INFINEON
Infineon 英飞凌专注于迎接现代社会的三大科技挑战： 高能效、 移动性和 安全性，为汽车和工业功率器件、芯片卡和安全应用提供半导体和系统解决方案。英飞凌的产品素以高可靠性、卓越质量和创新性著称，并在模拟和混合信号、射频、功率以及嵌入式控制装置领域掌握尖端技术。
Input Vcc: NoneV
Channels: 2.0
Configuration: Low-side
Voltage Class: 25.0V
Qualification: Industrial
Isolation Type: Non-isolated
Output Current(Sink): 3.3A
Output Current(Source): 2.3A
Turn Off Propagation Delay: 50.0ns
Turn On Propagation Delay: 50.0ns
IR2111
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器数据:
简介: 600 V half-bridge gate driver IC with shoot through protection
Input Vcc: NoneV
Channels: 2.0
Configuration: Half Bridge
Voltage Class: 600.0V
Qualification: Industrial
Isolation Type: Functional levelshift
Output Current(Source): 0.25A
Output Current(Sink): 0.5A
Turn Off Propagation Delay: 150.0ns
Turn On Propagation Delay: 750.0ns
VCC UVLO(Off): 8.2V
VCC UVLO(On): 8.6V
VBS UVLO(Off): 8.2V
VBS UVLO(On): 8.6V
IR2113
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器数据:
简介: 600 V high-side and low-side gate driver IC with shutdown
Input Vcc: NoneV
Channels: 2.0
Configuration: High-side and low-side
Voltage Class: 600.0V
Qualification: Industrial
Isolation Type: Functional levelshift
Output Current(Sink): 2.5A
Output Current(Source): 2.5A
Turn Off Propagation Delay: 94.0ns
Turn On Propagation Delay: 120.0ns
VCC UVLO(Off): 8.2V
VCC UVLO(On): 8.5V
VBS UVLO(Off): 8.2V
VBS UVLO(On): 8.6V
Input Vcc: NoneV
Channels: 2.0
Configuration: Half Bridge
Voltage Class: 600.0V
Qualification: Industrial
Isolation Type: Functional levelshift
Output Current(Source): 1.9A
Output Current(Sink): 2.3A
Turn Off Propagation Delay: 270.0ns
Turn On Propagation Delay: 680.0ns
VCC UVLO(Off): 8.2V
VCC UVLO(On): 8.9V
VBS UVLO(Off): 8.2V
VBS UVLO(On): 8.9V
Isolation Type: Functional levelshift
Input Vcc: NoneV
Channels: 2.0
Configuration: Half Bridge
Voltage Class: 600.0V
Qualification: Industrial
Output Current(Sink): 0.26A
Output Current(Source): 0.18A
VCC UVLO(Off): 8.0V
VCC UVLO(On): 9.0V
Input Vcc: NoneV
Channels: 2.0
Configuration: High-side and low-side
Voltage Class: 200.0V
Qualification: Industrial
Isolation Type: Functional levelshift
Output Current(Source): 0.29A
Output Current(Sink): 0.6A
Turn Off Propagation Delay: 150.0ns
Turn On Propagation Delay: 160.0ns
VCC UVLO(Off): 8.2V
VCC UVLO(On): 8.9V
Input Vcc: NoneV
Channels: 2.0
Configuration: Half Bridge
Voltage Class: 200.0V
Qualification: Industrial
Isolation Type: Functional levelshift
Output Current(Source): 0.29A
Output Current(Sink): 0.6A
Turn Off Propagation Delay: 150.0ns
Turn On Propagation Delay: 680.0ns
VCC UVLO(Off): 8.2V
VCC UVLO(On): 8.9V
Input Vcc: NoneV
Channels: 2.0
Configuration: Half Bridge
Voltage Class: 200.0V
Qualification: Industrial
Isolation Type: Functional levelshift
Output Current(Source): 0.29A
Output Current(Sink): 0.6A
Turn Off Propagation Delay: 150.0ns
Turn On Propagation Delay: 680.0ns
VCC UVLO(Off): 8.2V
VCC UVLO(On): 8.9V
IR2110
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器数据:
简介: 500 V high-side and low-side gate driver IC with shutdown
Input Vcc: NoneV
Channels: 2.0
Configuration: High-side and low-side
Voltage Class: 500.0V
Qualification: Industrial
Isolation Type: Functional levelshift
Output Current(Sink): 2.5A
Output Current(Source): 2.5A
Turn Off Propagation Delay: 94.0ns
Turn On Propagation Delay: 120.0ns
VCC UVLO(Off): 8.2V
VCC UVLO(On): 8.5V
VBS UVLO(Off): 8.2V
VBS UVLO(On): 8.6V
1EDF5673K
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器数据:
简介: GaN EiceDRIVER™ gate driver IC with excellent robustness and efficiency, the perfect fit to drive gallium nitride (GaN) HEMTs
Channels: 1.0
Configuration: High-side
Qualification: Industrial
Isolation Type: Galvanic isolation - Functional
Package: PG-TFLGA-13
Input Vcc: NoneV
Voltage Class: 650.0V
Output Current(Source): 4.0A
Output Current(Sink): 8.0A
Turn Off Propagation Delay: 41.0ns
Turn On Propagation Delay: 37.0ns
VCC UVLO(Off): 2.7V
VCC UVLO(On): 2.85V
VBS UVLO(Off): 5.2V
VBS UVLO(On): 5.8V
