PCA82C250


分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

TS3USBA225


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: DP3T USB 2.0 高速 (480Mbps) 音频开关

Type: Passive mux Function: USB 2.0 USB speed (Mbps): 480 Number of channels: 2 Supply voltage (max) (V): 5 Supply voltage (min) (V): 2.7 Ron (typ) (mΩ): 6500 Input/output voltage (min) (V): -1.8 Input/output voltage (max) (V): 4.3 Configuration: 3:1 Rating: Catalog Operating temperature range (°C): -40 to 85 Supply current (max) (µA): 50 ESD HBM (typ) (kV): 2 Bandwidth (MHz): 1900 Type: Passive mux Function: USB 2.0 USB speed (Mbps): 480 Number of channels: 2 Supply voltage (max) (V): 5
Supply voltage (min) (V): 2.7 Ron (typ) (mΩ): 6500 Input/output voltage (min) (V): -1.8 Input/output voltage (max) (V): 4.3 Configuration: 3:1 Rating: Catalog Operating temperature range (°C): -40 to 85 Supply current (max) (µA): 50 ESD HBM (typ) (kV): 2 Bandwidth (MHz): 1900

TS5USBA224


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: 具有负信号处理能力的 USB 2.0 高速 (480Mbps) 和音频开关

Type: Passive mux Function: USB 2.0 USB speed (Mbps): 480 Number of channels: 2 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.7 Ron (typ) (mΩ): 4000 Input/output voltage (min) (V): -2.8 Input/output voltage (max) (V): 5.5 Configuration: 2:1 SPDT Rating: Catalog Operating temperature range (°C): -40 to 85 Supply current (max) (µA): 10 ESD HBM (typ) (kV): 2 Bandwidth (MHz): 650 Type: Passive mux Function: USB 2.0 USB speed (Mbps): 480 Number of channels: 2 Supply voltage (max) (V): 5.5
Supply voltage (min) (V): 2.7 Ron (typ) (mΩ): 4000 Input/output voltage (min) (V): -2.8 Input/output voltage (max) (V): 5.5 Configuration: 2:1 SPDT Rating: Catalog Operating temperature range (°C): -40 to 85 Supply current (max) (µA): 10 ESD HBM (typ) (kV): 2 Bandwidth (MHz): 650

TCAN1043N-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: 具有唤醒、抑制和睡眠功能的汽车级 CAN FD 收发器

Protocols: CAN, CAN FD Number of channels: 1 Supply voltage (V): 4.5 to 40 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive Protocols: CAN, CAN FD Number of channels: 1 Supply voltage (V): 4.5 to 40 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive

TCAN1473-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: 具有 INH 和 WAKE 引脚及信号改善功能的汽车级低功耗 CAN FD 收发器

Protocols: CAN, CAN FD, CAN SIC Number of channels: 1 Supply voltage (V): 4.5 to 40 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive Protocols: CAN, CAN FD, CAN SIC Number of channels: 1 Supply voltage (V): 4.5 to 40 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive

TCAN1473A-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: 具有 INH 和 WAKE 引脚及信号改善功能的汽车级低功耗 CAN FD 收发器

Protocols: CAN, CAN FD, CAN SIC Number of channels: 1 Supply voltage (V): 4.5 to 28 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive Protocols: CAN, CAN FD, CAN SIC Number of channels: 1 Supply voltage (V): 4.5 to 28 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive

TCAN1472-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: 具有待机功能的汽车类信号改善 CAN FD 收发器

Protocols: CAN, CAN FD, CAN SIC Number of channels: 1 Supply voltage (V): 4.5 to 5.5 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive Protocols: CAN, CAN FD, CAN SIC Number of channels: 1 Supply voltage (V): 4.5 to 5.5 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive

TCAN3403-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: 具有灵活 I/O 和待机模式的汽车级 3.3V CAN 灵活数据速率 (FD) 收发器

Protocols: CAN, CAN FD Number of channels: 1 Supply voltage (V): 3 to 3.6 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive Protocols: CAN, CAN FD Number of channels: 1 Supply voltage (V): 3 to 3.6 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive

TCAN3404-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: 具有关断和待机模式的汽车级 3.3V CAN 灵活数据速率 (FD) 收发器

Protocols: CAN, CAN FD Number of channels: 1 Supply voltage (V): 3 to 3.6 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive Protocols: CAN, CAN FD Number of channels: 1 Supply voltage (V): 3 to 3.6 Bus fault voltage (V): -58 to 58 Signaling rate (max) (bps): 8000000 Rating: Automotive

TUSB2E221


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 总线接口电路

描述: 2 端口 eUSB2 转 USB2.0 中继器，eUSB 1.2

Type: Redriver Function: USB 2.0 USB speed (Mbps): 480 Number of channels: 2 Supply voltage (max) (V): 1.98, 3.6 Supply voltage (min) (V): 1.62, 3 Input/output voltage (min) (V): 0 Input/output voltage (max) (V): 3.6 Configuration: Dual-channel Rating: Catalog Operating temperature range (°C): -40 to 85 ESD HBM (typ) (kV): 1.5 Bandwidth (MHz): 240 Type: Redriver Function: USB 2.0 USB speed (Mbps): 480 Number of channels: 2 Supply voltage (max) (V): 1.98, 3.6 Supply voltage (min) (V): 1.62, 3 Input/output voltage (min) (V): 0
Input/output voltage (max) (V): 3.6 Configuration: Dual-channel Rating: Catalog Operating temperature range (°C): -40 to 85 ESD HBM (typ) (kV): 1.5 Bandwidth (MHz): 240
