Common-mode input low (min) (V): -20 Common-mode input high (max) (V): 20 Input offset (±) (max) (V): 0.00025 Iq (typ) (mA): 1.5 Slew rate (typ) (V/µs): 3 Voltage gain (min) (V/V): 1 Voltage gain (max) (V/V): 1 Small-signal bandwidth (typ) (Hz): 1000000 Rating: Catalog Operating temperature range (°C): -40 to 85 Gain drift (max) (ppm/°C): 1 Gain error (±) (max) (%): 0.01

GBW (typ) (MHz): 10 Slew rate (typ) (V/µs): 10 Rail-to-rail: No Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 2.5 Vn at 1 kHz (typ) (nV√Hz): 4.5 Features: Standard Amps THD + N at 1 kHz (typ) (%): 0.0015 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.04 Architecture: Bipolar CMRR (typ) (dB): 100 Input bias current (max) (pA): 1000000

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 32 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 0.1 Slew rate (typ) (V/µs): 0.05 Vos (offset voltage at 25°C) (max) (mV): 4 Iq per channel (typ) (mA): 0.02125 Vn at 1 kHz (typ) (nV√Hz): 80 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 10 Input bias current (max) (pA): 10000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.004 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -1.4

Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 8 Vos (offset voltage at 25°C) (max) (mV): 0.22 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 80000 GBW (typ) (MHz): 8 Slew rate (typ) (V/µs): 1.9 Rail-to-rail: No Iq per channel (typ) (mA): 3.3 Vn at 1 kHz (typ) (nV√Hz): 3.2 CMRR (typ) (dB): 122 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 3.2 Input common mode headroom (to positive supply) (typ) (V): -3.2 Output swing headroom (to negative supply) (typ) (V): 1.2 Output swing headroom (to positive supply) (typ) (V): -1.2

Output swing headroom (to positive supply) (typ) (V): -1.2 Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 8 Vos (offset voltage at 25°C) (max) (mV): 0.22 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 80000 GBW (typ) (MHz): 63 Features: Decompensated Slew rate (typ) (V/µs): 11.9 Rail-to-rail: No Iq per channel (typ) (mA): 3.3 Vn at 1 kHz (typ) (nV√Hz): 3.2 CMRR (typ) (dB): 122 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 3.2 Input common mode headroom (to positive supply) (typ) (V): -3.2 Output swing headroom (to negative supply) (typ) (V): 1.2 Output swing headroom (to positive supply) (typ) (V): -1.2

GBW (typ) (MHz): 5.5 Slew rate (typ) (V/µs): 8 Vos (offset voltage at 25°C) (max) (mV): 10 Offset drift (typ) (V/°C): 0.000025 Iq per channel (typ) (mA): 18 Features: Decompensated Rating: Catalog Operating temperature range (°C): 0 to 70 Input bias current (max) (pA): 2000000 CMRR (typ) (dB): 90 Rail-to-rail: No Architecture: Bipolar

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 32 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 0.1 Slew rate (typ) (V/µs): 0.05 Vos (offset voltage at 25°C) (max) (mV): 4 Iq per channel (typ) (mA): 0.02125 Vn at 1 kHz (typ) (nV√Hz): 80 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 10 Input bias current (max) (pA): 20000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.004 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -1.4

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 26 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 0.1 Slew rate (typ) (V/µs): 0.05 Vos (offset voltage at 25°C) (max) (mV): 10 Iq per channel (typ) (mA): 0.02125 Vn at 1 kHz (typ) (nV√Hz): 80 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 0 Input bias current (max) (pA): 20000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.004 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -1.4

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 32 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 0.1 Slew rate (typ) (V/µs): 0.05 Vos (offset voltage at 25°C) (max) (mV): 9 Iq per channel (typ) (mA): 0.02125 Vn at 1 kHz (typ) (nV√Hz): 80 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 10 Input bias current (max) (pA): 10000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.004 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0.0375 Input common mode headroom (to positive supply) (typ) (V): 0.02125 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -1.4

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 5 Rail-to-rail: No GBW (typ) (MHz): 4 Slew rate (typ) (V/µs): 13 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 1.8 Vn at 1 kHz (typ) (nV√Hz): 20 Rating: Military Operating temperature range (°C): -55 to 125 Offset drift (typ) (µV/°C): 10 Input bias current (max) (pA): 200 CMRR (typ) (dB): 100 Iout (typ) (A): 0.03 Architecture: FET Input common mode headroom (to negative supply) (typ) (V): 3 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 1.5 Output swing headroom (to positive supply) (typ) (V): -1.5
