ANALOG DEVICES INC

Analog Devices, Inc.（NASDAQ: ADI)是全球领先的半导体公司，致力于在现实世界与数字世界之间架起桥梁，以实现智能边缘领域的突破性创新。ADI提供结合模拟、数字和软件技术的解决方案，推动数字化工厂、汽车和数字医疗等领域的持续发展，应对气候变化挑战，并建立人与世界万物的可靠互联。ADI公司2022财年收入超过120亿美元，全球员工约2.5万人。

ADL8142ACPZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: GaAs、pHEMT、MMIC、低噪声放大器，23 GHz至31 GHz

RF Primary Function: LNA Freq Response RF (min): 23GHz Freq Response RF (max): 31GHz Gain dB (typ): 27dB OP1dB (typ): 10dBm NF (typ): 1.6dB OIP3 (typ): 21.5dBm Vs (typ): 2V Is (typ): 25mA Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 1.5V Vs+ (max): 3.5V Gain dB (min): 24.5dB Specified at Freq: 31GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C
Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8142ACPZN-R7)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8142ACPZN-R7)mm Launch Date: 2022-05-01 EP: No

ADPA1106ACGZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 功率放大器
数据:

简介: 46 dBm (40 W)、2.7 GHz至3.5 GHz GaN功率放大器

RF Primary Function: GaN Power Amp, Power Amp Freq Response RF (min): 2.7GHz Freq Response RF (max): 3.5GHz Gain dB (typ): 34.5dB Vs (typ): 50V Is (typ): 300mA Package: 32-Lead LFCSP (5mm x 5mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Gain dB (min): 32dB Specified at Freq: 3.1GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C Package Area: 25mm² (32-Lead LFCSP (5mm x 5mm w/ EP)) (ADPA1106ACGZN)mm² Package Height: 1.25mm (32-Lead LFCSP (5mm x 5mm w/ EP)) (ADPA1106ACGZN)mm Launch Date: 2022-04-25 EP: No

ADPA1106ACGZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 功率放大器
数据:

简介: 46 dBm (40 W)、2.7 GHz至3.5 GHz GaN功率放大器

RF Primary Function: GaN Power Amp, Power Amp Freq Response RF (min): 2.7GHz Freq Response RF (max): 3.5GHz Gain dB (typ): 34.5dB Vs (typ): 50V Is (typ): 300mA Package: 32-Lead LFCSP (5mm x 5mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Gain dB (min): 32dB Specified at Freq: 3.1GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C Package Area: 25mm² (32-Lead LFCSP (5mm x 5mm w/ EP)) (ADPA1106ACGZN)mm² Package Height: 1.25mm (32-Lead LFCSP (5mm x 5mm w/ EP)) (ADPA1106ACGZN)mm Launch Date: 2022-04-25 EP: No

ADL8107ACPZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: GaAs、pHEMT、MMIC、低噪声放大器，6 GHz至18 GHz

RF Primary Function: Driver Amp, LNA Freq Response RF (min): 6GHz Freq Response RF (max): 18GHz Gain dB (typ): 24dB OP1dB (typ): 18.5dBm NF (typ): 1.3dB OIP3 (typ): 29dBm Vs (typ): 5V Is (typ): 90mA Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 3V Vs+ (max): 5.5V Gain dB (min): 21.5dB Specified at Freq: 12GHz Eval / Ref Circuit: Evaluation board, Reference circuit Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C
Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8107ACPZN)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8107ACPZN)mm Launch Date: 2022-01-28 EP: No

ADL8107ACPZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: GaAs、pHEMT、MMIC、低噪声放大器，6 GHz至18 GHz

RF Primary Function: Driver Amp, LNA Freq Response RF (min): 6GHz Freq Response RF (max): 18GHz Gain dB (typ): 24dB OP1dB (typ): 18.5dBm NF (typ): 1.3dB OIP3 (typ): 29dBm Vs (typ): 5V Is (typ): 90mA Package: 8-lead LFCSP 2 mm × 2 mm × 0.85 Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 3V Vs+ (max): 5.5V Gain dB (min): 21.5dB Specified at Freq: 12GHz Eval / Ref Circuit: Evaluation board, Reference circuit Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C
Package Area: 4mm² (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8107ACPZN)mm² Package Height: 0.85mm (8-lead LFCSP 2 mm × 2 mm × 0.85) (ADL8107ACPZN)mm Launch Date: 2022-01-28 EP: No

ADPA7005AEHZ

分类: 微电路 / 微波半导体集成电路 / 放大器 / 功率放大器
数据:

简介: 18 GHz 至 44 GHz GaAs pHEMT 32 dBm (>1 W) MMIC 功率放大器

RF Primary Function: Power Amp, Wideband Distributed Amps Freq Response RF (min): 18GHz Freq Response RF (max): 44GHz Gain dB (typ): 15.5dB OP1dB (typ): 31dBm NF (typ): 7dB OIP3 (typ): 40dBm Vs (typ): 5V Is (typ): 1.4A Package: CHIPS OR DIE,18-Lead LCC (7mm x 7mm x 1.32mm w/EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 4V Vs+ (max): 5V Gain dB (min): 13.5dB Specified at Freq: 34GHz Eval / Ref Circuit: Evaluation board Export Classification: 3A001.b.2.d Automotive: No Temp Range: -40 to 85°C
Package Area: 49mm² (18-Lead LCC (7mm x 7mm x 1.32mm w/EP)) (ADPA7005AEHZ)mm² Package Height: 1.317mm (18-Lead LCC (7mm x 7mm x 1.32mm w/EP)) (ADPA7005AEHZ)mm Launch Date: 2022-01-27 EP: No

ADPA7005AEHZ-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 功率放大器
数据:

简介: 18 GHz 至 44 GHz GaAs pHEMT 32 dBm (>1 W) MMIC 功率放大器

RF Primary Function: Power Amp, Wideband Distributed Amps Freq Response RF (min): 18GHz Freq Response RF (max): 44GHz Gain dB (typ): 15.5dB OP1dB (typ): 31dBm NF (typ): 7dB OIP3 (typ): 40dBm Vs (typ): 5V Is (typ): 1.4A Package: CHIPS OR DIE,18-Lead LCC (7mm x 7mm x 1.32mm w/EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 4V Vs+ (max): 5V Gain dB (min): 13.5dB Specified at Freq: 34GHz Eval / Ref Circuit: Evaluation board Export Classification: 3A001.b.2.d Automotive: No Temp Range: -40 to 85°C
Package Area: 49mm² (18-Lead LCC (7mm x 7mm x 1.32mm w/EP)) (ADPA7005AEHZ)mm² Package Height: 1.317mm (18-Lead LCC (7mm x 7mm x 1.32mm w/EP)) (ADPA7005AEHZ)mm Launch Date: 2022-01-27 EP: No

ADPA7005C-KIT

分类: 微电路 / 微波半导体集成电路 / 放大器 / 功率放大器
数据:

简介: 18 GHz 至 44 GHz GaAs pHEMT 32 dBm (>1 W) MMIC 功率放大器

RF Primary Function: Power Amp, Wideband Distributed Amps Freq Response RF (min): 18GHz Freq Response RF (max): 44GHz Gain dB (typ): 15.5dB OP1dB (typ): 31dBm NF (typ): 7dB OIP3 (typ): 40dBm Vs (typ): 5V Is (typ): 1.4A Package: CHIPS OR DIE,18-Lead LCC (7mm x 7mm x 1.32mm w/EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 4V Vs+ (max): 5V Gain dB (min): 13.5dB Specified at Freq: 34GHz Eval / Ref Circuit: Evaluation board Export Classification: 3A001.b.2.d Automotive: No Temp Range: -40 to 85°C
Package Area: 49mm² (18-Lead LCC (7mm x 7mm x 1.32mm w/EP)) (ADPA7005AEHZ)mm² Package Height: 1.317mm (18-Lead LCC (7mm x 7mm x 1.32mm w/EP)) (ADPA7005AEHZ)mm Launch Date: 2022-01-27 EP: No

ADPA7005CHIP

分类: 微电路 / 微波半导体集成电路 / 放大器 / 功率放大器
数据:

简介: 18 GHz 至 44 GHz GaAs pHEMT 32 dBm (>1 W) MMIC 功率放大器

RF Primary Function: Power Amp, Wideband Distributed Amps Freq Response RF (min): 18GHz Freq Response RF (max): 44GHz Gain dB (typ): 15.5dB OP1dB (typ): 31dBm NF (typ): 7dB OIP3 (typ): 40dBm Vs (typ): 5V Is (typ): 1.4A Package: CHIPS OR DIE,18-Lead LCC (7mm x 7mm x 1.32mm w/EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 4V Vs+ (max): 5V Gain dB (min): 13.5dB Specified at Freq: 34GHz Eval / Ref Circuit: Evaluation board Export Classification: 3A001.b.2.d Automotive: No Temp Range: -40 to 85°C
Package Area: 49mm² (18-Lead LCC (7mm x 7mm x 1.32mm w/EP)) (ADPA7005AEHZ)mm² Package Height: 1.317mm (18-Lead LCC (7mm x 7mm x 1.32mm w/EP)) (ADPA7005AEHZ)mm Launch Date: 2022-01-27 EP: No

HMC8413LP2FE

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 0.01GHz 至 9GHz 低噪声放大器

RF Primary Function: Gain Block, LNA Freq Response RF (min): 10MHz Freq Response RF (max): 9GHz Gain dB (typ): 19.5dB OP1dB (typ): 21.5dBm NF (typ): 1.9dB OIP3 (typ): 35dBm Vs (typ): 5V Is (typ): 95mA Package: 6-Lead LFCSP (2mm x 2mm) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 2V Vs+ (max): 6V Gain dB (min): 17.5dB Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Reliability Level: Class S Temp Range: -40 to 85°C
Package Area: 4mm² (6-Lead LFCSP (2mm x 2mm)) (HMC8413LP2FE)mm² Package Height: 0.85mm (6-Lead LFCSP (2mm x 2mm)) (HMC8413LP2FE)mm Launch Date: 2021-11-02 EP: No
