Device type: Transmitter Number of input channels: 2 Active supply current (typ) (mA): 17 Supply voltage (max) (V): 5.25 Operating temperature range (°C): 0 to 85 Interface type: Serial Rating: Catalog Device type: Transmitter Number of input channels: 2 Active supply current (typ) (mA): 17 Supply voltage (max) (V): 5.25 Operating temperature range (°C): 0 to 85 Interface type: Serial Rating: Catalog

Resolution (Bits): 14 Sample rate (max) (ksps): 2000 Number of input channels: 2 Interface type: SPI Architecture: SAR Input type: Differential Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: Small Size Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 10.5 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 84 Digital supply (min) (V): 1.65 Digital supply (max) (V): 5.25 Resolution (Bits): 14 更多

Resolution (Bits): 14 Sample rate (max) (ksps): 2000 Number of input channels: 2 Interface type: SPI Architecture: SAR Input type: Pseudo-Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.25 Input voltage range (min) (V): 0 Features: Small Size Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 10.5 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 82 Digital supply (min) (V): 1.65 Digital supply (max) (V): 5.25 Resolution (Bits): 14 更多

Sample rate (max) (Msps): 1000, 2000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2700 Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 3510 Architecture: Folding Interpolating SNR (dB): 60.1 ENOB (Bits): 9.6 SFDR (dB): 75 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 1000, 2000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2700 更多

Sample rate (max) (Msps): 1600, 3200 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2700 Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 3880 Architecture: Folding Interpolating SNR (dB): 59 ENOB (Bits): 9.4 SFDR (dB): 75 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 1600, 3200 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2700 更多

Sample rate (max) (Msps): 1800, 3600 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2700 Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 4400 Architecture: Folding Interpolating SNR (dB): 58.6 ENOB (Bits): 9.3 SFDR (dB): 71.7 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 1800, 3600 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2700 更多

Sample rate (max) (Msps): 500, 1000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2700 Features: Low Power Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 2020 Architecture: Folding Interpolating SNR (dB): 60.4 ENOB (Bits): 9.7 SFDR (dB): 74.3 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 500, 1000 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2700 更多

Sample rate (max) (Msps): 100 Resolution (Bits): 14, 16, 18 Number of input channels: 4 Interface type: Parallel LVDS Analog input BW (MHz): 70 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 4 Power consumption (typ) (mW): 1350 Architecture: Pipeline SNR (dB): 85.5 ENOB (Bits): 12.8 SFDR (dB): 81 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 100 Resolution (Bits): 14, 16, 18 Number of input channels: 4 Interface type: Parallel LVDS Analog input BW (MHz): 70 更多

Resolution (Bits): 16 Number of channels: 4 Sample rate (Msps): 50 Gain (min) (dB): -6 Gain (max) (dB): 17 Pd (typ) (mW): 406 Supply voltage (max) (V): 3.3 Operating temperature range (°C): 0 to 85 Output data format: CMOS Selectable, Standard LVDS Rating: Catalog Resolution (Bits): 16 Number of channels: 4 Sample rate (Msps): 50 Gain (min) (dB): -6 Gain (max) (dB): 17 Pd (typ) (mW): 406 Supply voltage (max) (V): 3.3 Operating temperature range (°C): 0 to 85 Output data format: CMOS Selectable, Standard LVDS Rating: Catalog

Resolution (Bits): 12 Sample rate (max) (ksps): 1000 Number of input channels: 4 Interface type: SPI Architecture: SAR Input type: Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 10 Input voltage range (min) (V): -10 Features: Comparator Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 14.45 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.25 SNR (dB): 71.8 Digital supply (min) (V): 1.65 Digital supply (max) (V): 5.25 Resolution (Bits): 12 更多
