Sample rate (max) (Msps): 135 Resolution (Bits): 16 Number of input channels: 1 Interface type: Parallel LVDS Analog input BW (MHz): 485 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 3 Power consumption (typ) (mW): 2100 Architecture: Pipeline SNR (dB): 79 ENOB (Bits): 12.6 SFDR (dB): 97 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 135 Resolution (Bits): 16 Number of input channels: 1 Interface type: Parallel LVDS Analog input BW (MHz): 485 更多

Sample rate (max) (Msps): 105 Resolution (Bits): 14 Number of input channels: 1 Interface type: Parallel CMOS Analog input BW (MHz): 570 Features: High Performance Rating: Space Peak-to-peak input voltage range (V): 2.2 Power consumption (typ) (mW): 1900 Architecture: Pipeline SNR (dB): 72.4 ENOB (Bits): 11.7 SFDR (dB): 82.6 Operating temperature range (°C): -55 to 125 Input buffer: No Sample rate (max) (Msps): 105 Resolution (Bits): 14 Number of input channels: 1 Interface type: Parallel CMOS Analog input BW (MHz): 570 更多

Resolution (Bits): 31 Sample rate (max) (ksps): 4 Number of input channels: 2 Interface type: SPI Architecture: Delta-Sigma Input type: Differential Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External Input voltage range (max) (V): 1.15, 3.75 Input voltage range (min) (V): -1.9, 0.7 Features: PGA Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 25 Analog supply (min) (V): -2.5, 0 Analog supply voltage (max) (V): 2.5, 5 SNR (dB): 130 Digital supply (min) (V): 1.65 Digital supply (max) (V): 3.6 Resolution (Bits): 31 更多

Sample rate (max) (Msps): 40 Resolution (Bits): 16 Number of input channels: 1 Interface type: Parallel CMOS, Parallel LVDS Analog input BW (MHz): 250 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 3.6 Power consumption (typ) (mW): 674 Architecture: Pipeline SNR (dB): 84.3 ENOB (Bits): 13.5 SFDR (dB): 90 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 40 Resolution (Bits): 16 Number of input channels: 1 Interface type: Parallel CMOS, Parallel LVDS Analog input BW (MHz): 250 更多

Sample rate (max) (Msps): 80 Resolution (Bits): 16 Number of input channels: 1 Interface type: Parallel CMOS, Parallel LVDS Analog input BW (MHz): 250 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 3.6 Power consumption (typ) (mW): 865 Architecture: Pipeline SNR (dB): 84 ENOB (Bits): 13.1 SFDR (dB): 85 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 80 Resolution (Bits): 16 Number of input channels: 1 Interface type: Parallel CMOS, Parallel LVDS Analog input BW (MHz): 250 更多

Sample rate (max) (Msps): 1500, 3000 Resolution (Bits): 8 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2000 Features: Ultra High Speed Rating: Space Peak-to-peak input voltage range (V): 0.87 Power consumption (typ) (mW): 2000 Architecture: Folding Interpolating SNR (dB): 47 ENOB (Bits): 7.4 SFDR (dB): 55.5 Operating temperature range (°C): -55 to 125 Input buffer: Yes Radiation, TID (typ) (krad): 300 Radiation, SEL (MeV·cm2/mg): 120 Sample rate (max) (Msps): 1500, 3000 Resolution (Bits): 8 Number of input channels: 1, 2 更多

Sample rate (max) (Msps): 1000, 2000 Resolution (Bits): 10 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2800 Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 2770 Architecture: Folding Interpolating SNR (dB): 57 ENOB (Bits): 9.1 SFDR (dB): 70 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 1000, 2000 Resolution (Bits): 10 Number of input channels: 1, 2 Interface type: Parallel LVDS Analog input BW (MHz): 2800 更多

Number of input channels: 16 Resolution (Bits): 16 Features: Computed Tomography (CT) Operating temperature range (°C): 0 to 70 Interface type: Serial Rating: Catalog Number of input channels: 16 Resolution (Bits): 16 Features: Computed Tomography (CT) Operating temperature range (°C): 0 to 70 Interface type: Serial Rating: Catalog

Sample rate (max) (Msps): 65 Resolution (Bits): 10 Number of input channels: 8 Interface type: Serial LVDS Analog input BW (MHz): 520 Features: Low Power Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 616 Architecture: Pipeline SNR (dB): 61.7 ENOB (Bits): 9.94 SFDR (dB): 85 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 65 Resolution (Bits): 10 Number of input channels: 8 Interface type: Serial LVDS Analog input BW (MHz): 520 更多

Sample rate (max) (Msps): 65 Resolution (Bits): 12 Number of input channels: 8 Interface type: Serial LVDS Analog input BW (MHz): 520 Features: Low Power Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 616 Architecture: Pipeline SNR (dB): 70 ENOB (Bits): 11.3 SFDR (dB): 85 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 65 Resolution (Bits): 12 Number of input channels: 8 Interface type: Serial LVDS Analog input BW (MHz): 520 更多
