Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Unbuffered Voltage INL (max) (±LSB): 1 Settling time (µs): 1 Reference type: Ext Architecture: R-2R Rating: Catalog Features: Reset to Mid-Scale Sample/update rate (Msps): 1 Power consumption (typ) (mW): 0.015 Operating temperature range (°C): -40 to 105 Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Unbuffered Voltage INL (max) (±LSB): 1 Settling time (µs): 1 Reference type: Ext 更多

Resolution (Bits): 14 Number of DAC channels: 2 Interface type: Parallel Output type: Unbuffered Current INL (max) (±LSB): 1 Settling time (µs): 0.5 Reference type: Ext Architecture: Multiplying DAC Rating: Catalog Features: Reset to Mid-Scale Sample/update rate (Msps): 2 Power consumption (typ) (mW): 0.025 Operating temperature range (°C): -40 to 125 Resolution (Bits): 14 Number of DAC channels: 2 Interface type: Parallel Output type: Unbuffered Current INL (max) (±LSB): 1 Settling time (µs): 0.5 Reference type: Ext 更多

Resolution (Bits): 16 Number of DAC channels: 2 Interface type: Parallel Output type: Unbuffered Current INL (max) (±LSB): 1 Settling time (µs): 0.5 Reference type: Ext Architecture: Multiplying DAC Rating: Catalog Features: Reset to Mid-Scale Sample/update rate (Msps): 2 Power consumption (typ) (mW): 0.025 Operating temperature range (°C): -40 to 125 Resolution (Bits): 16 Number of DAC channels: 2 Interface type: Parallel Output type: Unbuffered Current INL (max) (±LSB): 1 Settling time (µs): 0.5 Reference type: Ext 更多

Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 8 Settling time (µs): 8 Reference type: Ext, Int Architecture: String Rating: Catalog Features: Low Power Sample/update rate (Msps): 0.2 Power consumption (typ) (mW): 2.6 Operating temperature range (°C): -40 to 105 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 更多

Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Unbuffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 1 Settling time (µs): 1 Reference type: Ext Architecture: R-2R Rating: HiRel Enhanced Product Sample/update rate (Msps): 2 Power consumption (typ) (mW): 0.015 Operating temperature range (°C): -55 to 125 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Unbuffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 1 更多

Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Unbuffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 1 Settling time (µs): 1 Reference type: Ext Architecture: R-2R Rating: HiRel Enhanced Product Sample/update rate (Msps): 1 Power consumption (typ) (mW): 0.015 Operating temperature range (°C): -55 to 125 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Unbuffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 1 更多

Resolution (Bits): 16 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 12 Settling time (µs): 10 Reference type: Ext Architecture: String Rating: Catalog Sample/update rate (Msps): 0.2 Power consumption (typ) (mW): 3 Operating temperature range (°C): -40 to 105 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 12 更多

Resolution (Bits): 12 Number of DAC channels: 2 Interface type: Parallel Output type: Unbuffered Current INL (max) (±LSB): 1 Settling time (µs): 0.2 Reference type: Ext Architecture: Multiplying DAC Rating: Catalog Sample/update rate (Msps): 10 Power consumption (typ) (mW): 0.0275 Operating temperature range (°C): -40 to 125 Resolution (Bits): 12 Number of DAC channels: 2 Interface type: Parallel Output type: Unbuffered Current INL (max) (±LSB): 1 Settling time (µs): 0.2 Reference type: Ext Architecture: Multiplying DAC 更多

Resolution (Bits): 8 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 0.5 Settling time (µs): 4.5 Reference type: Ext Architecture: String Rating: Catalog Sample/update rate (Msps): 2.5 Power consumption (typ) (mW): 0.6 Operating temperature range (°C): -40 to 105 Product type: General-purpose DAC Resolution (Bits): 8 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 0.5 更多

Resolution (Bits): 8 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 0.5 Settling time (µs): 4.5 Reference type: Ext Architecture: String Rating: Catalog Features: Low Power Sample/update rate (Msps): 2.5 Power consumption (typ) (mW): 1.1 Operating temperature range (°C): -40 to 105 Product type: General-purpose DAC Resolution (Bits): 8 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 更多
