ANALOG DEVICES INC

Analog Devices, Inc.（NASDAQ: ADI)是全球领先的半导体公司，致力于在现实世界与数字世界之间架起桥梁，以实现智能边缘领域的突破性创新。ADI提供结合模拟、数字和软件技术的解决方案，推动数字化工厂、汽车和数字医疗等领域的持续发展，应对气候变化挑战，并建立人与世界万物的可靠互联。ADI公司2022财年收入超过120亿美元，全球员工约2.5万人。

HMC920LP5ETR

分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 其他模拟集成电路
数据:

简介: 有源偏置控制器，采用SMT封装

Product Lifecycle: 推荐用于新设计 Package: 32-Lead QFN (5mm x 5mm w/ EP) RF Primary Function: PA Bias Controller Vs+ (min): 5V Vs+ (max): 16.5V Vs Drain (min): 3V Vs Drain (max): 15V Idrain (min): 0mA Idrain (max): 500mA Igate Drive (min): -4mA Igate Drive (max): 4mA Vgate (min): -2.5V Vgate (max): 2V Over/Under Idrain Alarm: Yes Low Vsupply Alarm: Yes Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C Package Area: 25mm² (32-Lead QFN (5mm x 5mm w/ EP)) (HMC920LP5ETR)mm²
Package Height: 1mm (32-Lead QFN (5mm x 5mm w/ EP)) (HMC920LP5ETR)mm EP: No

ADL8101ACPZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 10 kHz to 22 GHz, Ultrawideband, Low Noise Amplifier

RF Primary Function: LNA, Wideband Distributed Amps Freq Response RF (min): 10kHz Freq Response RF (max): 22GHz Gain dB (typ): 14dB OP1dB (typ): 15dBm NF (typ): 3.5dB OIP3 (typ): 26dBm Vs (typ): 5V Is (typ): 90mA Residual Phase Noise (typ): -153dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Specified at Freq: 16GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8101ACPZN)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8101ACPZN)mm
Launch Date: 2024-08-08 EP: No

ADL8101ACPZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 10 kHz to 22 GHz, Ultrawideband, Low Noise Amplifier

RF Primary Function: LNA, Wideband Distributed Amps Freq Response RF (min): 10kHz Freq Response RF (max): 22GHz Gain dB (typ): 14dB OP1dB (typ): 15dBm NF (typ): 3.5dB OIP3 (typ): 26dBm Vs (typ): 5V Is (typ): 90mA Residual Phase Noise (typ): -153dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Specified at Freq: 16GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8101ACPZN)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8101ACPZN)mm
Launch Date: 2024-08-08 EP: No

ADL8140ACPZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 10 GHz to 18 GHz Low Noise Amplifier

RF Primary Function: LNA Freq Response RF (min): 10GHz Freq Response RF (max): 18GHz Gain dB (typ): 27dB OP1dB (typ): 6.5dBm NF (typ): 0.95dB OIP3 (typ): 18dBm Vs (typ): 1.5V Is (typ): 35mA Residual Phase Noise (typ): -135dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Specified at Freq: 15GHz Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8140ACPZN)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8140ACPZN)mm Launch Date: 2024-07-26 EP: No

ADL8140ACPZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 10 GHz to 18 GHz Low Noise Amplifier

RF Primary Function: LNA Freq Response RF (min): 10GHz Freq Response RF (max): 18GHz Gain dB (typ): 27dB OP1dB (typ): 6.5dBm NF (typ): 0.95dB OIP3 (typ): 18dBm Vs (typ): 1.5V Is (typ): 35mA Residual Phase Noise (typ): -135dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Specified at Freq: 15GHz Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8140ACPZN)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8140ACPZN)mm Launch Date: 2024-07-26 EP: No

ADL8143ACPZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 8 GHz to 14 GHz, Low Noise Amplifier

RF Primary Function: LNA Freq Response RF (min): 8GHz Freq Response RF (max): 14GHz Gain dB (typ): 28.5dB OP1dB (typ): 8.5dBm NF (typ): 1.1dB OIP3 (typ): 22dBm Vs (typ): 1.5V Is (typ): 35mA Residual Phase Noise (typ): -137dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Specified at Freq: 14GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8143ACPZN-R7)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8143ACPZN-R7)mm
Launch Date: 2024-07-25 EP: No

ADL8143ACPZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 8 GHz to 14 GHz, Low Noise Amplifier

RF Primary Function: LNA Freq Response RF (min): 8GHz Freq Response RF (max): 14GHz Gain dB (typ): 28.5dB OP1dB (typ): 8.5dBm NF (typ): 1.1dB OIP3 (typ): 22dBm Vs (typ): 1.5V Is (typ): 35mA Residual Phase Noise (typ): -137dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Specified at Freq: 14GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8143ACPZN-R7)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8143ACPZN-R7)mm
Launch Date: 2024-07-25 EP: No

ADL8122ACPZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 10 kHz to 10 GHz, Wideband, Low Noise Amplifier

RF Primary Function: LNA, LNA High Survivability, Low Phase Noise Freq Response RF (min): 10kHz Freq Response RF (max): 10GHz Gain dB (typ): 17dB OP1dB (typ): 20dBm NF (typ): 2dB OIP3 (typ): 33.5dBm Vs (typ): 5V Is (typ): 95mA Residual Phase Noise (typ): -160dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 3V Vs+ (max): 6V Specified at Freq: 6GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C
Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8122ACPZN)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8122ACPZN)mm Launch Date: 2024-07-03 EP: No

ADL8122ACPZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 10 kHz to 10 GHz, Wideband, Low Noise Amplifier

RF Primary Function: LNA, LNA High Survivability, Low Phase Noise Freq Response RF (min): 10kHz Freq Response RF (max): 10GHz Gain dB (typ): 17dB OP1dB (typ): 20dBm NF (typ): 2dB OIP3 (typ): 33.5dBm Vs (typ): 5V Is (typ): 95mA Residual Phase Noise (typ): -160dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 3V Vs+ (max): 6V Specified at Freq: 6GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C
Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8122ACPZN)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8122ACPZN)mm Launch Date: 2024-07-03 EP: No

ADL8120ACPZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 30 kHz to 20 GHz, Ultra-Wideband, Low Noise Amplifier

RF Primary Function: LNA, LNA High Survivability Freq Response RF (min): 30kHz Freq Response RF (max): 20GHz Gain dB (typ): 14dB OP1dB (typ): 16dBm NF (typ): 1.9dB OIP3 (typ): 29.5dBm Vs (typ): 3.3V Is (typ): 55mA Residual Phase Noise (typ): -160dBc/Hz Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (max): 5.5V Specified at Freq: 14GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -55 to 125°C Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8120ACPZN-R7)mm²
Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8120ACPZN-R7)mm Launch Date: 2024-05-10 EP: No
