Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 2 IOL (max) (mA): 32 Input type: Standard CMOS IOH (max) (mA): -32 Output type: Push-Pull Data rate (max) (Mbps): 100 Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125 Technology family: LVC Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Number of channels: 1 Inputs per channel: 2 IOL (max) (mA): 32 Input type: Standard CMOS IOH (max) (mA): -32 更多

Technology family: AC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 3 Inputs per channel: 3 IOL (max) (mA): 24 IOH (max) (mA): -24 Input type: Standard CMOS Output type: Push-Pull Features: Very high speed (tpd 5-10ns) Data rate (max) (Mbps): 100 Rating: Automotive Operating temperature range (°C): -40 to 85 Technology family: AC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 3 Inputs per channel: 3 IOL (max) (mA): 24 IOH (max) (mA): -24 更多

Number of channels: 2 Technology family: ACT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Input type: TTL-Compatible CMOS Output type: Push-Pull Clock frequency (max) (MHz): 85 IOL (max) (mA): 24 IOH (max) (mA): -24 Supply current (max) (µA): 80 Operating temperature range (°C): -40 to 125 Rating: Automotive Number of channels: 2 Technology family: ACT Supply voltage (min) (V): 4.5 Supply voltage (max) (V): 5.5 Input type: TTL-Compatible CMOS Output type: Push-Pull Clock frequency (max) (MHz): 85 IOL (max) (mA): 24 更多

Number of channels: 16 Technology family: AUC Supply voltage (min) (V): 0.8 Supply voltage (max) (V): 2.7 Input type: Standard CMOS Output type: 3-State Clock frequency (max) (MHz): 250 IOL (max) (mA): 9 IOH (max) (mA): -9 Supply current (max) (µA): 20 Operating temperature range (°C): -40 to 85 Rating: Catalog Number of channels: 16 Technology family: AUC Supply voltage (min) (V): 0.8 Supply voltage (max) (V): 2.7 Input type: Standard CMOS Output type: 3-State Clock frequency (max) (MHz): 250 IOL (max) (mA): 9 更多

Technology family: LVC Number of channels: 4 Supply voltage (min) (V): 2 Supply voltage (max) (V): 3.6 Inputs per channel: 2 IOL (max) (mA): 24 IOH (max) (mA): -24 Output type: Push-Pull Input type: Standard CMOS Data rate (max) (Mbps): 100 Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125 Technology family: LVC Number of channels: 4 Supply voltage (min) (V): 2 Supply voltage (max) (V): 3.6 Inputs per channel: 2 IOL (max) (mA): 24 IOH (max) (mA): -24 Output type: Push-Pull 更多

Number of channels: 2 Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Technology family: AHC Input type: Schmitt-Trigger Output type: Push-Pull Supply current (µA): 40 IOL (max) (mA): 8 IOH (max) (mA): -8 Operating temperature range (°C): -55 to 125 Rating: HiRel Enhanced Product Number of channels: 2 Supply voltage (min) (V): 2 Supply voltage (max) (V): 5.5 Technology family: AHC Input type: Schmitt-Trigger Output type: Push-Pull Supply current (µA): 40 IOL (max) (mA): 8 IOH (max) (mA): -8 更多

Number of channels: 2 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Input type: CMOS Output type: Push-Pull Clock frequency (MHz): 20 Supply current (max) (µA): 80 IOL (max) (mA): -4 IOH (max) (mA): 4 Operating temperature range (°C): -55 to 125 Rating: Space Number of channels: 2 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Input type: CMOS Output type: Push-Pull Clock frequency (MHz): 20 Supply current (max) (µA): 80 更多

Function: Counter Bits (#): 4 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Input type: Standard CMOS Output type: Push-Pull Operating temperature range (°C): -55 to 125 Rating: Space Function: Counter Bits (#): 4 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Input type: Standard CMOS Output type: Push-Pull Operating temperature range (°C): -55 to 125 Rating: Space

Configuration: Parallel-in, Serial-out Bits (#): 8 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Input type: Standard CMOS Output type: Push-Pull Clock frequency (MHz): 24 IOL (max) (mA): 5.2 IOH (max) (mA): -5.2 Supply current (max) (µA): 160 Operating temperature range (°C): -55 to 125 Rating: Space Configuration: Parallel-in, Serial-out Bits (#): 8 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Input type: Standard CMOS Output type: Push-Pull 更多

Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 2 Inputs per channel: 4 IOL (max) (mA): 5.2 IOH (max) (mA): -5.2 Input type: Standard CMOS Output type: Push-Pull Features: High speed (tpd 10- 50ns) Data rate (max) (Mbps): 28 Rating: Space Operating temperature range (°C): -55 to 125 Technology family: HC Supply voltage (min) (V): 2 Supply voltage (max) (V): 6 Number of channels: 2 Inputs per channel: 4 IOL (max) (mA): 5.2 IOH (max) (mA): -5.2 更多
