Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 6 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Rail-to-rail: In, Out GBW (typ) (MHz): 2.8 Slew rate (typ) (V/µs): 1.5 Vos (offset voltage at 25°C) (max) (mV): 1.6 Iq per channel (typ) (mA): 0.6 Vn at 1 kHz (typ) (nV√Hz): 15 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 50 CMRR (typ) (dB): 84 Iout (typ) (A): 0.09 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 0.07 Output swing headroom (to positive supply) (typ) (V): -0.04

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 6 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Rail-to-rail: In, Out GBW (typ) (MHz): 2.8 Slew rate (typ) (V/µs): 1.5 Vos (offset voltage at 25°C) (max) (mV): 2.2 Iq per channel (typ) (mA): 0.6 Vn at 1 kHz (typ) (nV√Hz): 15 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 50 CMRR (typ) (dB): 84 Iout (typ) (A): 0.09 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 0.07 Output swing headroom (to positive supply) (typ) (V): -0.04

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 6 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Rail-to-rail: In, Out GBW (typ) (MHz): 2.8 Slew rate (typ) (V/µs): 1.5 Vos (offset voltage at 25°C) (max) (mV): 1.6 Iq per channel (typ) (mA): 0.6 Vn at 1 kHz (typ) (nV√Hz): 15 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 50 CMRR (typ) (dB): 84 Iout (typ) (A): 0.09 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 0.07 Output swing headroom (to positive supply) (typ) (V): -0.04

Output swing headroom (to positive supply) (typ) (V): -0.04 Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 6 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Rail-to-rail: In, Out GBW (typ) (MHz): 2.8 Slew rate (typ) (V/µs): 1.5 Vos (offset voltage at 25°C) (max) (mV): 2.2 Iq per channel (typ) (mA): 0.6 Vn at 1 kHz (typ) (nV√Hz): 15 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 0.4 Features: Shutdown Input bias current (max) (pA): 50 CMRR (typ) (dB): 84 Iout (typ) (A): 0.09 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 0.07 Output swing headroom (to positive supply) (typ) (V): -0.04

Output swing headroom (to positive supply) (typ) (V): -0.04 Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 6 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Rail-to-rail: In, Out GBW (typ) (MHz): 2.8 Slew rate (typ) (V/µs): 1.5 Vos (offset voltage at 25°C) (max) (mV): 1.6 Iq per channel (typ) (mA): 0.6 Vn at 1 kHz (typ) (nV√Hz): 15 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 0.4 Features: Shutdown Input bias current (max) (pA): 50 CMRR (typ) (dB): 84 Iout (typ) (A): 0.09 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 0.07 Output swing headroom (to positive supply) (typ) (V): -0.04

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 5.5 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.5 Rail-to-rail: In to V-, Out GBW (typ) (MHz): 5.1 Slew rate (typ) (V/µs): 10.5 Vos (offset voltage at 25°C) (max) (mV): 2.1 Iq per channel (typ) (mA): 1 Vn at 1 kHz (typ) (nV√Hz): 17 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 60 CMRR (typ) (dB): 96 Iout (typ) (A): 0.04 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.3 Output swing headroom (to negative supply) (typ) (V): 0.1 Output swing headroom (to positive supply) (typ) (V): -0.1

Output swing headroom (to positive supply) (typ) (V): -0.1 Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 5.5 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.5 Rail-to-rail: In to V-, Out GBW (typ) (MHz): 5.1 Slew rate (typ) (V/µs): 10.5 Vos (offset voltage at 25°C) (max) (mV): 2.1 Iq per channel (typ) (mA): 1 Vn at 1 kHz (typ) (nV√Hz): 17 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 2 Features: Shutdown Input bias current (max) (pA): 60 CMRR (typ) (dB): 96 Iout (typ) (A): 0.04 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.3 Output swing headroom (to negative supply) (typ) (V): 0.1 Output swing headroom (to positive supply) (typ) (V): -0.1

Output swing headroom (to positive supply) (typ) (V): -0.17 Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 22 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.5 Rail-to-rail: In, Out GBW (typ) (MHz): 21 Slew rate (typ) (V/µs): 12 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 0.97 Vn at 1 kHz (typ) (nV√Hz): 15 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 2 Features: High Cload Drive Input bias current (max) (pA): 2000000 CMRR (typ) (dB): 110 Iout (typ) (A): 0.053 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): 0.1 Output swing headroom (to negative supply) (typ) (V): 0.09 Output swing headroom (to positive supply) (typ) (V): -0.17

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Rail-to-rail: In to V- GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.4 Vos (offset voltage at 25°C) (max) (mV): 0.15 Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 22 Rating: Military Operating temperature range (°C): -55 to 125 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 20000 CMRR (typ) (dB): 117 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1.2 Output swing headroom (to negative supply) (typ) (V): 1 Output swing headroom (to positive supply) (typ) (V): -1

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Vos (offset voltage at 25°C) (max) (mV): 0.3 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 30000 GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.4 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 22 CMRR (typ) (dB): 114 Rating: Military Operating temperature range (°C): -55 to 125 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 1.5 Output swing headroom (to positive supply) (typ) (V): -1
