Resolution (Bits): 16 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5 INL (max) (±LSB): 64 Settling time (µs): 10 Reference type: Ext Architecture: String Rating: Catalog Sample/update rate (Msps): 0.093 Power consumption (typ) (mW): 2.7 Operating temperature range (°C): -40 to 105 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 4 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5 INL (max) (±LSB): 64 更多

Resolution (Bits): 12 Number of DAC channels: 1 Interface type: Parallel Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 4 Settling time (µs): 1 Reference type: Ext Architecture: String Rating: HiRel Enhanced Product Sample/update rate (Msps): 1 Power consumption (typ) (mW): 4.3 Operating temperature range (°C): -40 to 125 Product type: General-purpose DAC Resolution (Bits): 12 Number of DAC channels: 1 Interface type: Parallel Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 4 更多

Resolution (Bits): 12 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5 INL (max) (±LSB): 4 Settling time (µs): 1 Reference type: Ext, Int Architecture: String Rating: HiRel Enhanced Product Sample/update rate (Msps): 0.233 Power consumption (typ) (mW): 4.5 Operating temperature range (°C): -55 to 125 Product type: General-purpose DAC Resolution (Bits): 12 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5 INL (max) (±LSB): 4 更多

Resolution (Bits): 14 Number of DAC channels: 1 Interface type: Parallel LVDS Sample/update rate (Msps): 400 Features: High Performance Rating: Catalog Interpolation: 1x Power consumption (typ) (mW): 820 SFDR (dB): 77 Architecture: Current Sink Operating temperature range (°C): -40 to 85 Reference type: Ext, Int Resolution (Bits): 14 Number of DAC channels: 1 Interface type: Parallel LVDS Sample/update rate (Msps): 400 Features: High Performance Rating: Catalog Interpolation: 1x Power consumption (typ) (mW): 820 更多

Resolution (Bits): 16 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -2.5 to 2.5, -5 to 5 INL (max) (±LSB): 3 Settling time (µs): 10 Reference type: Ext Architecture: R-2R Rating: Catalog Features: Reset to Mid-Scale Sample/update rate (Msps): 0.089 Power consumption (typ) (mW): 2.5 Operating temperature range (°C): -40 to 85 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -2.5 to 2.5, -5 to 5 更多

Resolution (Bits): 16 Number of DAC channels: 2 Interface type: Parallel Output type: Buffered Voltage Settling time (µs): 10 Features: Reset to Mid-Scale Reference type: Ext Architecture: R-2R Rating: Catalog Output range (max) (mA/V): 2.5 Output range (min) (mA/V): -2.5 Sample/update rate (Msps): 0.1 Power consumption (typ) (mW): 2.5 Operating temperature range (°C): -40 to 85 Resolution (Bits): 16 Number of DAC channels: 2 Interface type: Parallel Output type: Buffered Voltage Settling time (µs): 10 Features: Reset to Mid-Scale 更多

Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -10 to 10, -5 to 5, 0 to 10 INL (max) (±LSB): 3 Settling time (µs): 5 Reference type: Ext, Int Architecture: R-2R Rating: Catalog Features: Reset to Mid-Scale, SDO Sample/update rate (Msps): 0.172 Power consumption (typ) (mW): 100 Operating temperature range (°C): -40 to 85 Resolution (Bits): 16 Number of DAC channels: 1 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): -10 to 10, -5 to 5, 0 to 10 INL (max) (±LSB): 3 更多

Resolution (Bits): 16 Number of DAC channels: 1 Interface type: Parallel Output type: Buffered Voltage INL (max) (±LSB): 3 Settling time (µs): 5 Reference type: Ext, Int Architecture: R-2R Rating: Catalog Features: Reset to Mid-Scale Sample/update rate (Msps): 0.2 Power consumption (typ) (mW): 100 Operating temperature range (°C): -40 to 85 Resolution (Bits): 16 Number of DAC channels: 1 Interface type: Parallel Output type: Buffered Voltage INL (max) (±LSB): 3 Settling time (µs): 5 Reference type: Ext, Int 更多

Resolution (Bits): 16 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5 INL (max) (±LSB): 65 Settling time (µs): 10 Reference type: Ext Architecture: String Rating: Catalog Sample/update rate (Msps): 0.093 Power consumption (typ) (mW): 1.35 Operating temperature range (°C): -40 to 105 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 2 Interface type: SPI Output type: Buffered Voltage Output voltage range (V): 0 to 5 INL (max) (±LSB): 65 更多

Resolution (Bits): 16 Number of DAC channels: 1 Interface type: Parallel Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 INL (max) (±LSB): 65 Settling time (µs): 10 Reference type: Ext Architecture: String Rating: Catalog Features: Reset to Mid-Scale Sample/update rate (Msps): 0.1 Power consumption (typ) (mW): 0.72 Operating temperature range (°C): -40 to 85 Product type: Precision DAC Resolution (Bits): 16 Number of DAC channels: 1 Interface type: Parallel Output type: Buffered Voltage Output voltage range (V): 0 to 5.5 更多
