天天芯片 - 物料搜索

TLD6098-1EP

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: DC-DC boost controller with spread spectrum frequency modulation and with built-in diagnosis and protection features designed for LED drivers.

Topology: Multitopology DC-DC controller f[SW] max: 2200.0kHz Tolerance: 3.5% Short Circuit Protection: Yes PWM: Yes Open Load Detection: Yes I[Q]: 5000.0µA Operating Temperature max: 150.0°C Dimming: Analog and Digital Type: Multitopology V[S] max: 60.0V Family: LITIX™ Power Currently planned availability until at least: 2038

TLD5099EP

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: LITIX™ Power TLD5099EP is a flexibly usable DC-DC boost controller with built in diagnosis and protection features especially designed to drive LEDs

Topology: Multitopology DC-DC controller f[SW] max: 500.0kHz Tolerance: 3.3% Short Circuit Protection: Yes PWM: Yes Open Load Detection: Yes I[q]: 10.0µA Operating Temperature max: 150.0°C Dimming: Analog and Digital Type: Multitopology V[S] max: 45.0V

TLD5098EP

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: The TLD5098EP is a LED boost controller with built in protection features

Topology: Multitopology DC-DC controller Short Circuit Protection: Yes PWM: Yes Open Load Detection: Yes Operating Temperature max: 150.0°C f[SW] max: 500.0kHz Tolerance: 3.3% I[q]: 10.0µA Dimming: Analog and Digital Type: Multitopology V[S] max: 45.0V

TLD5191ES

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: TLD5191ES - a synchronous MOSFET H-Bridge DC-DC controller with built-in protection features

I[q]: 1.5µA Inhibit: yes Open Load Detection: yes Short Circuit Protection: yes PWM: external or embedded PWM engine f[SW] max: 700.0kHz Operating Temperature max: 150.0°C Dimming: Analog and Digital Type: Buck-boost V[S] max: 40.0V

TLD1125EL

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: LITIX™ Basic TLD1125EL is a one channel high side driver IC with integrated output stages

V[S] max: 40.0V Output Current: 180.0mA I[q]: 0.1µA Operating Temperature max: 150.0°C Topology: Linear V[Q] (multiple): 40.0 V Tolerance: 7% Short Circuit Protection: Yes Inhibit: Yes PWM: Yes Open Load Detection: Yes Control Inputs: 1.0 Output Channels: 1.0 PWM engine: Yes Short GND Detection: Yes Feedback Output: No Language: SPICE Product Category: Automotive Lighting ICs Family: LITIX™ Basic Currently planned availability until at least: 2038

TLD5045EJ

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: The TLD5045 is a highly integrated smart LED buck converter with built in protection functions

I[Q] max: 700.0mA f[SW] max: 300.0kHz I[q]: 2.0µA Operating Temperature max: 150.0°C Topology: DC-DC Buck Short Circuit Protection: Yes Inhibit: Yes PWM: Yes Open Load Detection: Yes Classification: -- Dimming: Analog and Digital I[out] max: 700.0mA Type: Buck V[S] max: 40.0V

TLD5098EL

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: The TLD5098EL is a LED boost controller with built in protection features

V[S] max: 45.0V f[SW] max: 500.0kHz I[q]: 10.0µA Operating Temperature max: 150.0°C Topology: DC-DC Boost, Buck, Sepic, Buck-Boost, Flyback Tolerance: 3.3% Short Circuit Protection: Yes Inhibit: Yes PWM: Yes Open Load Detection: Yes

TLD5095EL

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: The TLD5095EL is a LED boost controller with built in protection features

TLD1314EL

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: LITIX™ Basic TLD1314EL is a three channel high side driver IC with integrated output stages

V[S] max: 40.0V I[q]: 0.1µA Operating Temperature max: 150.0°C Output Current: 60.0mA Topology: Linear V[Q] (multiple): 40.0 V Tolerance: 7% Short Circuit Protection: Yes Inhibit: No PWM: Yes Open Load Detection: Yes Short GND Detection: Yes Feedback Output: No Control Inputs: 1.0 Output Channels: 3.0 PWM engine: No Language: SPICE Product Category: Automotive Lighting ICs Family: LITIX™ Basic Currently planned availability until at least: 2038

TLD5097EL

数据:
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 非线性电路 / 开关电源电路

描述: The TLD5097EL is a LED boost controller with built in protection features
