TMUX4827
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有 1.8V 兼容逻辑电平、超出电源电压 +/-12V 的 2:1 (SPDT) 双通道开关
Configuration: 2:1 SPDT
Number of channels: 2
Power supply voltage - single (V): 1.8, 2.5, 3.3, 5
Protocols: Analog Audio
Ron (typ) (Ω): 0.12
CON (typ) (pF): 100
ON-state leakage current (max) (µA): 1
Supply current (typ) (µA): 50
Bandwidth (MHz): 18.3
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 1100
Rating: Catalog
Drain supply voltage (max) (V): 12
Supply voltage (max) (V): 5.5
Configuration: 2:1 SPDT
Number of channels: 2
Power supply voltage - single (V): 1.8, 2.5, 3.3, 5
Protocols: Analog Audio
Ron (typ) (Ω): 0.12
CON (typ) (pF): 100
更多
ON-state leakage current (max) (µA): 1
Supply current (typ) (µA): 50
Bandwidth (MHz): 18.3
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 1100
Rating: Catalog
Drain supply voltage (max) (V): 12
Supply voltage (max) (V): 5.5
TMUX4051-Q1
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有 1.8V 兼容逻辑电平的汽车类 ±12V 8:1 单通道多路复用器
Configuration: 8:1
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 24
Power supply voltage - dual (V): +/-10, +/-12, +/-5
Protocols: Analog
Ron (typ) (Ω): 60
CON (typ) (pF): 11
ON-state leakage current (max) (µA): 1
Supply current (typ) (µA): 20
Bandwidth (MHz): 400
Operating temperature range (°C): -55 to 125
Features: 1.8-V compatible control inputs
Input/output continuous current (max) (mA): 10
Rating: Automotive
Drain supply voltage (max) (V): 24
Supply voltage (max) (V): 24
Configuration: 8:1
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 24
Power supply voltage - dual (V): +/-10, +/-12, +/-5
更多
Protocols: Analog
Ron (typ) (Ω): 60
CON (typ) (pF): 11
ON-state leakage current (max) (µA): 1
Supply current (typ) (µA): 20
Bandwidth (MHz): 400
Operating temperature range (°C): -55 to 125
Features: 1.8-V compatible control inputs
Input/output continuous current (max) (mA): 10
Rating: Automotive
Drain supply voltage (max) (V): 24
Supply voltage (max) (V): 24
TMUX4052-Q1
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有 1.8V 兼容逻辑电平的汽车类 ±12V 4:1 双通道多路复用器
Configuration: 4:1
Number of channels: 2
Power supply voltage - single (V): 5, 12, 16, 20, 24
Power supply voltage - dual (V): +/-10, +/-12, +/-5
Protocols: Analog
Ron (typ) (Ω): 60
CON (typ) (pF): 7
ON-state leakage current (max) (µA): 1
Supply current (typ) (µA): 20
Bandwidth (MHz): 500
Operating temperature range (°C): -55 to 125
Features: 1.8-V compatible control inputs
Input/output continuous current (max) (mA): 10
Rating: Automotive
Drain supply voltage (max) (V): 24
Supply voltage (max) (V): 24
Configuration: 4:1
Number of channels: 2
Power supply voltage - single (V): 5, 12, 16, 20, 24
Power supply voltage - dual (V): +/-10, +/-12, +/-5
更多
Protocols: Analog
Ron (typ) (Ω): 60
CON (typ) (pF): 7
ON-state leakage current (max) (µA): 1
Supply current (typ) (µA): 20
Bandwidth (MHz): 500
Operating temperature range (°C): -55 to 125
Features: 1.8-V compatible control inputs
Input/output continuous current (max) (mA): 10
Rating: Automotive
Drain supply voltage (max) (V): 24
Supply voltage (max) (V): 24
TMUX6201
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有 1.8V 逻辑电平和闩锁效应抑制的 36V、1:1 (SPST) 单通道精密开关（高电平有效）
Configuration: 1:1 SPST
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 36
Power supply voltage - dual (V): +/-10, +/-12, +/-15, +/-18, +/-5
Protocols: Analog
Ron (typ) (Ω): 1.6
CON (typ) (pF): 24
ON-state leakage current (max) (µA): 0.002
Supply current (typ) (µA): 30
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 500
Rating: Catalog
Drain supply voltage (max) (V): 36
Supply voltage (max) (V): 36
Negative rail supply voltage (max) (V): -4
Configuration: 1:1 SPST
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 36
Power supply voltage - dual (V): +/-10, +/-12, +/-15, +/-18, +/-5
Protocols: Analog
更多
Ron (typ) (Ω): 1.6
CON (typ) (pF): 24
ON-state leakage current (max) (µA): 0.002
Supply current (typ) (µA): 30
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 500
Rating: Catalog
Drain supply voltage (max) (V): 36
Supply voltage (max) (V): 36
Negative rail supply voltage (max) (V): -4
TMUX6202
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有 1.8V 逻辑电平和闩锁效应抑制的 36V、1:1 (SPST) 单通道精密开关（低电平有效）
Configuration: 1:1 SPST
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 24, 36
Power supply voltage - dual (V): +/-10, +/-12, +/-15, +/-18, +/-5
Protocols: Analog
Ron (typ) (Ω): 1
CON (typ) (pF): 24
ON-state leakage current (max) (µA): 0.0005
Supply current (typ) (µA): 3
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 500
Rating: Catalog
Drain supply voltage (max) (V): 36
Configuration: 1:1 SPST
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 24, 36
Power supply voltage - dual (V): +/-10, +/-12, +/-15, +/-18, +/-5
Protocols: Analog
Ron (typ) (Ω): 1
CON (typ) (pF): 24
更多
ON-state leakage current (max) (µA): 0.0005
Supply current (typ) (µA): 3
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 500
Rating: Catalog
Drain supply voltage (max) (V): 36
TMUX7201
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有 1.8V 逻辑电平和闩锁效应抑制的 44V、1:1 (SPST) 单通道精密开关（高电平有效）
Configuration: 1:1 SPST
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 36, 44
Power supply voltage - dual (V): +/-10, +/-15, +/-18, +/-22, +/-5
Protocols: Analog
Ron (typ) (Ω): 1.6
CON (typ) (pF): 24
ON-state leakage current (max) (µA): 0.002
Supply current (typ) (µA): 17
Bandwidth (MHz): 20
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 370
Rating: Catalog
Drain supply voltage (max) (V): 22
Supply voltage (max) (V): 44
Negative rail supply voltage (max) (V): -22
Configuration: 1:1 SPST
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 36, 44
Power supply voltage - dual (V): +/-10, +/-15, +/-18, +/-22, +/-5
更多
Protocols: Analog
Ron (typ) (Ω): 1.6
CON (typ) (pF): 24
ON-state leakage current (max) (µA): 0.002
Supply current (typ) (µA): 17
Bandwidth (MHz): 20
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 370
Rating: Catalog
Drain supply voltage (max) (V): 22
Supply voltage (max) (V): 44
Negative rail supply voltage (max) (V): -22
TMUX7202
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有 1.8V 逻辑电平和闩锁效应抑制的 44V、1:1 (SPST) 单通道精密开关（低电平有效）
Configuration: 1:1 SPST
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 24, 36, 44
Power supply voltage - dual (V): +/-10, +/-12, +/-15, +/-18, +/-22, +/-5
Protocols: Analog
Ron (typ) (Ω): 1.6
CON (typ) (pF): 24
ON-state leakage current (max) (µA): 0.002
Supply current (typ) (µA): 3
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 500
Rating: Catalog
Supply voltage (max) (V): 44
Negative rail supply voltage (max) (V): -18
Configuration: 1:1 SPST
Number of channels: 1
Power supply voltage - single (V): 5, 12, 16, 20, 24, 36, 44
Power supply voltage - dual (V): +/-10, +/-12, +/-15, +/-18, +/-22, +/-5
Protocols: Analog
Ron (typ) (Ω): 1.6
更多
CON (typ) (pF): 24
ON-state leakage current (max) (µA): 0.002
Supply current (typ) (µA): 3
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 500
Rating: Catalog
Supply voltage (max) (V): 44
Negative rail supply voltage (max) (V): -18
Configuration: 4:1
Number of channels: 2
Power supply voltage - single (V): 5, 12, 16, 20, 24
Power supply voltage - dual (V): +/-10, +/-12, +/-5
Protocols: Analog
Ron (typ) (Ω): 60
CON (typ) (pF): 7
ON-state leakage current (max) (µA): 0.1
Supply current (typ) (µA): 20
Bandwidth (MHz): 500
Operating temperature range (°C): -55 to 125
Features: 1.8-V compatible control inputs
Input/output continuous current (max) (mA): 10
Rating: Catalog
Drain supply voltage (max) (V): 24
Supply voltage (max) (V): 24
Configuration: 4:1
Number of channels: 2
Power supply voltage - single (V): 5, 12, 16, 20, 24
Power supply voltage - dual (V): +/-10, +/-12, +/-5
更多
Protocols: Analog
Ron (typ) (Ω): 60
CON (typ) (pF): 7
ON-state leakage current (max) (µA): 0.1
Supply current (typ) (µA): 20
Bandwidth (MHz): 500
Operating temperature range (°C): -55 to 125
Features: 1.8-V compatible control inputs
Input/output continuous current (max) (mA): 10
Rating: Catalog
Drain supply voltage (max) (V): 24
Supply voltage (max) (V): 24
Configuration: 2:1 SPDT
Number of channels: 3
Power supply voltage - single (V): 5, 12, 16, 20, 24
Power supply voltage - dual (V): +/-10, +/-12, +/-5
Protocols: Analog
Ron (typ) (Ω): 60
CON (typ) (pF): 5
ON-state leakage current (max) (µA): 0.1
Supply current (typ) (µA): 20
Bandwidth (MHz): 600
Operating temperature range (°C): -55 to 125
Features: 1.8-V compatible control inputs
Input/output continuous current (max) (mA): 10
Rating: Catalog
Drain supply voltage (max) (V): 24
Supply voltage (max) (V): 24
Configuration: 2:1 SPDT
Number of channels: 3
Power supply voltage - single (V): 5, 12, 16, 20, 24
Power supply voltage - dual (V): +/-10, +/-12, +/-5
更多
Protocols: Analog
Ron (typ) (Ω): 60
CON (typ) (pF): 5
ON-state leakage current (max) (µA): 0.1
Supply current (typ) (µA): 20
Bandwidth (MHz): 600
Operating temperature range (°C): -55 to 125
Features: 1.8-V compatible control inputs
Input/output continuous current (max) (mA): 10
Rating: Catalog
Drain supply voltage (max) (V): 24
Supply voltage (max) (V): 24
TMUX8211
数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 模拟开关电路
描述: 具有闩锁效应抑制和 1.8V 逻辑电平（逻辑低电平）的 100V、扁平 RON、1:1 (SPST)、四通道开关
Configuration: 1:1 SPST
Number of channels: 4
Power supply voltage - single (V): 12, 16, 20, 36, 44, 72, 100
Power supply voltage - dual (V): +/-10, +/-15, +/-18, +/-22, +/-36, +/-50
Protocols: Analog
Ron (typ) (Ω): 5
CON (typ) (pF): 14
ON-state leakage current (max) (µA): 0.07
Supply current (typ) (µA): 350
Bandwidth (MHz): 420
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 125
Rating: Catalog
Drain supply voltage (max) (V): 100
Supply voltage (max) (V): 100
Negative rail supply voltage (max) (V): -50
Configuration: 1:1 SPST
Number of channels: 4
Power supply voltage - single (V): 12, 16, 20, 36, 44, 72, 100
Power supply voltage - dual (V): +/-10, +/-15, +/-18, +/-22, +/-36, +/-50
更多
Protocols: Analog
Ron (typ) (Ω): 5
CON (typ) (pF): 14
ON-state leakage current (max) (µA): 0.07
Supply current (typ) (µA): 350
Bandwidth (MHz): 420
Operating temperature range (°C): -40 to 125
Input/output continuous current (max) (mA): 125
Rating: Catalog
Drain supply voltage (max) (V): 100
Supply voltage (max) (V): 100
Negative rail supply voltage (max) (V): -50
