Sample rate (max) (Msps): 65 Resolution (Bits): 12 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 1050 Architecture: Pipeline SNR (dB): 71.4 ENOB (Bits): 11.5 SFDR (dB): 93 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 65 Resolution (Bits): 12 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 更多

Sample rate (max) (Msps): 80 Resolution (Bits): 12 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 1180 Architecture: Pipeline SNR (dB): 71.4 ENOB (Bits): 11.5 SFDR (dB): 91 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 80 Resolution (Bits): 12 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 更多

Sample rate (max) (Msps): 105 Resolution (Bits): 12 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 1350 Architecture: Pipeline SNR (dB): 71.2 ENOB (Bits): 11.4 SFDR (dB): 91 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 105 Resolution (Bits): 12 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 更多

Sample rate (max) (Msps): 500 Resolution (Bits): 8 Number of input channels: 1 Interface type: Parallel LVDS Analog input BW (MHz): 1700 Features: Low Power Rating: Catalog Peak-to-peak input voltage range (V): 0.87 Power consumption (typ) (mW): 800 Architecture: Folding Interpolating SNR (dB): 48 ENOB (Bits): 7.5 SFDR (dB): 56 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 500 Resolution (Bits): 8 Number of input channels: 1 Interface type: Parallel LVDS Analog input BW (MHz): 1700 更多

Sample rate (max) (Msps): 3000 Resolution (Bits): 8 Number of input channels: 1 Interface type: Parallel LVDS Analog input BW (MHz): 3000 Features: Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 0.82 Power consumption (typ) (mW): 1900 Architecture: Folding Interpolating SNR (dB): 45.4 ENOB (Bits): 7.2 SFDR (dB): 57 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 3000 Resolution (Bits): 8 Number of input channels: 1 Interface type: Parallel LVDS Analog input BW (MHz): 3000 更多

Resolution (Bits): 16 Sample rate (max) (ksps): 250 Number of input channels: 1 Interface type: SPI Architecture: SAR Input type: Single-ended Rating: Catalog Reference mode: External Input voltage range (max) (V): 5.5 Input voltage range (min) (V): 0 Operating temperature range (°C): -40 to 85 Power consumption (typ) (mW): 10 Analog supply (min) (V): 2.7 Analog supply voltage (max) (V): 5.5 SNR (dB): 91.5 Digital supply (min) (V): 2.7 Digital supply (max) (V): 5.5 Resolution (Bits): 16 Sample rate (max) (ksps): 250 Number of input channels: 1 更多

Sample rate (max) (Msps): 65 Resolution (Bits): 14 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 1050 Architecture: Pipeline SNR (dB): 74.5 ENOB (Bits): 12 SFDR (dB): 93 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 65 Resolution (Bits): 14 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 更多

Sample rate (max) (Msps): 80 Resolution (Bits): 14 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 1180 Architecture: Pipeline SNR (dB): 74.4 ENOB (Bits): 11.9 SFDR (dB): 92 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 80 Resolution (Bits): 14 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 更多

Sample rate (max) (Msps): 105 Resolution (Bits): 14 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 1350 Architecture: Pipeline SNR (dB): 73.8 ENOB (Bits): 11.7 SFDR (dB): 91 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 105 Resolution (Bits): 14 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 更多

Sample rate (max) (Msps): 125 Resolution (Bits): 14 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 Features: High Performance Rating: Catalog Peak-to-peak input voltage range (V): 2 Power consumption (typ) (mW): 1680 Architecture: Pipeline SNR (dB): 73.7 ENOB (Bits): 11.7 SFDR (dB): 87 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 125 Resolution (Bits): 14 Number of input channels: 4 Interface type: Serial LVDS Analog input BW (MHz): 500 更多
