Number of channels: 2 Operating voltage (max) (V): 18 Operating voltage (min) (V): 6 Ron (typ) (mΩ): 50 Imax (A): 2 Current limit (min) (A): 2 Current limit (max) (A): 18 Current limit type: Adjustable Current limit accuracy: +/-24% Current sense accuracy: +/-5% @ 1A FET: Internal Operating temperature range (°C): -40 to 125 Rating: Automotive Number of channels: 2 Operating voltage (max) (V): 18 Operating voltage (min) (V): 6 Ron (typ) (mΩ): 50 Imax (A): 2 Current limit (min) (A): 2 Current limit (max) (A): 18 更多

Number of channels: 1 Operating voltage (max) (V): 18 Operating voltage (min) (V): 6 Ron (typ) (mΩ): 8 Imax (A): 10 Current limit (min) (A): 6.4 Current limit (max) (A): 70 Current limit type: Adjustable TI functional safety category: Functional Safety-Capable Current limit accuracy: +25%/-36% Current sense accuracy: +5/-5% @ 1A FET: Internal Operating temperature range (°C): -40 to 125 Rating: Automotive Number of channels: 1 Operating voltage (max) (V): 18 Operating voltage (min) (V): 6 Ron (typ) (mΩ): 8 Imax (A): 10 Current limit (min) (A): 6.4 更多

Number of supplies monitored: 1 Threshold voltage 1 (typ) (V): 1.7, 1.8, 2.25, 2.4, 2.64, 2.93, 3.08, 3.3, 4.2, 4.38, 4.63 Reset threshold accuracy (%): 2 Iq (typ) (mA): 0.00025 Output driver type/reset output: Active-low, Open-drain Time delay (ms): 0.04, 200 Supply voltage (min) (V): 1.7 Supply voltage (max) (V): 6 Rating: Catalog Watchdog timer WDI (s): None Operating temperature range (°C): -40 to 125 Number of supplies monitored: 1 Threshold voltage 1 (typ) (V): 1.7, 1.8, 2.25, 2.4, 2.64, 2.93, 3.08, 3.3, 4.2, 4.38, 4.63 Reset threshold accuracy (%): 2 Iq (typ) (mA): 0.00025 Output driver type/reset output: Active-low, Open-drain Time delay (ms): 0.04, 200 Supply voltage (min) (V): 1.7 Supply voltage (max) (V): 6 Rating: Catalog 更多

Number of supplies monitored: 1 Threshold voltage 1 (typ) (V): 1.7, 2.25, 2.64, 2.93, 3.08, 4.38, 4.55, 4.63 Reset threshold accuracy (%): 2 Iq (typ) (mA): 0.00025 Output driver type/reset output: Active-low, Push-Pull Time delay (ms): 10, 50, 200, 400 Supply voltage (min) (V): 1.7 Supply voltage (max) (V): 6 Rating: Catalog Watchdog timer WDI (s): None Operating temperature range (°C): -40 to 125 Number of supplies monitored: 1 Threshold voltage 1 (typ) (V): 1.7, 2.25, 2.64, 2.93, 3.08, 4.38, 4.55, 4.63 Reset threshold accuracy (%): 2 Iq (typ) (mA): 0.00025 Output driver type/reset output: Active-low, Push-Pull Time delay (ms): 10, 50, 200, 400 Supply voltage (min) (V): 1.7 Supply voltage (max) (V): 6 Rating: Catalog 更多

Number of channels: 2 Operating voltage (max) (V): 18 Operating voltage (min) (V): 6 Ron (typ) (mΩ): 16 Imax (A): 5 Current limit (min) (A): 4.1 Current limit (max) (A): 48.5 Current limit type: Adjustable Current limit accuracy: +30%/-35% Current sense accuracy: +6%/-4% @ 1A FET: Internal Operating temperature range (°C): -40 to 125 Rating: Automotive Number of channels: 2 Operating voltage (max) (V): 18 Operating voltage (min) (V): 6 Ron (typ) (mΩ): 16 Imax (A): 5 Current limit (min) (A): 4.1 Current limit (max) (A): 48.5 更多

Number of channels: 2 Operating voltage (max) (V): 18 Operating voltage (min) (V): 6 Ron (typ) (mΩ): 35 Imax (A): 3 Current limit (min) (A): 2 Current limit (max) (A): 25 Current limit type: Adjustable Current limit accuracy: +25%/-10% Current sense accuracy: +/-4% @ 1A FET: Internal Operating temperature range (°C): -40 to 125 Rating: Automotive Number of channels: 2 Operating voltage (max) (V): 18 Operating voltage (min) (V): 6 Ron (typ) (mΩ): 35 Imax (A): 3 Current limit (min) (A): 2 Current limit (max) (A): 25 更多

Number of supplies monitored: 1 Threshold voltage 1 (typ) (V): 2.63, 2.75, 2.93, 3.08, 3.65, 4, 4.38, 4.63 Reset threshold accuracy (%): 1.5 Iq (typ) (mA): 0.0003 Output driver type/reset output: Active-low, Open-drain Supply voltage (min) (V): 0.9 Supply voltage (max) (V): 10 Rating: Catalog Watchdog timer WDI (s): None Operating temperature range (°C): -40 to 125 Number of supplies monitored: 1 Threshold voltage 1 (typ) (V): 2.63, 2.75, 2.93, 3.08, 3.65, 4, 4.38, 4.63 Reset threshold accuracy (%): 1.5 Iq (typ) (mA): 0.0003 Output driver type/reset output: Active-low, Open-drain Supply voltage (min) (V): 0.9 Supply voltage (max) (V): 10 Rating: Catalog Watchdog timer WDI (s): None Operating temperature range (°C): -40 to 125

Number of channels: 1 Vin (min) (V): 2.5 Vin (max) (V): 5.5 Imax (A): 0.1 Ron (typ) (mΩ): 300 Shutdown current (ISD) (typ) (µA): 5 Quiescent current (Iq) (typ) (µA): 50 Soft start: Fixed Rise Time Current limit type: Fixed Rating: Catalog Operating temperature range (°C): -40 to 105 FET: Internal Device type: Load switches Number of channels: 1 Vin (min) (V): 2.5 Vin (max) (V): 5.5 Imax (A): 0.1 Ron (typ) (mΩ): 300 Shutdown current (ISD) (typ) (µA): 5 Quiescent current (Iq) (typ) (µA): 50 更多

Product type: Charge port converter Vin (min) (V): 4.5 Vin (max) (V): 36 Continuous current (max) (A): 3.5 Current limit (A): 0.1 to 3.5 Operating temperature range (°C): -40 to 125 Enable: Active High Number of switches: 1 TI functional safety category: Functional Safety-Capable Current limit accuracy at 1 A: adjustable Rating: Automotive Product type: Charge port converter Vin (min) (V): 4.5 Vin (max) (V): 36 Continuous current (max) (A): 3.5 Current limit (A): 0.1 to 3.5 Operating temperature range (°C): -40 to 125 Enable: Active High Number of switches: 1 TI functional safety category: Functional Safety-Capable 更多

Product type: Charge port converter Vin (min) (V): 4.5 Vin (max) (V): 36 Continuous current (max) (A): 3.5 Current limit (A): User-selectable current limit Operating temperature range (°C): -40 to 125 Enable: Active High Number of switches: 1 TI functional safety category: Functional Safety-Capable Rating: Automotive Product type: Charge port converter Vin (min) (V): 4.5 Vin (max) (V): 36 Continuous current (max) (A): 3.5 Current limit (A): User-selectable current limit Operating temperature range (°C): -40 to 125 Enable: Active High Number of switches: 1 TI functional safety category: Functional Safety-Capable Rating: Automotive
