Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 32 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 1 Slew rate (typ) (V/µs): 0.1 Vos (offset voltage at 25°C) (max) (mV): 7 Iq per channel (typ) (mA): 0.25 Vn at 1 kHz (typ) (nV√Hz): 40 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 7 Input bias current (max) (pA): 150000 CMRR (typ) (dB): 85 Iout (typ) (A): 0.02 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -2

Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 10 Rail-to-rail: No GBW (typ) (MHz): 1 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 1.7 Vn at 1 kHz (typ) (nV√Hz): 30 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 15 Input bias current (max) (pA): 210000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 2 Input common mode headroom (to positive supply) (typ) (V): -2 Output swing headroom (to negative supply) (typ) (V): 1 Output swing headroom (to positive supply) (typ) (V): -1

Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 10 Rail-to-rail: No GBW (typ) (MHz): 1 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 1.7 Vn at 1 kHz (typ) (nV√Hz): 30 Rating: Military Operating temperature range (°C): -55 to 125 Offset drift (typ) (µV/°C): 15 Input bias current (max) (pA): 210000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 3 Input common mode headroom (to positive supply) (typ) (V): -3 Output swing headroom (to negative supply) (typ) (V): 3 Output swing headroom (to positive supply) (typ) (V): -3

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 10 Rail-to-rail: No GBW (typ) (MHz): 1.5 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 1.7 Vn at 1 kHz (typ) (nV√Hz): 23 Rating: Military Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 15 Input bias current (max) (pA): 80000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 2 Input common mode headroom (to positive supply) (typ) (V): -2 Output swing headroom (to negative supply) (typ) (V): 1 Output swing headroom (to positive supply) (typ) (V): -1

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 44 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 10 Rail-to-rail: No GBW (typ) (MHz): 1.5 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 1.7 Vn at 1 kHz (typ) (nV√Hz): 23 Rating: Military Operating temperature range (°C): -55 to 125 Offset drift (typ) (µV/°C): 15 Input bias current (max) (pA): 1500000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 3 Input common mode headroom (to positive supply) (typ) (V): -3 Output swing headroom (to negative supply) (typ) (V): 3 Output swing headroom (to positive supply) (typ) (V): -3

GBW (typ) (MHz): 15 Slew rate (typ) (V/µs): 7 Rail-to-rail: No Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 2.5 Vn at 1 kHz (typ) (nV√Hz): 4.5 Features: Premium Sound, Standard Amps THD + N at 1 kHz (typ) (%): 0.002 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.04 Architecture: Bipolar CMRR (typ) (dB): 100 Input bias current (max) (pA): 1000000

Output swing headroom (to positive supply) (typ) (V): -1.5 Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 30 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 7 Rail-to-rail: In to V+ GBW (typ) (MHz): 3 Slew rate (typ) (V/µs): 13 Vos (offset voltage at 25°C) (max) (mV): 6 Iq per channel (typ) (mA): 1.4 Vn at 1 kHz (typ) (nV√Hz): 18 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 18 Features: Standard Amps Input bias current (max) (pA): 200 CMRR (typ) (dB): 86 Iout (typ) (A): 0.01 Architecture: FET Input common mode headroom (to negative supply) (typ) (V): 3 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 1.5 Output swing headroom (to positive supply) (typ) (V): -1.5

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 30 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 10 Rail-to-rail: In to V+ GBW (typ) (MHz): 4 Slew rate (typ) (V/µs): 13 Vos (offset voltage at 25°C) (max) (mV): 15 Iq per channel (typ) (mA): 1.75 Vn at 1 kHz (typ) (nV√Hz): 25 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 10 Input bias current (max) (pA): 400 CMRR (typ) (dB): 100 Iout (typ) (A): 0.017 Architecture: FET Input common mode headroom (to negative supply) (typ) (V): 3 Input common mode headroom (to positive supply) (typ) (V): 0 Output swing headroom (to negative supply) (typ) (V): 1.5 Output swing headroom (to positive supply) (typ) (V): -1.5

Output swing headroom (to positive supply) (typ) (V): -1.2 Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 16 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 2 Slew rate (typ) (V/µs): 3.6 Vos (offset voltage at 25°C) (max) (mV): 10 Iq per channel (typ) (mA): 0.675 Vn at 1 kHz (typ) (nV√Hz): 25 Rating: Catalog, Military Operating temperature range (°C): -55 to 125 Offset drift (typ) (µV/°C): 1.8 Features: Shutdown Input bias current (max) (pA): 60 CMRR (typ) (dB): 80 Iout (typ) (A): 0.01 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -0.8 Output swing headroom (to negative supply) (typ) (V): 0.03 Output swing headroom (to positive supply) (typ) (V): -1.2

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 16 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 2 Slew rate (typ) (V/µs): 3.6 Vos (offset voltage at 25°C) (max) (mV): 10 Iq per channel (typ) (mA): 0.7 Vn at 1 kHz (typ) (nV√Hz): 25 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 1.8 Input bias current (max) (pA): 60 CMRR (typ) (dB): 80 Iout (typ) (A): 0.01 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -0.8 Output swing headroom (to negative supply) (typ) (V): 0.03 Output swing headroom (to positive supply) (typ) (V): -1.2
