Package name: SC70-3, SOT-23-3 Peak pulse power (8/20 μs) (max) (W): 210 Vrwm (V): 24 Bi-/uni-directional: Bi-directional Number of channels: 2 IO capacitance (typ) (pF): 3 IEC 61000-4-2 contact (±V): 30000 IEC 61000-4-5 (A): 5.7 Features: ESD Protection Clamping voltage (V): 35 Dynamic resistance (typ): 0.35 Interface type: CAN, GPIO, RS-485/432/422/232, USB Type-C Breakdown voltage (min) (V): 25.5 IO leakage current (max) (nA): 50 Rating: Catalog Operating temperature range (°C): -55 to 150 Package name: SC70-3, SOT-23-3 Peak pulse power (8/20 μs) (max) (W): 210 Vrwm (V): 24 Bi-/uni-directional: Bi-directional 更多

Package name: DFN0603 Peak pulse power (8/20 μs) (max) (W): 54 Vrwm (V): 3.6 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 0.66 IEC 61000-4-2 contact (±V): 30000 IEC 61000-4-5 (A): 5.4 Clamping voltage (V): 8.8 Dynamic resistance (typ): 0.25 Interface type: Ethernet, GPIO, General purpose, HDMI 1.4, HDMI 1.4/1.3, USB 2.0 Breakdown voltage (min) (V): 5 IO leakage current (max) (nA): 100 Rating: Catalog Operating temperature range (°C): -40 to 125 Package name: DFN0603 Peak pulse power (8/20 μs) (max) (W): 54 Vrwm (V): 3.6 Bi-/uni-directional: Bi-directional Number of channels: 1 更多

Package name: DFN1006 Peak pulse power (8/20 μs) (max) (W): 27 Vrwm (V): 3.6 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 0.2 IEC 61000-4-2 contact (±V): 15000 IEC 61000-4-5 (A): 2.5 Clamping voltage (V): 15 Dynamic resistance (typ): 0.57 Breakdown voltage (min) (V): 6.4 IO leakage current (max) (nA): 10 Rating: Automotive Operating temperature range (°C): -40 to 125 Package name: DFN1006 Peak pulse power (8/20 μs) (max) (W): 27 Vrwm (V): 3.6 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 0.2 更多

Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 1100 IEC 61000-4-5 (A): 27 Vrwm (V): 33 Breakdown voltage (min) (V): 34.4 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 54 Clamping voltage (V): 40 Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 1100 IEC 61000-4-5 (A): 27 Vrwm (V): 33 Breakdown voltage (min) (V): 34.4 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 54 Clamping voltage (V): 40

Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 360 IEC 61000-4-5 (A): 30 Vrwm (V): 7 Breakdown voltage (min) (V): 9.3 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 77 Clamping voltage (V): 11 Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 360 IEC 61000-4-5 (A): 30 Vrwm (V): 7 Breakdown voltage (min) (V): 9.3 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 77 Clamping voltage (V): 11

Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 600 IEC 61000-4-5 (A): 30 Vrwm (V): 14 Breakdown voltage (min) (V): 17.1 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 68 Clamping voltage (V): 20.5 Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 600 IEC 61000-4-5 (A): 30 Vrwm (V): 14 Breakdown voltage (min) (V): 17.1 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 68 Clamping voltage (V): 20.5

Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 825 IEC 61000-4-5 (A): 30 Vrwm (V): 18 Breakdown voltage (min) (V): 23.35 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 65 Clamping voltage (V): 27.4 Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 825 IEC 61000-4-5 (A): 30 Vrwm (V): 18 Breakdown voltage (min) (V): 23.35 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 65 Clamping voltage (V): 27.4

Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 850 IEC 61000-4-5 (A): 30 Vrwm (V): 22 Breakdown voltage (min) (V): 25.1 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 62 Clamping voltage (V): 29.6 Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 850 IEC 61000-4-5 (A): 30 Vrwm (V): 22 Breakdown voltage (min) (V): 25.1 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 62 Clamping voltage (V): 29.6

Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 950 IEC 61000-4-5 (A): 27 Vrwm (V): 27 Breakdown voltage (min) (V): 29.6 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 40 Clamping voltage (V): 34 Package name: DFN3030 Peak pulse power (8/20 μs) (max) (W): 950 IEC 61000-4-5 (A): 27 Vrwm (V): 27 Breakdown voltage (min) (V): 29.6 Bi-/uni-directional: Bi-directional Number of channels: 1 IO capacitance (typ) (pF): 40 Clamping voltage (V): 34

Package name: SOT-23-3 Peak pulse power (8/20 μs) (max) (W): 85 Vrwm (V): 3.6 Bi-/uni-directional: Uni-Directional Number of channels: 2 IO capacitance (typ) (pF): 2.3 IEC 61000-4-2 contact (±V): 30000 IEC 61000-4-5 (A): 12 Features: Surge protection Clamping voltage (V): 5.5 Interface type: Ethernet, General purpose, USB 2.0 Breakdown voltage (min) (V): 4.5 IO leakage current (max) (nA): 50 Rating: Catalog Operating temperature range (°C): -40 to 125 Package name: SOT-23-3 Peak pulse power (8/20 μs) (max) (W): 85 Vrwm (V): 3.6 Bi-/uni-directional: Uni-Directional Number of channels: 2 更多
