Resolution (Bits): 24 Sample rate (max) (ksps): 0.03 Number of input channels: 1 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: 50/60 Hz Rejection Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 0.27 Analog supply (min) (V): 2.5 Analog supply voltage (max) (V): 5.25 Digital supply (min) (V): 1.8 Digital supply (max) (V): 3.6 Resolution (Bits): 24 Sample rate (max) (ksps): 0.03 Number of input channels: 1 更多

Resolution (Bits): 24 Sample rate (max) (ksps): 0.015 Number of input channels: 8 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: 50/60 Hz Rejection, GPIO, PGA Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 0.6 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 24 Sample rate (max) (ksps): 0.015 更多

Resolution (Bits): 24 Sample rate (max) (ksps): 0.015 Number of input channels: 4 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: 50/60 Hz Rejection, GPIO, PGA Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 0.6 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 24 Sample rate (max) (ksps): 0.015 更多

Resolution (Bits): 24 Sample rate (max) (ksps): 0.015 Number of input channels: 8 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: 50/60 Hz Rejection, GPIO, PGA Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 0.6 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 24 Sample rate (max) (ksps): 0.015 更多

Resolution (Bits): 24 Sample rate (max) (ksps): 0.015 Number of input channels: 4 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: 50/60 Hz Rejection, GPIO, PGA Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 0.6 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.25 Resolution (Bits): 24 Sample rate (max) (ksps): 0.015 更多

Number of ADC channels: 2 Analog inputs: 2 Digital audio interface: I2S, L, R Control interface: H/W Sampling rate (max) (kHz): 48 ADC SNR (typ) (dB): 95 Rating: Catalog Analog outputs: 0 Operating temperature range (°C): to Number of ADC channels: 2 Analog inputs: 2 Digital audio interface: I2S, L, R Control interface: H/W Sampling rate (max) (kHz): 48 ADC SNR (typ) (dB): 95 Rating: Catalog Analog outputs: 0 Operating temperature range (°C): to

Sample rate (max) (Msps): 500 Resolution (Bits): 16 Number of input channels: 2 Interface type: DDR LVDS Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 640 Architecture: Pipeline SNR (dB): 75.2 ENOB (Bits): 12.3 SFDR (dB): 80 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 500 Resolution (Bits): 16 Number of input channels: 2 Interface type: DDR LVDS Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 640 更多

Number of channels: 1 Gain (min) (dB): 1 Gain (max) (dB): 1 Pd (typ) (mW): 20 Supply voltage (max) (V): 14 Operating temperature range (°C): 0 to 85 Output data format: Analog Rating: Catalog Number of channels: 1 Gain (min) (dB): 1 Gain (max) (dB): 1 Pd (typ) (mW): 20 Supply voltage (max) (V): 14 Operating temperature range (°C): 0 to 85 Output data format: Analog Rating: Catalog

Resolution (Bits): 16 Sample rate (max) (ksps): 0.215 Number of input channels: 4 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.5 Input voltage range (min) (V): 0 Features: PGA Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 1.2 Analog supply (min) (V): 2.85 Analog supply voltage (max) (V): 5.5 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.5 Resolution (Bits): 16 Sample rate (max) (ksps): 0.215 更多

Resolution (Bits): 16 Sample rate (max) (ksps): 0.215 Number of input channels: 4 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.5 Input voltage range (min) (V): 0 Features: Excitation Current Sources (iDACs), PGA Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 1.2 Analog supply (min) (V): 2.85 Analog supply voltage (max) (V): 5.5 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.5 Resolution (Bits): 16 Sample rate (max) (ksps): 0.215 更多
