: DLP3010LC, DLPA2000, DLPA2005, DLPA3000, DLPA3005, DLPC3478 Micromirror pitch (mm): 0.0054 Component type: DMD Micromirror array orientation: Orthogonal Pattern rate, binary (max) (Hz): 2487 Array diagonal (in): 0.3 Display resolution (max): 720p (1280x720) Rating: Catalog Pattern rate, 8-bit (max) (Hz): 272 Micromirror driver support: Integrated Thermal dissipation (°C/W): 5.4 Input frame rate (Hz): 120 Operating temperature range (°C): 0 to 70 Illumination wavelength (min) (nm): 420 Illumination wavelength (max) (nm): 700 Micromirror array size: 1280 x 720 Chipset family: DLP3010LC, DLPA2000, DLPA2005, DLPA3000, DLPA3005, DLPC3478 更多

Micromirror pitch (mm): 0.0054 Component type: DMD Micromirror array orientation: Orthogonal Pattern rate, binary (max) (Hz): 2487 Array diagonal (in): 0.3 Display resolution (max): 720p (1280x720) Rating: Catalog Pattern rate, 8-bit (max) (Hz): 272 Micromirror driver support: Integrated Thermal dissipation (°C/W): 5.4 Input frame rate (Hz): 120 Operating temperature range (°C): 0 to 70

DLP9000XUV

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: 0.9-inch WQXGA high-speed UV DLP® digital micromirror device (DMD)

Illumination wavelength (min) (nm): 355 Illumination wavelength (max) (nm): 420 Micromirror array size: 2560 x 1600 Chipset family: DLP9000XUV, DLPC910, DLPR910 Pattern rate, binary (max) (Hz): 14989 Pixel data rate (max) (Gbpp): 61.1 Micromirror pitch (mm): 0.0076 Component type: DMD Rating: Catalog Display resolution (max): 2560 x 1600 (WQXGA), WQXGA (2560x1600) Pattern rate, 8-bit (max) (Hz): 1873 Micromirror array orientation: Orthogonal Micromirror driver support: Integrated Thermal dissipation (°C/W): 0.5 Operating temperature range (°C): 20 to 30 Illumination wavelength (min) (nm): 355 Illumination wavelength (max) (nm): 420 Micromirror array size: 2560 x 1600 Chipset family: DLP9000XUV, DLPC910, DLPR910 Pattern rate, binary (max) (Hz): 14989 更多

Pixel data rate (max) (Gbpp): 61.1 Micromirror pitch (mm): 0.0076 Component type: DMD Rating: Catalog Display resolution (max): 2560 x 1600 (WQXGA), WQXGA (2560x1600) Pattern rate, 8-bit (max) (Hz): 1873 Micromirror array orientation: Orthogonal Micromirror driver support: Integrated Thermal dissipation (°C/W): 0.5 Operating temperature range (°C): 20 to 30

DLP5534-Q1

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: DLP® 汽车级 0.55 英寸 405nm 数字微镜器件 (DMD)

Array diagonal (in): 0.55 Display resolution (max): 1152 x 576 Component type: DMD Chipset family: DLP5534-Q1 Rating: Automotive Input frame rate (max) (Hz): 60 Micromirror pitch (mm): 0.0076 Operating temperature range (°C): -40 to 105 Array diagonal (in): 0.55 Display resolution (max): 1152 x 576 Component type: DMD Chipset family: DLP5534-Q1 Rating: Automotive Input frame rate (max) (Hz): 60 Micromirror pitch (mm): 0.0076 Operating temperature range (°C): -40 to 105

DLP3034-Q1

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: DLP® 汽车级 0.3 英寸 405nm 数字微镜器件 (DMD)

Array diagonal (in): 0.3 Display resolution (max): 864 x 480 Component type: DMD Chipset family: DLP3034-Q1 Rating: Automotive Input frame rate (max) (Hz): 60 Micromirror pitch (mm): 0.0076 Operating temperature range (°C): -40 to 105 Array diagonal (in): 0.3 Display resolution (max): 864 x 480 Component type: DMD Chipset family: DLP3034-Q1 Rating: Automotive Input frame rate (max) (Hz): 60 Micromirror pitch (mm): 0.0076 Operating temperature range (°C): -40 to 105

DLP2000

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: 0.20 英寸 nHD DLP® 数字微镜器件 (DMD)

Component type: DMD Display resolution (max): nHD (640x360) System brightness (max) (lm): 50 Array diagonal (in): 0.2 Chipset family: DLP2000, DLPA1000, DLPC2607 Micromirror array size: 640x360 Input frame rate (max) (Hz): 120 Micromirror pitch (mm): 0.0076 Rating: Catalog Operating temperature range (°C): 0 to 70 Component type: DMD Display resolution (max): nHD (640x360) System brightness (max) (lm): 50 Array diagonal (in): 0.2 Chipset family: DLP2000, DLPA1000, DLPC2607 Micromirror array size: 640x360 Input frame rate (max) (Hz): 120 Micromirror pitch (mm): 0.0076 Rating: Catalog Operating temperature range (°C): 0 to 70

DLP230NP

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: 0.23 英寸 1080p DLP® 数字微镜器件 (DMD)

Component type: DMD Display resolution (max): 1080p (1920x1080) System brightness (max) (lm): 450 Array diagonal (in): 0.23 Chipset family: DLP230NP, DLPA2000, DLPA2005, DLPA3000, DLPC3436 Micromirror array size: 960x540 Input frame rate (max) (Hz): 60 Micromirror pitch (mm): 0.0054 Rating: Catalog Operating temperature range (°C): 0 to 70 Component type: DMD Display resolution (max): 1080p (1920x1080) System brightness (max) (lm): 450 Array diagonal (in): 0.23 Chipset family: DLP230NP, DLPA2000, DLPA2005, DLPA3000, DLPC3436 Micromirror array size: 960x540 Input frame rate (max) (Hz): 60 Micromirror pitch (mm): 0.0054 Rating: Catalog Operating temperature range (°C): 0 to 70

DLPC3436

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: 适用于 DLP230NP (0.23 1080p) DMD 的 DLP® 显示控制器

Component type: Display Controller Display resolution (max): 1080p (1920x1080) System brightness (max) (lm): 400 Chipset family: DLP230NP, DLPA2000, DLPA2005, DLPA3000, DLPC3436 Input frame rate (max) (Hz): 60 Rating: Catalog Video ports: 24-bit RGB, Parallel Operating temperature range (°C): -30 to 85 Component type: Display Controller Display resolution (max): 1080p (1920x1080) System brightness (max) (lm): 400 Chipset family: DLP230NP, DLPA2000, DLPA2005, DLPA3000, DLPC3436 Input frame rate (max) (Hz): 60 Rating: Catalog Video ports: 24-bit RGB, Parallel Operating temperature range (°C): -30 to 85

DLP470NE

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: 0.47 英寸 1080p 2xLVDS DLP® 数字微镜器件 (DMD)

Component type: DMD Display resolution (max): 1080p (1920x1080) System brightness (max) (lm): 5500 Chipset family: DLPC4430 Array diagonal (in): 0.47 Input frame rate (max) (Hz): 120 Rating: Catalog Micromirror array size: 1920x1080 Micromirror pitch (mm): 0.0054 Operating temperature range (°C): 0 to 70 Component type: DMD Display resolution (max): 1080p (1920x1080) System brightness (max) (lm): 5500 Chipset family: DLPC4430 Array diagonal (in): 0.47 Input frame rate (max) (Hz): 120 Rating: Catalog Micromirror array size: 1920x1080 Micromirror pitch (mm): 0.0054 Operating temperature range (°C): 0 to 70

DLP470TE

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: 0.47 英寸 4K UHD 2XLVDS DLP® 数字微镜器件 (DMD)

Component type: DMD Display resolution (max): 4K UHD (3840x2160) System brightness (max) (lm): 5500 Chipset family: DLPC4420 Array diagonal (in): 0.47 Input frame rate (max) (Hz): 60 Rating: Catalog Micromirror array size: 1920x1080 Micromirror pitch (mm): 0.0054 Operating temperature range (°C): 0 to 70 Component type: DMD Display resolution (max): 4K UHD (3840x2160) System brightness (max) (lm): 5500 Chipset family: DLPC4420 Array diagonal (in): 0.47 Input frame rate (max) (Hz): 60 Rating: Catalog Micromirror array size: 1920x1080 Micromirror pitch (mm): 0.0054 Operating temperature range (°C): 0 to 70

DLPC3479

数据:
分类: 光电子器件 / 电子显示器件及组件 / 其他电子显示器件及组件

描述: DLP® controller for DLP4710LC digital micromirror device (DMD)

Chipset family: DLP4710LC, DLPC3479 Component type: Controller Pattern rate, binary (max) (Hz): 2487 Display resolution (max): 1080p (1920x1080) Rating: Catalog Pattern rate, 8-bit (max) (Hz): 437 Micromirror driver support: Integrated Input frame rate (Hz): 60 Operating temperature range (°C): -30 to 85 Chipset family: DLP4710LC, DLPC3479 Component type: Controller Pattern rate, binary (max) (Hz): 2487 Display resolution (max): 1080p (1920x1080) Rating: Catalog Pattern rate, 8-bit (max) (Hz): 437 Micromirror driver support: Integrated Input frame rate (Hz): 60 Operating temperature range (°C): -30 to 85
