天天芯片 - 物料搜索

INA1650-Q1

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: 汽车类高共模抑制、低失真差分音频线路接收器

Number of channels: 2 Voltage gain (V/V): 1 CMRR at RS = 0 Ω (min) (dB): 85 THD + N at 1 kHz (%): 0.00039 Noise floor (RTO, 20-kHz BW) (dBu): -104.7 Differential input impedance (kΩ): 1000 Common-mode input impedance (kΩ): 250 Slew rate (typ) (V/µs): 10 Small-signal bandwidth (typ) (Hz): 2700000 Supply voltage (max) (V): 24 Supply voltage (min) (V): 4.5 Iq per channel (typ) (mA): 5.25 Operating temperature range (°C): -40 to 125 Rating: Automotive Number of channels: 2 Voltage gain (V/V): 1 CMRR at RS = 0 Ω (min) (dB): 85 THD + N at 1 kHz (%): 0.00039 Noise floor (RTO, 20-kHz BW) (dBu): -104.7 Differential input impedance (kΩ): 1000 更多

Common-mode input impedance (kΩ): 250 Slew rate (typ) (V/µs): 10 Small-signal bandwidth (typ) (Hz): 2700000 Supply voltage (max) (V): 24 Supply voltage (min) (V): 4.5 Iq per channel (typ) (mA): 5.25 Operating temperature range (°C): -40 to 125 Rating: Automotive

INA1650

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: 双路 SoundPlus™ 高共模抑制 (91dB)、低 THD+N (-120dB) 差分线路接收器

Number of channels: 2 Voltage gain (V/V): 1 CMRR at RS = 0 Ω (min) (dB): 85 THD + N at 1 kHz (%): 0.00039 Noise floor (RTO, 20-kHz BW) (dBu): -104.7 Differential input impedance (kΩ): 1000 Common-mode input impedance (kΩ): 250 Slew rate (typ) (V/µs): 10 Small-signal bandwidth (typ) (Hz): 2700000 Supply voltage (max) (V): 36 Supply voltage (min) (V): 4.5 Iq per channel (typ) (mA): 5.25 Operating temperature range (°C): -40 to 125 Rating: Catalog Number of channels: 2 Voltage gain (V/V): 1 CMRR at RS = 0 Ω (min) (dB): 85 THD + N at 1 kHz (%): 0.00039 Noise floor (RTO, 20-kHz BW) (dBu): -104.7 Differential input impedance (kΩ): 1000 更多

Common-mode input impedance (kΩ): 250 Slew rate (typ) (V/µs): 10 Small-signal bandwidth (typ) (Hz): 2700000 Supply voltage (max) (V): 36 Supply voltage (min) (V): 4.5 Iq per channel (typ) (mA): 5.25 Operating temperature range (°C): -40 to 125 Rating: Catalog

IRS2452AM

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

Package: MLPQ 32 pins Technology: HVIC Output Current(Source): 500.0mA Output Current(Sink): 600.0mA V[CC] max: 15.0V Audio Input Type: Analog Speaker Channels: 2 Supply Voltage((V)): +/-200 Budgetary Price €/1k: 3.02

IRS2093MPBF

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: The IRS2093 integrates four channels of high voltage, high performance Class D audio amplifier drivers with PWM modulators and protections.

Output Current(Sink): 600.0mA Package: MLPQ 48 pins Technology: HVIC V[CC] max: 15.0V Output Current(Source): 500.0mA Audio Input Type: Analog Speaker Channels: 4 Supply Voltage((V)): +/-100

IRS20957SPBF

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: Protected Digital Audio Driver with Floating PWM input in a 16-Lead SOIC Narrow Package

Package: SOIC 16 pins Output Current(Source): 1000.0mA Output Current(Sink): 1200.0mA Technology: HVIC V[CC] max: 15.0V Audio Input Type: PWM Speaker Channels: 1 Supply Voltage((V)): +/-100

IRS2092SPBF

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: High Voltage, high performance Class D audio amplifier driver with PWM modulator and protection in a 16-Lead SOIC Narrow Package

Output Current(Sink): 1200.0mA Package: SOIC 16 pins Technology: HVIC Output Current(Source): 1000.0mA V[CC] max: 20.0V Audio Input Type: Analog Speaker Channels: 1 Supply Voltage((V)): +/-100

IR4321M

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: Integrated Digital Audio Amplifier

Technology: CMCM Package: PQFN 22 pins Description: Integrated 90W - 1 channel analog input Class-D amplifier Audio Input Type: Analog Speaker Channels: 1 Output Power((W per channel)): 90.0W Supply Voltage((V)): +/-25 or 50

IR4302M

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: 2 CH Integrated Class D Audio Amplifier

Technology: CMCM Package: QFN 44 pins Description: Integrated 130W - 2 channel analog input Class-D amplifier Audio Input Type: Analog Speaker Channels: 2 Output Power((W per channel)): 130.0W Supply Voltage((V)): +/-34 or 68 Download Model: https://www.infineon.com/api/redirect/ispn/IR4302M/#!simulation

IRS2461S

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: Discrete Class D Audio IC

Audio Input Type: Analog Output Current(Source): 500.0mA Output Current(Sink): 600.0mA Package: 20-lead SOIC Supply Voltage((V)): +/-200 Speaker Channels: 1 Technology: HVIC V[CC] max: 15.0V Description: 400 V single channel Class D audio amplifier

MA2304PNS

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 音频放大器

描述: MERUS™ class-D audio amplifier, 2x37 W, 10-20 V, ultra-low idle power, inductor-less operation, with volume control and peak limiter

Audio Input Type: I2S & TDM Speaker Channels: 2xBTL/1xPBTL Supply Voltage((V)): 20 Output Power((W per channel)): 37.0W Package: QFN 40 pins
