Resolution (Bits): 16 Number of DAC channels: 2 Interface type: Parallel CMOS Sample/update rate (Msps): 800 Features: High Performance Rating: Catalog Interpolation: 1x, 2x, 4x, 8x Power consumption (typ) (mW): 1750 SFDR (dB): 83 Architecture: Current Sink Operating temperature range (°C): -40 to 85 Reference type: Int Resolution (Bits): 16 Number of DAC channels: 2 Interface type: Parallel CMOS Sample/update rate (Msps): 800 Features: High Performance Rating: Catalog Interpolation: 1x, 2x, 4x, 8x Power consumption (typ) (mW): 1750 更多

Resolution (Bits): 12 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -16.5 to 16.5 INL (max) (±LSB): 1 Settling time (µs): 6 Reference type: Ext Architecture: R-2R Rating: Catalog Features: On-chip Offset and Gain Calibration, SDO Sample/update rate (Msps): 0.125 Power consumption (typ) (mW): 260 Operating temperature range (°C): -40 to 105 Resolution (Bits): 12 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -16.5 to 16.5 INL (max) (±LSB): 1 更多

Resolution (Bits): 14 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -16.5 to 16.5 INL (max) (±LSB): 1 Settling time (µs): 6 Reference type: Ext Architecture: R-2R Rating: Catalog Features: On-chip Offset and Gain Calibration, SDO Sample/update rate (Msps): 0.125 Power consumption (typ) (mW): 260 Operating temperature range (°C): -40 to 105 Resolution (Bits): 14 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -16.5 to 16.5 INL (max) (±LSB): 1 更多

Resolution (Bits): 16 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -10 to 10, -5 to 5, 0 to 10, 0 to 20 INL (max) (±LSB): 1 Settling time (µs): 6 Reference type: Ext Architecture: R-2R Rating: Catalog Features: On-chip Offset and Gain Calibration, SDO Sample/update rate (Msps): 0.125 Power consumption (typ) (mW): 280 Operating temperature range (°C): -40 to 105 Resolution (Bits): 16 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -10 to 10, -5 to 5, 0 to 10, 0 to 20 INL (max) (±LSB): 1 更多

Resolution (Bits): 8 Number of DAC channels: 1 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 0.25 Settling time (µs): 6 Reference type: Ext Architecture: String Rating: Automotive Features: Low Power Sample/update rate (Msps): 0.1 Power consumption (typ) (mW): 0.14 Operating temperature range (°C): -40 to 85 Product type: General-purpose DAC Resolution (Bits): 8 Number of DAC channels: 1 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 更多

Resolution (Bits): 12 Number of DAC channels: 8 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 1 Settling time (µs): 5 Reference type: Ext, Int Architecture: String Rating: Catalog Features: Low glitch Sample/update rate (Msps): 0.1 Power consumption (typ) (mW): 2.2 Operating temperature range (°C): -40 to 125 Product type: General-purpose DAC Resolution (Bits): 12 Number of DAC channels: 8 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 更多

Resolution (Bits): 14 Number of DAC channels: 8 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 4 Settling time (µs): 5 Reference type: Ext, Int Architecture: String Rating: Catalog Features: Low glitch Sample/update rate (Msps): 0.1 Power consumption (typ) (mW): 2.2 Operating temperature range (°C): -40 to 125 Product type: Precision DAC Resolution (Bits): 14 Number of DAC channels: 8 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 更多

Resolution (Bits): 16 Number of DAC channels: 8 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 12 Settling time (µs): 5 Reference type: Ext, Int Architecture: String Rating: Catalog Features: Current source/sink DAC, Reset to Mid-Scale Sample/update rate (Msps): 0.1 Power consumption (typ) (mW): 2.2 Operating temperature range (°C): -40 to 125 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 8 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 更多

Resolution (Bits): 16 Number of DAC channels: 1 Interface type: Parallel LVDS Sample/update rate (Msps): 1000 Features: Ultra High Speed Rating: Catalog Interpolation: 1x Power consumption (typ) (mW): 650 SFDR (dB): 81 Architecture: Current Sink Operating temperature range (°C): -40 to 85 Reference type: Int Resolution (Bits): 16 Number of DAC channels: 1 Interface type: Parallel LVDS Sample/update rate (Msps): 1000 Features: Ultra High Speed Rating: Catalog Interpolation: 1x Power consumption (typ) (mW): 650 更多

Resolution (Bits): 14 Number of DAC channels: 1 Interface type: Parallel LVDS Sample/update rate (Msps): 2400 Features: Ultra High Speed Rating: Space Interpolation: 1x, 2x Power consumption (typ) (mW): 2000 SFDR (dB): 55 Architecture: Current Sink Operating temperature range (°C): -55 to 125 Reference type: Int Resolution (Bits): 14 Number of DAC channels: 1 Interface type: Parallel LVDS Sample/update rate (Msps): 2400 Features: Ultra High Speed Rating: Space Interpolation: 1x, 2x Power consumption (typ) (mW): 2000 更多
