INFINEON
Infineon 英飞凌专注于迎接现代社会的三大科技挑战： 高能效、 移动性和 安全性，为汽车和工业功率器件、芯片卡和安全应用提供半导体和系统解决方案。英飞凌的产品素以高可靠性、卓越质量和创新性著称，并在模拟和混合信号、射频、功率以及嵌入式控制装置领域掌握尖端技术。
V[DS] max: 800.0V
V[CC] max: 25.0V
t[r]: 30.0ns
t[f]: 30.0ns
I[CC]: 5.7mA
ESD Protection max: 2.0kV
Operating Temperature max: 130.0°C
Package: PG-DIP-7
Frequency Range: 100kHz fixed
Green Product: Yes
Switching Frequency: 100.0kHz
Topology: Flyback
R[DS (on)] max: 1.71Ω
P[out] max: 26.0W
Type: PWM controller with integrated MOSFET
Technology: Gen3R
Target Application: Power Supplies
Sub Application: Offline SMPS
Mounting: THD
Budgetary Price €/1k: 1.02
ESD Protection max: 2.0kV
Frequency Range: 100kHz fixed
Green Product: Yes
I[CC]: 5.7mA
Operating Temperature max: 130.0°C
Package: PG-DSO-12
R[DS (on)] max: 1.11Ω
V[CC] max: 25.0V
V[DS] max: 800.0V
t[f]: 30.0ns
t[r]: 30.0ns
Switching Frequency: 100.0kHz
Topology: Flyback
P[out] max: 30.0W
Type: PWM controller with integrated MOSFET
Technology: Gen3R
Target Application: Power Supplies
Sub Application: Offline SMPS
Mounting: SMD
Budgetary Price €/1k: 1.08
V[DS] max: 800.0V
R[DS (on)] max: 2.62Ω
t[r]: 30.0ns
t[f]: 30.0ns
V[CC] max: 25.0V
I[CC]: 3.1mA
ESD Protection max: 2.0kV
Operating Temperature max: 130.0°C
Package: PG-DIP-7
Frequency Range: 65kHz fixed
Green Product: Yes
Topology: Flyback
Switching Frequency: 65.0kHz
P[out] max: 21.0W
Technology: Gen3R
Type: PWM controller with integrated MOSFET
Target Application: Power Supplies
Sub Application: Offline SMPS
Mounting: THD
Budgetary Price €/1k: 0.91
ICE5BR4780BZ
分类:数据:
简介: 65 kHz offline flyback and buck regulator with integrated 800 V CoolMOS™ superjunction MOSFET
ESD Protection max: 2.0kV
Green Product: Yes
I[CC]: 0.9mA
Operating Temperature max: 129.0°C
Package: PG-DIP-7
P[out] max: 15.0W
R[DS (on)] max: 4.85Ω
Sub Application: Offline SMPS
Switching Frequency: 65.0kHz
Technology: Gen5
V[DS] max: 800.0V
Topology: Flyback
Topology: Non-isolated flyback
Topology: Buck
Type: PWM controller with integrated MOSFET
V[CC] max: 24.0V
Target Application: Power Supplies
Target Application: Industrial
Target Application: Consumer
Target Application: Home appliances
更多
Target Application: SMPS
Mounting: THD
ESD Protection max: 2.0kV
Green Product: Yes
I[CC]: 0.9mA
Operating Temperature max: 129.0°C
P[out] max: 15.0W
Package: PG-DIP-7
R[DS (on)] max: 5.18Ω
Sub Application: Offline SMPS
Switching Frequency: 100.0kHz
Target Application: Power Supplies
Technology: Gen5
Topology: Flyback
Topology: Non-isolated flyback
Type: PWM controller with integrated MOSFET
V[CC] max: 24.0V
V[DS] max: 700.0V
Target Application: Consumer
Target Application: SMPS
Mounting: THD
Budgetary Price €/1k: 0.6
ICE5BR2280BZ
分类:数据:
简介: 65 kHz offline flyback and buck regulator with integrated 800 V CoolMOS™ superjunction MOSFET
ESD Protection max: 2.0kV
Green Product: Yes
I[CC]: 0.9mA
Operating Temperature max: 129.0°C
Package: PG-DIP-7
P[out] max: 22.0W
R[DS (on)] max: 2.35Ω
Sub Application: Offline SMPS
Switching Frequency: 65.0kHz
Technology: Gen5
V[DS] max: 800.0V
Topology: Flyback
Topology: Non-isolated flyback
Topology: Buck
Type: PWM controller with integrated MOSFET
V[CC] max: 24.0V
Target Application: Power Supplies
Target Application: Industrial
Target Application: Consumer
Target Application: Home appliances
更多
Target Application: SMPS
Mounting: THD
ESD Protection max: 2.0kV
Green Product: Yes
I[CC]: 0.9mA
Operating Temperature max: 129.0°C
P[out] max: 39.0W
Package: PG-DIP-7
R[DS (on)] max: 0.8Ω
Sub Application: Offline SMPS
Switching Frequency: 100.0kHz
Target Application: Power Supplies
Technology: Gen5
Topology: Flyback
Topology: Non-isolated flyback
Type: PWM controller with integrated MOSFET
V[CC] max: 24.0V
V[DS] max: 800.0V
Target Application: Consumer
Target Application: SMPS
Mounting: THD
Budgetary Price €/1k: 0.94
ESD Protection max: 2.0kV
I[CC]: 0.9mA
Operating Temperature max: 129.0°C
Package: PG-DSO-12
P[out] max: 15.0W
Switching Frequency: 125.0kHz
V[DS] max: 800.0V
V[CC] max: 24.0V
R[DS (on)] max: 4.85Ω
Topology: Flyback
Topology: Non-isolated flyback
Green Product: Yes
Technology: Gen5
Type: PWM controller with integrated MOSFET
Target Application: Power Supplies
Sub Application: Offline SMPS
Target Application: Industrial
Target Application: SMPS
Language: PowerEsim
Product Category: AC-DC Power Conversion
更多
Mounting: SMD
Budgetary Price €/1k: 0.62
V[DS] max: 650.0V
R[DS (on)] max: 0.75Ω
t[r]: 30.0ns
t[f]: 30.0ns
V[CC] max: 25.0V
I[CC]: 3.8mA
ESD Protection max: 2.0kV
Operating Temperature max: 130.0°C
Frequency Range: 65kHz fixed
Green Product: Yes
Package: PG-DIP-8
Switching Frequency: 65.0kHz
Topology: Flyback
P[out] max: 41.0W
Type: PWM controller with integrated MOSFET
Technology: Gen3R
Target Application: Power Supplies
Sub Application: Offline SMPS
Mounting: THD
Budgetary Price €/1k: 1.16
t[f]: 30.0ns
I[CC]: 3.0mA
ESD Protection max: 2.0kV
R[DS (on)] max: 5.18Ω
t[r]: 30.0ns
V[DS] max: 800.0V
Operating Temperature max: 130.0°C
V[CC] max: 25.0V
Green Product: Yes
Frequency Range: 100kHz fixed
Package: PG-DIP-7
Switching Frequency: 100.0kHz
Topology: Flyback
P[out] max: 15.0W
Type: PWM controller with integrated MOSFET
Technology: Gen3R
Target Application: Power Supplies
Sub Application: Offline SMPS
Mounting: THD
Budgetary Price €/1k: 0.79
