Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 24 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 5 Rail-to-rail: Out GBW (typ) (MHz): 17 Slew rate (typ) (V/µs): 5.5 Vos (offset voltage at 25°C) (max) (mV): 2.5 Iq per channel (typ) (mA): 0.96 Vn at 1 kHz (typ) (nV√Hz): 6 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 5 CMRR (typ) (dB): 98 Iout (typ) (A): 0.016 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -2.1 Output swing headroom (to negative supply) (typ) (V): 0.013 Output swing headroom (to positive supply) (typ) (V): -0.02

GBW (typ) (MHz): 10 Slew rate (typ) (V/µs): 13 Rail-to-rail: No Vos (offset voltage at 25°C) (max) (mV): 4 Iq per channel (typ) (mA): 4 Vn at 1 kHz (typ) (nV√Hz): 4 Features: Standard Amps THD + N at 1 kHz (typ) (%): 0.002 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.038 Architecture: Bipolar CMRR (typ) (dB): 100 Input bias current (max) (pA): 1500000

GBW (typ) (MHz): 10 Slew rate (typ) (V/µs): 13 Rail-to-rail: No Vos (offset voltage at 25°C) (max) (mV): 4 Iq per channel (typ) (mA): 4 Vn at 1 kHz (typ) (nV√Hz): 3.5 Features: Standard Amps THD + N at 1 kHz (typ) (%): 0.002 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.038 Architecture: Bipolar CMRR (typ) (dB): 100 Input bias current (max) (pA): 1500000

Output swing headroom (to positive supply) (typ) (V): -0.025 Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 5 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 1.8 Rail-to-rail: In to V-, Out GBW (typ) (MHz): 17 Slew rate (typ) (V/µs): 9.5 Vos (offset voltage at 25°C) (max) (mV): 1.35 Iq per channel (typ) (mA): 1.15 Vn at 1 kHz (typ) (nV√Hz): 5.8 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 1 Features: Shutdown Input bias current (max) (pA): 1 CMRR (typ) (dB): 100 Iout (typ) (A): 0.021 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.02 Output swing headroom (to positive supply) (typ) (V): -0.025

3rd harmonic (dBc): 100 Frequency of harmonic distortion measurement (MHz): 10 Architecture: Voltage FB Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 5 GBW (typ) (MHz): 3000 BW at Acl (MHz): 3000 Acl, min spec gain (V/V): 1 Slew rate (typ) (V/µs): 790 Vn at flatband (typ) (nV√Hz): 2.4 Vn at 1 kHz (typ) (nV√Hz): 6.4 Iq per channel (typ) (mA): 18 Vos (offset voltage at 25°C) (max) (mV): 4 Rail-to-rail: No Rating: Catalog Operating temperature range (°C): -40 to 85 CMRR (typ) (dB): 95 Input bias current (max) (pA): 12000000 Offset drift (typ) (µV/°C): 5 Iout (typ) (mA): 100 2nd harmonic (dBc): 84 3rd harmonic (dBc): 100 Frequency of harmonic distortion measurement (MHz): 10

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 16 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Rail-to-rail: In, Out GBW (typ) (MHz): 3 Slew rate (typ) (V/µs): 2.4 Vos (offset voltage at 25°C) (max) (mV): 4.5 Iq per channel (typ) (mA): 0.55 Vn at 1 kHz (typ) (nV√Hz): 39 Rating: Automotive Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 60 CMRR (typ) (dB): 72 Iout (typ) (A): 0.007 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 0.05 Output swing headroom (to positive supply) (typ) (V): -0.07

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 16 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Rail-to-rail: In, Out GBW (typ) (MHz): 3 Slew rate (typ) (V/µs): 2.4 Vos (offset voltage at 25°C) (max) (mV): 4.5 Iq per channel (typ) (mA): 0.55 Vn at 1 kHz (typ) (nV√Hz): 39 Rating: Automotive Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 60 CMRR (typ) (dB): 72 Iout (typ) (A): 0.007 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 0.05 Output swing headroom (to positive supply) (typ) (V): -0.07

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 30 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 1.2 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 35 Rating: Catalog Operating temperature range (°C): -25 to 85 Offset drift (typ) (µV/°C): 7 Input bias current (max) (pA): 250000 CMRR (typ) (dB): 80 Iout (typ) (A): 0.04 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -2

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 30 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 1.2 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 2 Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 35 Rating: Catalog Operating temperature range (°C): -25 to 85 Offset drift (typ) (µV/°C): 7 Input bias current (max) (pA): 80000 CMRR (typ) (dB): 80 Iout (typ) (A): 0.04 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -2

Output swing headroom (to positive supply) (typ) (V): -2 Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 26 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 1.2 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 7 Iq per channel (typ) (mA): 0.175 Vn at 1 kHz (typ) (nV√Hz): 35 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 7 Features: Standard Amps Input bias current (max) (pA): 250000 CMRR (typ) (dB): 80 Iout (typ) (A): 0.04 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -2
