Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 30 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.3 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 40 Rating: Catalog Operating temperature range (°C): -25 to 85 Offset drift (typ) (µV/°C): 7 Input bias current (max) (pA): 80000 CMRR (typ) (dB): 80 Iout (typ) (A): 0.03 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -2

GBW (typ) (MHz): 2.5 Slew rate (typ) (V/µs): 20 Iq per channel (typ) (mA): 1.3 Rating: Automotive Operating temperature range (°C): -40 to 85 Input bias current (max) (pA): 200000 Iout (typ) (A): 0.005 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 0.2 Output swing headroom (to positive supply) (typ) (V): -1.5

Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 40 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 10 Rail-to-rail: No GBW (typ) (MHz): 15 Slew rate (typ) (V/µs): 70 Vos (offset voltage at 25°C) (max) (mV): 10 Iq per channel (typ) (mA): 4.5 Vn at 1 kHz (typ) (nV√Hz): 15 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 6 Input bias current (max) (pA): 500000 CMRR (typ) (dB): 100 Iout (typ) (A): 0.02 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 3.5 Input common mode headroom (to positive supply) (typ) (V): -3.5 Output swing headroom (to negative supply) (typ) (V): 2 Output swing headroom (to positive supply) (typ) (V): -2

Output swing headroom (to positive supply) (typ) (V): -2 Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 30 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.3 Vos (offset voltage at 25°C) (max) (mV): 7 Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 40 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 7 Features: Standard Amps Input bias current (max) (pA): 150000 CMRR (typ) (dB): 80 Iout (typ) (A): 0.03 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -2

Output swing headroom (to positive supply) (typ) (V): -2 Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 30 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.3 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 40 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 7 Features: Standard Amps Input bias current (max) (pA): 100000 CMRR (typ) (dB): 80 Iout (typ) (A): 0.03 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -2

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Vos (offset voltage at 25°C) (max) (mV): 0.3 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 30000 GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.4 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 22 CMRR (typ) (dB): 114 Rating: Catalog Operating temperature range (°C): 0 to 70 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 1.5 Output swing headroom (to positive supply) (typ) (V): -1

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Vos (offset voltage at 25°C) (max) (mV): 0.3 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 30000 GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.4 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 22 CMRR (typ) (dB): 114 Rating: Automotive, Catalog Operating temperature range (°C): -55 to 125 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 1.5 Output swing headroom (to positive supply) (typ) (V): -1

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 5 Vos (offset voltage at 25°C) (max) (mV): 0.3 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 30000 GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.4 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 22 CMRR (typ) (dB): 117 Rating: Catalog Operating temperature range (°C): 0 to 70 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1.2 Output swing headroom (to negative supply) (typ) (V): 1 Output swing headroom (to positive supply) (typ) (V): -1

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 5 Vos (offset voltage at 25°C) (max) (mV): 0.8 Offset drift (typ) (µV/°C): 0.7 Input bias current (max) (pA): 30000 GBW (typ) (MHz): 0.7 Slew rate (typ) (V/µs): 0.4 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.35 Vn at 1 kHz (typ) (nV√Hz): 22 CMRR (typ) (dB): 117 Rating: Automotive, Catalog Operating temperature range (°C): -55 to 125 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1.2 Output swing headroom (to negative supply) (typ) (V): 1 Output swing headroom (to positive supply) (typ) (V): -1

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 30 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 10 Rail-to-rail: No GBW (typ) (MHz): 1 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 6 Iq per channel (typ) (mA): 1.5 Vn at 1 kHz (typ) (nV√Hz): 45 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 0 Input bias current (max) (pA): 500000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.045 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 3 Input common mode headroom (to positive supply) (typ) (V): -3 Output swing headroom (to negative supply) (typ) (V): 1 Output swing headroom (to positive supply) (typ) (V): -1
