AFE639D2
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 具有 TEC 控制功能以及内置 ADC 和 DAC 的双通道 12 位智能模拟前端 (AFE)
Resolution (Bits): 12
Number of DAC channels: 2
Interface type: I2C
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: Smart DAC
Resolution (Bits): 12
Number of DAC channels: 2
Interface type: I2C
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: Smart DAC
DAC53004W
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 采用 WCSP 封装、具有 Hi-Z、EEPROM 和波形发生器的 10 位、4 通道低功耗 VOUT 和 IOUT 智能 DAC
Resolution (Bits): 10
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: Current source/sink DAC, EEPROM, Low Power, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.13
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
Resolution (Bits): 10
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: Current source/sink DAC, EEPROM, Low Power, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.13
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
DAC63004W
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 采用 Wafer Chip Scale Package 且具有 I²C、SPI 和 PWM 的超低功耗四通道 12 位智能 DAC
Resolution (Bits): 12
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 4
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: Current source/sink DAC, EEPROM, Low Power, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.13
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
Resolution (Bits): 12
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 4
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: Current source/sink DAC, EEPROM, Low Power, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.13
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
DAC63204W
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 采用 WCSP 封装且具有 Hi-Z、EEPROM 和波形发生器的 12 位、4 通道电压/电流输出智能 DAC
Resolution (Bits): 12
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 4
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: Current source/sink DAC, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
Resolution (Bits): 12
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 4
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: Current source/sink DAC, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
AFE53902-Q1
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 具有用于多斜率热折返控制的 ADC 和 PWM 输出的汽车类、10 位、双通道智能 DAC
Resolution (Bits): 10
Number of DAC channels: 2
Interface type: I2C, SPI
Output type: Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Automotive
Features: (x1) PWM, EEPROM, Integrated ADC, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: Smart DAC
Resolution (Bits): 10
Number of DAC channels: 2
Interface type: I2C, SPI
Output type: Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Automotive
Features: (x1) PWM, EEPROM, Integrated ADC, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: Smart DAC
DAC53204-Q1
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 具有 Hi-Z、EEPROM 和波形发生器的汽车类、10 位、4 通道电压/电流输出智能 DAC
Resolution (Bits): 10
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Automotive
Features: Current source/sink DAC, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
Resolution (Bits): 10
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Automotive
Features: Current source/sink DAC, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
DAC63204-Q1
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 具有 Hi-Z、EEPROM 和波形发生器的汽车类、12 位、4 通道电压/电流输出智能 DAC
Resolution (Bits): 12
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 4
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Automotive
Features: Current source/sink DAC, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
Resolution (Bits): 12
Number of DAC channels: 4
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 4
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Automotive
Features: Current source/sink DAC, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
Resolution (Bits): 10
Number of DAC channels: 1
Interface type: I2C, SPI
Output type: Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Automotive
Features: (x1) PWM, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: Smart DAC
Resolution (Bits): 10
Number of DAC channels: 1
Interface type: I2C, SPI
Output type: Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Automotive
Features: (x1) PWM, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.4
Operating temperature range (°C): -40 to 125
Product type: Smart DAC
AFE881H1
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 具有 DAC、ADC 和 HART® 调制解调器、适用于传感器发送器的 16 位低功耗模拟前端 (AFE)
Resolution (Bits): 16
Number of DAC channels: 1
Interface type: SPI
Output type: Voltage
Output voltage range (V): 0.15 to 1.25, 0.2 to 1.0, 0.3 to 2.5, 0.4 to 2.0
Reference type: INT/EXT
Architecture: STRING
Rating: Catalog
Features: 4-20mA loop transmitter, HART, HART Modem
Power consumption (typ) (mW): 0.342
Operating temperature range (°C): -55 to 125
Product type: Special-function DAC
Resolution (Bits): 16
Number of DAC channels: 1
Interface type: SPI
Output type: Voltage
Output voltage range (V): 0.15 to 1.25, 0.2 to 1.0, 0.3 to 2.5, 0.4 to 2.0
Reference type: INT/EXT
Architecture: STRING
Rating: Catalog
更多
Features: 4-20mA loop transmitter, HART, HART Modem
Power consumption (typ) (mW): 0.342
Operating temperature range (°C): -55 to 125
Product type: Special-function DAC
DAC53001
数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 数字/模拟(D/A)转换器
描述: 具有 Hi-Z、EEPROM 和波形发生器的 10 位、单通道低功耗电压/电流输出智能 DAC
Resolution (Bits): 10
Number of DAC channels: 1
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: Current source/sink DAC, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.13
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
Resolution (Bits): 10
Number of DAC channels: 1
Interface type: I2C, SPI
Output type: Buffered Current, Buffered Voltage
Output voltage range (V): 0 to 5.5
更多
INL (max) (±LSB): 1
Settling time (µs): 20
Reference type: Ext, Int
Architecture: String
Rating: Catalog
Features: Current source/sink DAC, EEPROM, Smart DAC
Sample/update rate (Msps): 0.025
Power consumption (typ) (mW): 0.13
Operating temperature range (°C): -40 to 125
Product type: General-purpose DAC, Smart DAC
