VO (V): 2.5 Initial accuracy (max) (%): 1 Iz for regulation (min) (µA): 400 Reference voltage (V): Fixed Rating: Space Temp coeff (max) (ppm/°C): 40 Operating temperature range (°C): -55 to 125 Iout/Iz (max) (mA): 10 VO (V): 2.5 Initial accuracy (max) (%): 1 Iz for regulation (min) (µA): 400 Reference voltage (V): Fixed Rating: Space Temp coeff (max) (ppm/°C): 40 Operating temperature range (°C): -55 to 125 Iout/Iz (max) (mA): 10

VO (V): 1.225 Initial accuracy (max) (%): 0.1, 0.2, 0.5 VO adj (min) (V): 1.24 VO adj (max) (V): 10 Iz for regulation (min) (µA): 60 Reference voltage (V): Fixed, adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 12 VO (V): 1.225 Initial accuracy (max) (%): 0.1, 0.2, 0.5 VO adj (min) (V): 1.24 VO adj (max) (V): 10 Iz for regulation (min) (µA): 60 Reference voltage (V): Fixed, adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 12

VO (V): 1.024, 1.25, 2.048, 2.5, 4.096 Initial accuracy (max) (%): 0.1 Temp coeff (max) (ppm/°C): 3, 6, 10 Vin (min) (V): 1.8 Vin (max) (V): 5.5 Iq (typ) (mA): 0.23, 0.265 Rating: Catalog Features: Enable pin LFN 0.1 to 10 Hz (typ) (µVPP): 2.2 Iout/Iz (max) (mA): 8 Operating temperature range (°C): 0 to 70 Shutdown current (ISD) (typ) (µA): 0.1 VO (V): 1.024, 1.25, 2.048, 2.5, 4.096 Initial accuracy (max) (%): 0.1 Temp coeff (max) (ppm/°C): 3, 6, 10 Vin (min) (V): 1.8 Vin (max) (V): 5.5 Iq (typ) (mA): 0.23, 0.265 Rating: Catalog Features: Enable pin 更多

VO (V): 1.24 Initial accuracy (max) (%): 1 VO adj (min) (V): 1.24 VO adj (max) (V): 30 Iz for regulation (min) (µA): 80 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 138 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 15 VO (V): 1.24 Initial accuracy (max) (%): 1 VO adj (min) (V): 1.24 VO adj (max) (V): 30 Iz for regulation (min) (µA): 80 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 138 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 15

VO (V): 1.24 Initial accuracy (max) (%): 1.5 VO adj (min) (V): 1.24 VO adj (max) (V): 30 Iz for regulation (min) (µA): 80 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 138 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 15 VO (V): 1.24 Initial accuracy (max) (%): 1.5 VO adj (min) (V): 1.24 VO adj (max) (V): 30 Iz for regulation (min) (µA): 80 Reference voltage (V): adjustable Rating: Catalog Temp coeff (max) (ppm/°C): 138 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 15

VO (V): 2.048, 2.5, 4.096, 4.1, 5, 8.192, 10 Initial accuracy (max) (%): 0.1, 0.2, 0.5 VO adj (min) (V): 2.048 VO adj (max) (V): 10 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 15 VO (V): 2.048, 2.5, 4.096, 4.1, 5, 8.192, 10 Initial accuracy (max) (%): 0.1, 0.2, 0.5 VO adj (min) (V): 2.048 VO adj (max) (V): 10 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 15

VO (V): 2.048, 2.5, 4.096, 5, 8.192, 10 Initial accuracy (max) (%): 0.1, 0.2, 0.5 VO adj (min) (V): 2.048 VO adj (max) (V): 10 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Automotive TI functional safety category: Functional Safety-Capable Temp coeff (max) (ppm/°C): 50 Operating temperature range (°C): -40 to 125 Iout/Iz (max) (mA): 15 VO (V): 2.048, 2.5, 4.096, 5, 8.192, 10 Initial accuracy (max) (%): 0.1, 0.2, 0.5 VO adj (min) (V): 2.048 VO adj (max) (V): 10 Iz for regulation (min) (µA): 45 Reference voltage (V): Fixed Rating: Automotive TI functional safety category: Functional Safety-Capable Temp coeff (max) (ppm/°C): 50 更多

VO (V): 3.3, 5 Initial accuracy (max) (%): 0.5, 1, 11 VO adj (min) (V): 3.3 VO adj (max) (V): 5 Iz for regulation (min) (µA): 85 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 61 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 15 VO (V): 3.3, 5 Initial accuracy (max) (%): 0.5, 1, 11 VO adj (min) (V): 3.3 VO adj (max) (V): 5 Iz for regulation (min) (µA): 85 Reference voltage (V): Fixed Rating: Catalog Temp coeff (max) (ppm/°C): 61 Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 15

VO (V): 5 Initial accuracy (max) (%): 0.2 Temp coeff (max) (ppm/°C): 10, 15 Vin (min) (V): 8 Vin (max) (V): 40 Iq (typ) (mA): 1 Rating: Catalog Features: TRIM/NR pin LFN 0.1 to 10 Hz (typ) (µVPP): 4 Iout/Iz (max) (mA): 21 Operating temperature range (°C): -40 to 85 VO (V): 5 Initial accuracy (max) (%): 0.2 Temp coeff (max) (ppm/°C): 10, 15 Vin (min) (V): 8 Vin (max) (V): 40 Iq (typ) (mA): 1 Rating: Catalog Features: TRIM/NR pin LFN 0.1 to 10 Hz (typ) (µVPP): 4 更多

VO (V): 1.2 Initial accuracy (max) (%): 0.3 VO adj (min) (V): 1.2 VO adj (max) (V): 1.2 Iz for regulation (min) (µA): 8 Reference voltage (V): Fixed Rating: Catalog Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 20 VO (V): 1.2 Initial accuracy (max) (%): 0.3 VO adj (min) (V): 1.2 VO adj (max) (V): 1.2 Iz for regulation (min) (µA): 8 Reference voltage (V): Fixed Rating: Catalog Operating temperature range (°C): -40 to 85 Iout/Iz (max) (mA): 20
